Summary of Contents for Siemens iQ700 HS858KX 6 Series
- Page 1 Combi steam oven HS858KX.6 User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Safety Table of contents 1 Safety Observe the following safety instructions. 1.1 General information USER MANUAL ¡ Read this instruction manual carefully. Safety .............. 2 ¡ Keep the instruction manual and the Preventing material damage ....... 4 product information safe for future refer- ence or for the next owner. -
Page 3: Safety
Safety en ▶ If smoke is emitted, the appliance must be WARNING ‒ Risk of injury! switched off or the plug must be pulled out Scratched glass in the appliance door may and the door must be held closed in order develop into a crack. to stifle any flames. -
Page 4: Preventing Material Damage
en Preventing material damage electronic implants, e.g. heart pacemakers or Hot liquid may spill over the sides of the ac- insulin pumps. cessory when it is removed from the cooking ▶ Wearers of electronic implants must stay at compartment. least 10 cm away from the control panel. ▶... -
Page 5: Environmental Protection And Saving En- Ergy
Environmental protection and saving energy en Only leave the cooking compartment to dry with the ▶ 2.2 Steam door open if a lot of moisture was produced during Follow these instructions when using the steam func- operation. tion. Fruit juice dripping from the baking tray leaves stains that cannot be removed. - Page 6 en Familiarising yourself with your appliance 4 Familiarising yourself with your appliance 4.1 Control panel Buttons The buttons on the left- and right-hand side of You can use the control panel to configure all functions the control panel have a pressure point. Press of your appliance and to obtain information about the a button to execute its function.
-
Page 7: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en Countdown Self-cleaning surfaces You can view the countdown time or the cooking time The self-cleaning surfaces in the cooking compartment for the previous operation in the top right in the status are coated with a porous, matt ceramic layer and have bar. -
Page 8: Operating Modes
en Operating modes Tank cover Opening for filling and emptying Handle for removing and inserting 5 Operating modes This is where you can find an overview of your appli- Operating ance's operating modes and main functions. mode Press to open the menu. Basic set- Adjust the basic settings. - Page 9 Accessories en Symbol Types of heating Temperature What it's used for and how it works range Possible additional options Grill, small area Grill settings: Grill small quantities, such as steak, sausages or toast. Gratinate 1 = low small quantities of food. 2 = medium The central area below the grill element becomes hot.
-
Page 10: Accessories
en Accessories Accessories Wire rack ¡ Cake tins ¡ Ovenproof dishes ¡ Cookware ¡ Meat, e.g. roasting joints or steak ¡ Frozen meals Universal pan ¡ Moist cakes ¡ Baked items ¡ Bread ¡ Large roasts ¡ Frozen meals ¡ Catch dripping liquids, e.g. fat when grilling food on the wire rack or water when cooking with steam. -
Page 11: Before Using For The First Time
You will find a comprehensive range of products for your appliance in our brochures and online: www.siemens-home.bsh-group.com Accessories vary from one appliance to another. When purchasing accessories, always quote the exact product number (E no.) of your appliance. -
Page 12: Basic Operation
en Before using for the first time Setting Water hardness in German hardness in French hardness °fH mmol/l °dH 0 (softened) 1 (soft) Up to 1.5 Up to 8.4 Up to 15 2 (moderately hard) 1.5-2.5 8.4-14 15-25 3 (hard) 2.5-3.8 14-21.3 25-38 4 (very hard) -
Page 13: Time-Setting Options
Change any further settings depending on the selec- button lights up blue. ‒ tion. a The Siemens logo appears in the display. A type of Press to start. heating and a temperature are then displayed. 8.6 Setting the type of heating and the 8.2 Switching off the appliance... - Page 14 en Rapid heating 9 Rapid heating To save time, you can shorten the preheating time for Set a suitable type of heating and a temperature of set temperatures of 100 °C and higher. at least 100 °C. You can use rapid heating for this type of heating: Press ...
- Page 15 Steam en When the food is ready, press to switch the Press to start the operation. ‒ appliance off. a The status bar shows a notification when the opera- tion starts. The appliance is in standby mode. Changing the cooking time a Once the start time has been reached, the appli- You can change the cooking time at any time.
-
Page 16: Steam
en Steam Lift the water tank and remove it from the water tank Reheating recess . The reheating function can be used to warm up food that has already been cooked, or bread and pastries from the day before. Defrosting Use the defrost setting to defrost deep-frozen and frozen products. - Page 17 Steam en To set another cooking time, press the cooking Note: If the water tank runs dry during operation, a ‒ time and use the rotary selector to set the value. notification appears in the display. The appliance When the food is ready, press to switch the continues to operate without steam injection.
