Owner's Manual
Winter Use Device:
WUD
For use only with GSWH-1
Helps Protect the GSWH-1 from
Freezing Temperatures that may
cause damage to the unit.
• Installation
• Operation
• Service and Maintenance
Installation and service must be
performed by a certified installer or
service agency.
The WUD is certified for use with the
Girard Tankless Water Heater System
in RV's constructed for use where
freezing temperatures are likely.
Girard Products LLC, 1361 Calle Avanazado, San Clemente CA 92673 U.S.A
Owner's Manual Part No. 1GWH9403
CAUTION:
Read and Follow
all the Safety Rules
and Instructions.
Patent Pending
P a g e
1

Advertisement

Table of Contents
loading

Related Manuals for Girard Products WUD

Summary of Contents for Girard Products WUD

  • Page 1 Safety Rules Girard Tankless Water Heater System in RV’s constructed for use where and Instructions. freezing temperatures are likely. Girard Products LLC, 1361 Calle Avanazado, San Clemente CA 92673 U.S.A Owner’s Manual Part No. 1GWH9403 Patent Pending P a g e...
  • Page 2 Winter Use Device - WUD Installer/Customer Responsibilities • Read and observe all safety rules • Keep these instructions and warranty for future reference • If this device is purchased as an aftermarket item. Installation and Service must be performed by a certified installer or service agency.

  • Page 3: Critical Installation Warnings

    WARNING! PRODUCT DAMAGE • Freezing of the internal pipes and Heat Exchanger of the Model GSWH-1 water heater will result in severe damage not covered by warranty. For this reason it is not advisable to use the GSWH-1 in the winter unless the RV is manufactured for use in the winter and equipped with the Winter Use Device.
  • Page 4 WINTER USE DEVICE (WUD) Description Girard Products LLC offers a Winter Use Device (WUD - Part# 1GWHAF) as an option for use with the GSWH-1. The Winter Use Device helps protect the GSWH-1 water heater when freezing conditions are likely to occur by automatically activating the GSWH-1 for a short period of time. This is know as the Anti-Freezing Mode.
  • Page 5 • All models of the Girard GSWH-1 Tankless Water Heater (with or without the Winter Use Device) must be winterized if the RV is not in use and/or in storage. C. Components The WUD device consists of two components: 1) a Thermostat and 2) a Solenoid 1.
  • Page 6 Figure 2 2. Solenoid Valve. The Solenoid Valve may be located in either of two locations: Option 1: attached to the Hot Water Outlet on the back of the Water Heater (recommended) and plumbed both to the Hot Water System AND the fresh water tank;...
  • Page 7 Figure 3 PEX tubing and connector may be used for the installation of the Solenoid Valve. INSTALLATION, OPERATION, MAINTENANCE AND SERVICE WARNING! PRODUCT DAMAGE! • Freezing of the internal pipes and Heat Exchanger of the Model GSWH-1 water heater will result in severe damage not covered by warranty.

  • Page 8: Plumbing Installations

    • DO NOT modify the Winter Use Device in any way. This is dangerous and will void the warranty. The following instructions apply to the most common type of installation for Girard Products Winter Use Device. Consult with Girard Products, LLC technical support or engineering department if you have any additional questions regarding your specific installation/application.
  • Page 9 B. Electrical The wiring of the solenoid valve may be carried out with either 16AWG or 18AWG wires. Simply bring an extension of the orange wire from the Water heater to the location of the Solenoid Valve and connect to the RED wire on the Solenoid Valve. The current draw of the valve at 12 VDC is less than 350mA.

  • Page 10: Operation

    Operation Anti-freezing Mode The operation of the Anti-Freezing Mode in the Winter Use Device (WUD) is TOTALLY AUTOMATIC, IF the GSWH-1 SWITCH is set to the ‘ON’ position, the system is POWERED with 12VDC (the PUMP must be ON), GAS is available i.e., turned ON, and FRESH WATER from the holding tank is provided to the water heater.

  • Page 11: Two Year Limited Warranty

    This limited warranty extends to the original owner of the product only, is not transferable and is subject to the following conditions: 1. For a period of two years from the date of purchase, Girard Products will replace any parts that are found defective and will pay a warranty service allowance directly to the recommended Girard Products Water Heater Service Center at rates mutually agreed upon between Girard Products and its recommended service centers.
  • Page 12 PAYMENTS WILL NOT BE REIMBURSED. Be sure to provide purchase documentation regarding your Girard Products. The Girard Products Winter Use Device is designed for use with the Girard Tankless Water Heater in recreation vehicles designed specifically for winter use. Any other use, unless authorized in writing by the Girard Products Engineering Department, voids this warranty.

Table of Contents
