MODEL EMBER VISION 100 AND 200 SERIES
EMBER VISION 100 SERIES VENT-FREE OR VENTED 24"(OAK) GAS LOG SET
EMBER VISION 200 SERIES VENT-FREE OR VENTED 30"(OAK) GAS LOG SET
WARNING: If the following information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury, or loss of life.
-DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER APPLIANCE.
-WHAT TO DO IF YOU SMELL GAS
* Do not try to light any appliance.
* Do not touch any electrical switch; do not use any phone in your building.
* Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
* If you cannot reach the gas supplier, call the fire department.
-Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
-This appliance is intended for supplemental heating.
This is an unvented and vented gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate air for combustion and ventilation must be provided. Refer to Section V, page 20.
This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases.
WARNING: This appliance is equipped for (natural or propane) gas. Field conversion is not permitted.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
New Buck Corporation
200 Ethan Allen Drive
P.O. Box 69
Spruce Pine, NC 28777
www.buckstove.com
FOR NATURAL OR LIQUID PETROLEUM (L.P.)
WITH OPTIONAL HEAT SHIELD MODEL 19HS
Revised November 2019

Advertisement

Table of Contents
loading

Summary of Contents for BuckMaster EMBER VISION 100 Series

  • Page 1 MODEL EMBER VISION 100 AND 200 SERIES EMBER VISION 100 SERIES VENT-FREE OR VENTED 24”(OAK) GAS LOG SET EMBER VISION 200 SERIES VENT-FREE OR VENTED 30”(OAK) GAS LOG SET FOR NATURAL OR LIQUID PETROLEUM (L.P.) WITH OPTIONAL HEAT SHIELD MODEL 19HS WARNING: If the following information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.
  • Page 2 Page 2...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION I: Safety Information ....................1 SECTION II: Residential Installation-Unvented Gas Logs ............4 Clearances ............................5 Gas Connection ..........................5 Preparing Log Kit .......................... 6 Log Placement ..........................7 Gas Pressure Check ........................8 Lighting Instructions ........................9 Flame Check ..........................
  • Page 4: Section I: Safety Information

    SECTION I SAFETY INFORMATION WARNINGS IMPORTANT: READ THIS OWNER'S MANUAL CAREFULLY AND COMPLETELY BEFORE TRYING TO ASSEMBLE, OPERATE, OR SERVICE THE APPLIANCE. IMPROPER USE OF THESE LOGS CAN CAUSE SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, AND CARBON MONOXIDE POISONING.
  • Page 5 5. Two models are available. One specific model for propane (LP), and one for natural gas. Use the correct gas type for your home. This unit is not field convertible. 6. If these gas logs are for use with propane gas, do not place propane supply tank(s) inside any structure.
  • Page 6 17. Do not use the appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. 18.
  • Page 7: Section Ii: Residential Installation-Unvented Gas Logs

    SECTION II RESIDENTIAL INSTALLATION OF GAS LOGS FIREPLACE PREPARATION The fireplace needs to be prepared before installing the gas logs. A. Turn off the gas supply to the fireplace. B. Any outside air ducts on the fireplace shall be permanently closed at the time of the appliance installation.
  • Page 8: Clearances

    WARNING: THIS APPLIANCE IS FOR INSTALLATION ONLY IN A SOLID FUEL BURNING MASONRY OR UL127 FACTORY BUILT FIREPLACE OR IN A LISTED VENTLESS FIREBOX ENCLOSURE. IT HAS BEEN DESIGN CERTIFIED FOR THESE INSTALLATIONS. EXCEPTION: DO NOT INSTALL THIS APPLIANCE IN A FACTORY BUILT FIREPLACE THAT INCLUDES INSTRUCTIONS STATING IT HAS NOT BEEN TESTED OR SHOULD NOT BE USED WITH UNVENTED GAS LOGS.
  • Page 9: Preparing Log Kit

    Always use an external regulator for all LP heaters to reduce the supply tank pressure to a maximum of 13" W.C. This is in addition to the regulator furnished with the heater. Warning: Connection directly to an unregulated LP tank can cause an explosion. The normal gas connection is 3/8"...
  • Page 10: Log Placement

    LOG PLACEMENT FOR EMBER VISION OAK - 100 SERIES 24” AND 200 SERIES 30” LOG SET Figure 2. REV. DATE DISCRIPTION APRVD Apply loose material per instructions manual. DO NOT apply extra material or material not sup- plied with the heater. Replace only with material from your Buck Stove dealer or from New Buck Corporation.
  • Page 11: Gas Pressure Check

