TECHNICAL DATA SHEET
AGE GROUP:
PLAYERS:
Size (cm):
FREE FALL HEIGHT:
STANDARDS:
GSL12 - slide
1. FEATURES
0-6 y
1 max
L:198/W:53/H:189
14 m2
85 cm
metal tubes; metal plates; HDPE panels; HEXA panels
anchor / concrete
EN1176-1; EN1176-3
60 m
web:gotinshtain.com
e-mail: office@gotinshtain.com
tel: +359 896 602070
ISO 9001
ISO 14001
Advertisement
Table of Contents
Related Manuals for GOTINSHTAIN GSL12
Summary of Contents for GOTINSHTAIN GSL12
- Page 1 +359 896 602070 ISO 9001 ISO 14001 TECHNICAL DATA SHEET GSL12 - slide 1. FEATURES 0-6 y AGE GROUP: PLAYERS: 1 max L:198/W:53/H:189 SIZE (cm): 14 m2 IMPACT ZONE: 85 cm FREE FALL HEIGHT: MATERIALS: metal tubes; metal plates; HDPE panels; HEXA panels...
- Page 2 3. IMPACT ZONE - 14 m2 150 см 150 см 498 см 4. INSTALLATION Concrete Anchor Pole Pole Level 0 mark Anchor plate Shock absorbing layer Shock absorbing layer Reinforcing steel Level 0 Ground Concrete 40/40/40cm Ground 40 cm GSL12 - slide TECHNICAL DATA SHEET...
- Page 3 +359 896 602070 5. MATERIALS Constructions They are made of metal tubes and plates, which ensure strength, long-term use, durability and reliability of the equipments. Metal parts are covered by anti-corrosion primer and paint with UV protection.The structures of the facilities are designed according to the requirements of EN 1176-1.