- Page 18 en Meat probe Drying the drip trough Dry the cooking compartment by hand or use the ▶ "Drying" function. WARNING ‒ Risk of burns! → "Drying", Page 29 The appliance becomes hot during operation. Drying the cooking compartment manually Allow the appliance to cool down before cleaning. ▶...
- Page 19 Meat probe en a The required temperature and core temperature are Thick Insert the meat probe diagonally into the in the centre and to the right of the display. The cur- pieces meat from above, pushing it in as far as rent temperature or core temperature is shown on of meat possible.
-
Page 20: Meat Probe
en Dishes Food Core temperature Food Core temperature in °C in °C Beef, rare Lamb Beef, medium Heating food, reheating 65–75 Beef, well done 13 Dishes The "Dishes" operating mode helps you to use your ap- Meat probe pliance to prepare different meals by selecting the op- You can use the meat probe for several dishes. -
Page 21: Dishes
Dishes en 13.5 Adjusting the dish Category Foods Fish Fish, whole Note: Once it has started, you can no longer change or Fish fillets interrupt the dish or the settings. Fish dishes Requirement: To start the operation, the cooking com- Seafood partment must be cooled down. Side dishes, Vegetables Press... -
Page 22: Childproof Lock
en Childproof lock 14 Childproof lock You can secure your appliance to prevent children a A confirmation notification appears on the display. from accidentally switching it on or changing the set- a The appears in the status bar when the appliance tings. - Page 23 Home Connect en Download the Home Connect app. Open the Home Connect app and scan the follow- ing QR code. Follow the instructions in the Home Connect app. 16.2 Home Connect Settings You can adjust the settings and network settings for Home Connect by going to your appliance's basic settings. Which settings the display shows will depend on whether Home Connect has been set up and whether the appliance is connected to your home network.
-
Page 24: Sabbath Mode
The first time your appliance is registered on a home A detailed RED Declaration of Conformity can be found network connected to the Internet, your appliance will online at www.siemens-home.bsh-group.com among transmit the following types of data to the the additional documents on the product page for your Home Connect server (initial registration):... -
Page 25: Home Connect
Cleaning and servicing en Select the "Settings" operating mode. Basic setting Selection a The first basic setting appears. Home Connect Home Connect Settings Press to switch between the different settings. → "Home Connect ", Use the rotary selector to change the basic setting. Page 22 Press ... - Page 26 en Cleaning and servicing Area Suitable cleaning agents Information Door cover ¡ Made of stainless Do not use glass cleaner or a glass scraper. steel: Do not use stainless steel care products. Stainless steel cleaner Tip: Remove the door cover for thorough cleaning. ¡...
-
Page 27: Cleaning Function
Cleaning function en For some surfaces, you can use alternative 18.2 Cleaning the appliance ‒ cleaning agents. In order to avoid damaging the appliance, you must → "Suitable cleaning agents", Page 25 clean your appliance only as specified, and with suit- Dry with a soft cloth. able cleaning products. -
Page 28: Cleaning Assistance
en Cleaning assistance Remove accessories and cookware from the cook- Press to start. ing compartment. Note: Do not open the appliance door while the Detach the shelf supports and remove them from cleaning function is running. The cleaning result the cooking compartment. would no longer be correct and the operation is in- → "Rails", Page 33 terrupted. -
Page 29: Descaling
Descaling en Remove limescale with a cloth soaked in vinegar. In order to dry the cooking compartment, leave the Then wipe with clean water and rub dry with a soft appliance door open in the detent position (approx. cloth (including under the door seal). 30°) for approx. one hour. - Page 30 en Appliance door Press to start the drying function. A message appears in the display. ‒ a The appliance starts to dry and the duration counts Press to silence the audible signal before ‒ down. it is due to end. Once the duration has elapsed: Press to switch the appliance off.
- Page 31 Appliance door en Close the locking levers on the left- and right-hand Lift out the inner pane and set it down carefully hinges . on a flat surface. Lift out the intermediate pane and set it down carefully on a flat surface. a The locking levers are closed.
- Page 32 en Appliance door Open the appliance door and attach the door seal. 23.4 Fitting the door panes WARNING ‒ Risk of injury! The hinges on the appliance door move when the door is opened and closed, which could trap your fingers. Keep your hands away from the hinges. ▶...
-
Page 33: Rails
Rails en Note: Do not use the cooking compartment again until the door panes have been correctly fitted. 24 Rails To thoroughly clean the rails and the cooking compart- 24.2 Attaching the rails ment, or to replace the rails, you can remove the rails. Notes ¡... - Page 34 en Troubleshooting Fault Cause and troubleshooting The operation does Malfunction not start or is inter- Call the after-sales service. ▶ rupted. → "Customer Service", Page 36 Different causes are possible. Check any notifications that appear in the display. ▶ → "Displaying information", Page 13 Appliance does not Device is in demo mode.