    GAS PRESSURE CHECK Check the inlet pressure to the burner to ensure that it is as shown in the table below. NOTE: The pressure check point is located on right side of valve facing the burner. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa).
  • Page 12: Lighting Instructions

    OPERATING INSTRUCTIONS Before operating this appliance, proceed through the following checklist. 1. Read and understand these instructions before operating this appliance. 2. Check that there are no gas leaks. If you smell gas do not attempt to light this appliance. 3.
  • Page 13 LIGHTING INSTRUCTIONS 1. STOP! Read the safety information on the reverse side of this label. 2. Make sure manual shutoff valve is fully closed. If equipped with thermostat, set to the low- est setting. 3. Turn off all electrical power to the appliance. 4.
  • Page 14 * If the pilot will not stay lit after several tries, turn the gas control knob to “OFF” and call your service technician or gas supplier. 10. Turn control knob counterclockwise to “ON”. 11. If using unit without wall thermostat place Auto/Off/Manual switch into the manual position.
  • Page 15 MANUAL LIGHTING PROCEDURE 1. If the pilot cannot be ignited with the piezo, it can be manually lit with the use of a paper match and lighter rod. 2. Place the match in the holder and light. With the left hand, depress the control knob ...
  • Page 16: Flame Check

    BURNER & PILOT FLAME CHECK A periodic check of the flames should be made. The pilot flame should always be present when the gas logs are in operation. See figure below. Rear Flames: The flames at the rear should be yellow in color, and should extend about 4" to 5" above the large rear log for natural gas logs and about 6"...
  • Page 17: Section Iii: Installation-Heat Shield

    Heat Shield base, there is a “go through hole”. Position the Heat Shield as described above. Mark the hole for drilling. See Figure 6. NOTE: When using Ember Vision 100 Series Log Set with optional Heat Shield the following minimums must be met: Front 34"-Rear 31"-Height 20"-Depth 20 1/2"...
  • Page 18: Replacement Parts Heat Shield

    REPLACEMENT PARTS FOR (OPTIONAL) HEAT SHIELD MODEL 19HS Always include correct name, part number, and model number of the heater when ordering service parts. KEY# PART DESCRIPTION PART NUMBER BLOWER PE-A2-40-01. Rating: .120 volts/60HZ/ .54 Amps 110 THERMOSTAT PE 400132 CHROME SHIELD PO HS14 POWER CORD...
  • Page 19: Wiring Diagram

    WARNING: CHILDREN AND ADULTS SHOULD BE ALERTED TO THE HAZARDS OF HIGH SURFACE TEMPERATURES AND SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN THEY ARE IN THE SAME ROOM AS THESE GAS LOGS.
  • Page 20: Section Iv: Installation-Permanently Located After Market Manufactured Home

    SECTION IV AFTER MARKET MANUFACTURED HOME INSTALLATION THIS APPLIANCE MAY BE INSTALLED IN AN PERMANENTLY LOCATED AFTERMARKET MANUFACTURED HOME, WHERE NOT PROHIBITED BY LOCAL CODES. *After Market: Completion of sale, not for the purpose of resale from the manufacturer. THIS APPLIANCE IS ONLY FOR USE WITH THE TYPE OF GAS INDICATED ON THE RATING PLATE.
  • Page 21 NOTICE SOME AREAS IN THE UNITED STATES HAVE HIGHER REQUIREMENTS FOR CUBIC FEET PER 1000 BTU/ HOUR INPUT. (EX. CINCINNATI, OHIO CODES REQUIRE 70 CUBIC FEET). CHECK YOUR LOCAL CODE BEFORE INSTALLATION. DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION DETERMINE IF YOU HAVE UNUSUALLY TIGHT CONSTRUCTION OR UNCONFINED SPACE Use this worksheet to determine if you have unusually tight construction or unconfined space.
  • Page 22 Example: Gas water heater 40000 BTU/Hr Vent-free heater + 18000 BTU/Hr Total = 58000 BTU/Hr *Does not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors. 4. Compare the maximum BTU/Hr the space can support with the actual amount of BTU/Hr used.
  • Page 23: Ventilation Air For Combustion And Ventilation From Inside

    VENTILATION AIR FOR COMBUSTION AND VENTILATION FROM INSIDE BUILDING This fresh air would come from an adjoining unconfined space. When ventilating to an adjoining space, you must provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor on the wall connecting the two spaces (See Options 1 and 2, Figure 8.
  • Page 24: Ventilation Air For Combustion And Ventilation From Outdoors

