Summary of Contents for Nex Dryft A90 BLDC
- Page 1 FEEL THE FUTURE INSTRUCTION MANUAL This handy guide will help you put your Nex fan together. Have more questions? Talk to us at care@nexlife.com...
- Page 2 ASSEMBLY & INSTALLATION: FAN INSTALLATION & ASSEMBLY OF BLADE 1. Place the motor on thermo buffer to avoid any scratches as shown in (Figure 1). 2. Unscrew the blade screw from Motor and align the blade with the motor as shown in (Figure 1).
- Page 3 INSTALLATION OF HANGING ASSEMBLY & CANOPIES TO MOTOR 1. Hold the down-rod vertically with Slit side downward. 2. Slide canopy stopper (4a) from top end of down rod & Ensure Figure 6A stopper should be below down rod(3)slit hole. Now Pass the connection wires through slit hole at the Bottom end of down rod (3) and remove them from the top end of down rod (Figure CANOPY...
- Page 4 IN CASE OF FALSE CEILING WHERE DOWN ROD IS ALREADY INSTALLED IN CEILING 1. Assemble top canopy (5) and false ceiling cover (5b) together (figure 7) and slide it up from bottom end of down rod (already mounted). 2. Slide the bottom canopy(4) from down side of top canopy(5). 3.
-
Page 5: Remote Control Diagram
IMPORTANT The diagram of fan are just the general representation of ceiling fan and not the actual fan. Read the instructions carefully. Open the packing and arrange the fan parts as per the numers marked on diagram. Assemble & install fan as per the assembly, wiring diagram and written instruction. Check the assembled fan, ensure proper installation before switching ON the fan. - Page 6 REMOTE PAIRING INSTRUCTIONS PERFORM WITHIN 10 SECONDS 1.TURN "ON" FAN FROM MAINS SUPPLY 2 BEEPS HOLD THE 2.PRESS "POWER" BUTTON ON REMOTE TURN "OFF" FAN INDICATES REMOTE IN 3.THEN PRESS "SPEED 1" ON REMOTE FROM MAINS SUCCESSFUL HAND WITHIN 10 SECONDS PAIRING IF PAIRING FAILS REPEAT ABOVE STEPS STEP 1...
- Page 7 TROUBLE-SHOOTING INSTRUCTION Problem Causes Solutions A. Opposite Placement of Canopy A. Ensure the slotted bush of canopy Stopper stopper must be on upper side Excessive gap between Bottom canopy and Top Cover B. Bottom Canopy does not rest on B. Pull Bottom Canopy downward Canopy stopper up to canopy stopper Down rod length is short because...
-
Page 8: Selection Guide
WARNING THE INSTALLATION OF THE FANS SHOULD BE AS PER INSTRUCTION MANUAL TO AVOID ANY DAMAGE TO FANS AND OTHER MOVING PARTS. DAMAGE OF ANY MOVING PARTS DUE TO IMPROPER INSTALLATION MAY LEAD TO INJURY. SELECTION GUIDE Ceiling Fan Room Size Fan Sweep recommend Sweep Less than 8 X 8 ft... - Page 9 INSTALLATION OF SUPPORT CABLE WITH FAN Installation of Secondary Support Cable CAUTION The purpose of Secondary support Cable is to temporarily hold the fan with ceiling hook, in case of failuse of primary suspension system, which may happen due to faulty installation, inadequate tightening of fasteners like nut &...
