TECHNICAL DATA SHEET
AGE GROUP:
PLAYERS:
Size (cm):
IMPACT ZONE:
FREE FALL HEIGHT:
STANDARDS:
G007 - springer
1. ОБЩА ХАРАКТЕРИСТИКА
3-12 y
1 max
L:85/W:25/H:85
6 m2
49 cm
metal plates; HDPE panels; springer
anchor / concrete
EN1176-1, EN1176-6
60 m
web:gotinshtain.com
e-mail: office@gotinshtain.com
tel: +359 896 602070
ISO 9001
ISO 14001
Advertisement
Table of Contents
Related Manuals for GOTINSHTAIN G007 springer
Summary of Contents for GOTINSHTAIN G007 springer
- Page 1 +359 896 602070 ISO 9001 ISO 14001 TECHNICAL DATA SHEET G007 - springer 1. ОБЩА ХАРАКТЕРИСТИКА 3-12 y AGE GROUP: PLAYERS: 1 max L:85/W:25/H:85 SIZE (cm): 6 m2 IMPACT ZONE: 49 cm FREE FALL HEIGHT: MATERIALS: metal plates;...
- Page 2 +359 896 602070 2. SIZE 3. IMPACT ZONE - 6 m2 4. INSTALLATION Concrete Anchor Pole Pole Level 0 mark Anchor plate Shock absorbing layer Shock absorbing layer Reinforcing steel Level 0 Ground Concrete 40/40/40cm Ground...
- Page 3 +359 896 602070 5. MATERIALS Constructions They are made of metal tubes and plates, which ensure strength, long-term use, durability and reliability of the equipments. Metal parts are covered by anti-corrosion primer and paint with UV protection.The structures of the facilities are designed according to the requirements of EN 1176-1.