    WARNING THIS HEATER MUST HAVE ADEQUATE AMOUNT OF AIR FOR PROPER OPERATION. IF NOT, POOR FUEL COMBUSTION COULD RESULT. READ THE FOLLOWING INSTRUCTIONS TO ENSURE PROPER AMOUNT OF AIR FOR THIS AND OTHER FUEL-BURNING APPLIANCES IN YOUR HOME. VENTILATION AIR FOR COMBUSTION AND VENTILATION FROM OUTDOORS Provide extra fresh air by using ventilation grills or ducts.
  • Page 25: Section Vi: Vented Logs

    SECTION VI VENTED LOGS (1) This appliance must be installed only in a solid-fuel burning fireplace with a working flue and constructed of non-combustible materials. (2) A minimum of 34 sq. in. (Min.6’chimney height) (Min. 7” diameter round flue), permanent flue opening must be provided by either the fireplace chimney or chimney damper to vent the flue gases.
  • Page 26 (5) See: GAS PRESSURE CHECK, page 8. (6) See: OPERATING INSTRUCTIONS, pages 9-12. (7) See: BURNER & PILOT FLAME CHECK, for proper flame pattern, page 13. (8) See: CLEANING INSTRUCTIONS, page 24. NOTE: Visually check the pilot and burner flames annually, and monthly during seasons that the appliance is operating frequently.
  • Page 27: Important Safeguards

    Appliance Input Rate (kBTU/hr) Chimney Minimum Opening** (sq. in.) Input* Height* (ft) 11.3 16.6 22.1 28.3 35.3 44.2 —– —– —– —– —– 77.6 12.6 17.3 21.2 26.4 32.2 38.5 45.4 —– —– —– 98.2 10.8 14.5 18.1 22.1 26.4 31.2 37.4 43.0...
  • Page 28: Troubleshooting

    If the flames show any unusual shapes or behavior, or if the burners fail to ignite properly, then the burner holes may require cleaning. If this occurs, it is preferable to contact your nearest dealer to get your heater serviced. Alternatively, the heater can becleaned by removing the top, front, and rear logs.
  • Page 29 4. Air in gas lines when 4. Continue to hold down control installed knob. Repeat igniting operation until air is removed. 5. Depleted gas supply 5. Contact local propane gas company 6. ODS/PILOT is clogged 6. Clean ODS/PILOT or replace ODS/PILOT assembly 7.
  • Page 30 OBSERVED POSSIBLE PROBLEM CAUSE SOLUTION Burner does not light after ODS/ 1. Burner orifice is clogged 1. Clean burner (see Cleaning PILOT is lit and Maintenance) or replace burner orifice 2. Inlet gas pressure is too low 2. Contact local propane gas company Delayed ignition of burner 1.
  • Page 31 WARNING IF YOU SMELL GAS: * SHUT OFF GAS SUPPLY * DO NOT TRY TO LIGHT APPLIANCE * DO NOT TOUCH ANY ELECTRICAL SWITCH; DO NOT USE ANY PHONE IN YOUR BUILDING * IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOR’S PHONE.
  • Page 32 OBSERVED POSSIBLE SOLUTION PROBLEM CAUSE Gas odor during combustion 1. Foreign matter between 1. Take apart gas tubing and control valve and burner remove foreign matter 2. Gas Leak. See 2. Locate and correct all leaks “WARNING” statement at top (See “Checking Gas of previous page Connections”)
  • Page 33: Servicing And Replacement Parts

    NOTE: You may want to have your chimney cleaned by a professional before installing unit. SERVICING Repair and replacement work should only be done by a qualified service person. Always shut off the gas supply and make sure that heater is cool before beginning any service operation.
  • Page 34 REPAIR PARTS A parts list with exploded view follows. Always include correct name, part number, and model number of the heater when ordering service parts. Please contact your local dealer or distributor when ordering . If one is not available, you may contact. New Buck Corporation 200 Ethan Allen Drive, P.O.
  • Page 35: Warranty

    NEW BUCK CORPORATION 200 ETHAN ALLEN DRIVE ● P.O. BOX 69 SPRUCE PINE, NC 28777 We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty. We make no other warranty, expressed or implied.
  • Page 36 Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential damages, so the above limitation on implied warran- ties, or exclusion or limitation on damages may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