- Page 35 Setting values, e.g. temperature or cooking time, depend on the recipe, quantity and food. Next time, set lower or higher values. ▶ Tip: A lot of information about the food preparation and corresponding setting values can be found on our website www.siemens-home.bsh-group.com .
-
Page 36: Disposal
en Disposal 26 Disposal Find out here how to dispose of old appliances cor- This appliance is labelled in accord- rectly. ance with European Directive 2012/19/EU concerning used elec- trical and electronic appliances 26.1 Disposing of old appliance (waste electrical and electronic equip- Valuable raw materials can be reused by recycling. - Page 37 How it works en Cooking time range, e.g. 10-15: ATTENTION! ¡ Your food will be ready within the specified range of When the cooking compartment is hot, any water in- time (in minutes). side it will create steam. The change in temperature may cause damage.
- Page 38 en How it works ¡ Place the food to be grilled directly onto the wire ¡ Use open, heat-resistant cookware that is suitable rack. for cooking with steam. ¡ To catch any liquids that drip down, place the uni- ¡ The perforated steam container (size XL) is the best versal pan into the cooking compartment at least option here.
- Page 39 How it works en Food Accessories/cook- Shelf pos- Heating Temperature in Steam in- Cooking time ware ition function °C tensity in mins → Page 8 Fruit pie Plate Ø 20 cm 170–190 60–75 Pie tin Quiche Dark coated 190–210 35–45 quiche tin Bread or white bread Loaf tin, 1 x 900 g 180–200 20–30...
- Page 40 en How it works Food Accessories/cook- Shelf pos- Heating Temperature in Steam in- Cooking time ware ition function °C tensity in mins → Page 8 Complete meal with Wire rack 65 - 75 chicken, 1.5 kg Steam 0 Wire rack when yorkshire pudding is placed in the oven...
- Page 41 How it works en To ensure that the climate in the cooking compart- 28.7 Special cooking methods and other ment remains constant, keep the cooking compart- applications ment door closed during slow cooking. Information and recommended settings for special After slow cooking, remove the meat from the cook- cooking methods and other applications, e.g.
- Page 42 en How it works Always thoroughly rinse and peel fruit and veget- ¡ The quality of the cooking result is 100% influenced ▶ ables. by the quality of the ingredients you use. Use only Always keep work surfaces and chopping boards fresh, top-quality food.
- Page 43 How it works en Use scissors to open the vacuum-sealing bag. Pour Food Cooking tips all the food and liquid out into the container. Fish ¡ Season the fish and coat with hot You can use the stock or marinade to make a butter.
- Page 44 en How it works Food Accessory/cookware Heating Temperat- Cooking Tips for sous-vide cooking function ure in °C time in mins Apples, peeled, in 0.5 cm Wire rack 15–25 Recipe tip: Vacuum-seal slices, x 2–4 along with some caramel Universal pan sauce. The cooking time may vary depending on the type of apple.
- Page 45 How it works en ¡ Place food that you are not reheating in cookware Tips for reheating food (e.g. bread rolls) directly onto the wire rack at ¡ Use uncovered, heat-resistant cookware that is suit- level 2. able for cooking with steam. ¡...
- Page 46 en How it works Food Accessories/cook- Shelf pos- Heating Temperature in Steam intens- Cooking ware ition function °C time in → Page 8 mins Small cakes, on 2 levels Universal pan 25 - 35 Baking tray Small cakes, on 3 levels x 2 5+3+1 35 - 45 Baking tray x 1 Universal pan...
-
Page 47: Installation Instructions
Installation instructions en 29 Installation instructions Observe this information when installing the appliance. 29.1 General installation instructions Follow these instructions before you start with the installation of the appliance. ¡ The safe operation of this appliance can only be guaranteed if it has been installed ¡... - Page 48 en Installation instructions 29.2 Appliance dimensions 29.3 Installation below a worktop You will find the dimensions of the appliance here Observe the installation dimensions and the installation instructions when installing below a worktop. ¡ To ventilate the appliance, the intermediate floor must have a ventilation cut-out. ¡...
- Page 49 Installation instructions en ¡ The power cable must be plugged in at the rear of 29.5 Installation in a tall unit the appliance until you hear a clicking sound. A 3 m Observe the installation dimensions and the installation power cable can be obtained from the after-sales instructions when installing in a tall unit.
- Page 50 en Installation instructions Screw the appliance into place. For handleless kitchens with vertical bar handle strips: Attach a suitable filling piece in order to cover ‒ any sharp edges and to guarantee a safe install- ation. Pre-drill aluminium profiles to establish a screw ‒...
- Page 52 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001620829* 9001620829 (010624)
