KNOW YOUR PRODUCT
PETROL
DEMOLITION
BREAKER
• 2.3HP POWERFUL ENGINE
• 25-55 JOULES
• QUICK RELEASE BIT LOCK
• SOFT GRIP HANDLES
• 30MM HEX FITMENT
INSTRUCTION MANUAL
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
10/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Full Boar FBT-2000
Summary of Contents for Full Boar FBT-2000
- Page 1 KNOW YOUR PRODUCT PETROL DEMOLITION BREAKER • 2.3HP POWERFUL ENGINE • 25-55 JOULES • QUICK RELEASE BIT LOCK • SOFT GRIP HANDLES • 30MM HEX FITMENT INSTRUCTION MANUAL WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
-
Page 2: Specifications
SPECIFICATIONS - MODEL NO. FBT-2000 Motor Type: 2-stroke, 1-cylinder, air cooled Displacement: 52cc Power: 2.3HP Engine Speed: 6500/min Impact Energy: 25-55J Impact Frequency: 700-1500bpm Fuel Mix: 40:1, Unleaded petrol to 2-stroke engine oil Fuel Tank Capacity: 1.7L Spark Plug: TORCH BM6A... -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS............Page 02 KNOW YOUR PRODUCT........... Page 02 INTRODUCTION............Page 04 SAFETY INSTRUCTIONS........... Page 04 ASSEMBLY..............Page 07 PRE-OPERATION CHECK.......... Page 08 OPERATION............... Page 09 MAINTENANCE............Page 12 DESCRIPTION OF SYMBOLS........Page 14 TROUBLE SHOOTING ..........Page 15 CONTENTS.............. -
Page 4: Introduction
INTRODUCTION Congratulations on purchasing a Full Boar Petrol Demolition Breaker. Your Full Boar Petrol Demolition Breaker FBT-2000 has been designed for heavy duty breaking and chipping of concrete, block and masonry products. SAFETY INSTRUCTIONS WARNING! When using this equipment, basic safety precautions, including the following, should always be followed to reduce risk of fire, electric shock, personal injury and material damage. - Page 5 GENERAL SAFETY WARNINGS b. Dress appropriately. Do not wear loose clothing or jewellery. Contain long hair. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. c. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
- Page 6 DEMOLITION BREAKER SAFETY WARNINGS • Wear ear protectors. Exposure to noise can cause hearing loss. • Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury. WARNING! This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 7: Assembly
WARNING! Ensure the tool has been shut off and completely stopped before performing any of the following operations. Removing and Fitting the Chisel The Full Boar FBT-2000 comes with 2 chisel attachments that require fitting before starting the demolition breaker. IMPORTANT! Always lubricate the accessory fitment prior to inserting them into the demolition breaker. -
Page 8: Pre-Operation Check
PRE-OPERATION CHECK Adding Fuel The 2-stroke demolition breaker requires a fuel mix of 40 parts of unleaded petrol (91 Octane) to 1 part 2-stroke engine oil. Ensure you are using the markings on the 40:1 side of the mixing bottle. 1. -
Page 9: Operation
OPERATION Starting the Demolition Breaker 1. Press the priming bulb 10 times to prepare the carbueretor for starting. Fig. 9 2. Close the choke lever by pushing it up towards “ “ . Fig. 10 3. Hold the demolition breaker handle firmly with one hand. - Page 10 OPERATION Adjusting the Speed INCREASE 1. To increase the speed push the throttle lever away with your thumb. 2. To decrease the speed allow the throttle lever to retract. DECREASE Fig. 13 Stopping the Engine 1. Reduce the speed of the engine by allowing the throttle lever to retract.
- Page 11 OPERATION KNOW YOUR PRODUCT Cold Hammering If the demolition hammer is stored for long periods of time or at cold temperatures, the lubrication may become stiff and the demolition hammer may not hammer initially or the hammering may be weak. Should this occur, insert an accessory into the demolition hammer, turn the demolition hammer on and apply the end of the accessory against a scrap piece of concrete or timber.
-
Page 12: Maintenance
MAINTENANCE KNOW YOUR PRODUCT • A fter each use, blow air through the over the demolition breaker to ensure it is free from all dust particles which may build up. Build up of dust particles may cause the demolition breaker to overheat and fail. • I f the enclosure of the demolition breaker requires cleaning, do not use solvents but a moist soft cloth only. Never let any liquid get inside the demolition breaker; never immerse any part of the demolition breaker into a liquid. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the demolition breaker by an unauthorised person or by mishandling of the demolition breaker. - Page 13 MAINTENANCE Spark plug removal, installation and inspection 1. Remove the spark plug lead. 2. Using the supplied spark plug wrench, remove the spark plug. 3. Clean the electrode with a metal brush and remove any carbon build-up. 4. Using a thickness gauge, check for the right gap (0.6-0.8mm) between the centre electrode and side electrode.
-
Page 14: Description Of Symbols
DESCRIPTION OF SYMBOLS Volts Hertz Alternating current Watts Revolutions or No load speed reciprocation per minute Diameter Regulator compliance mark Double insulated Warning Wear ear, eye and Read operation instruction breathing protection Do not smoke Hot surface Two stroke engine oil Unleaded Petrol Toxic Fumes Keep bystanders away... -
Page 15: Troubleshooting
TROUBLESHOOTING Symptom Solution Accessory is falling out Ensure that the accessory locking bolt has been rotated to the correct position. Engine starts but the The chisel needs to be pushed down for the demolition breaker does not demolition breaker to start operating. operate. -
Page 16: Contents
CARING FOR THE ENVIRONMENT Power tools that are no longer usable should not be disposed of with household waste but in an environmentally friendly way. Please recycle where facilities exist. Check with your local council authority for recycling advice. Recycling packaging reduces the need for landfill and raw materials. -
Page 18: Warranty
WARRANTY YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations) WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE: Australia 1800 069 486 New Zealand 0508 069 486...
