KNOW YOUR PRODUCT
DEMOLITION
HAMMER KIT
• 1500W MOTOR
• 32 JOULES
• ANTI-VIBRATION
HANDLE
ORIGINAL INSTRUCTIONS
WARNING: Read all safety warnings and instructions before use. Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury. Save these instructions for future reference.
09/16
Advertisement
Table of Contents
Related Manuals for Full Boar FBT-1100U
Summary of Contents for Full Boar FBT-1100U
- Page 1 KNOW YOUR PRODUCT DEMOLITION HAMMER KIT • 1500W MOTOR • 32 JOULES • ANTI-VIBRATION HANDLE ORIGINAL INSTRUCTIONS WARNING: Read all safety warnings and instructions before use. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
SPECIFICATIONS - MODEL NO. FBT-1100U TABLE OF CONTENTS Power: 1500W SPECIFICATIONS............Page 02 Input: 230-240V ~ 50Hz Impact Energy: KNOW YOUR PRODUCT........... Page 02 Impact Frequency: 1900/min Breaking Capacity: 38mm INTRODUCTION............Page 04 Accessory Fitment: SDS Max Weight: 10.8kg SAFETY INSTRUCTIONS........... Page 04 ASSEMBLY.............. -
Page 3: Introduction
GENERAL SAFETY INSTRUCTIONS WARNING! Read all safety warnings and instructions before use. Failure to follow the Congratulations on purchasing your Full Boar demolition warnings and instructions may result in electric shock, fire and/or serious injury. Save this instruction manual for future reference. The term “power tool” in the warnings refers hammer kit. -
Page 4: Assembly
GENERAL SAFETY INSTRUCTIONS ASSEMBLY WARNING! Ensure the tool has been switched off and completely stopped before d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with performing any of the following operations. the power tool or these instructions to operate the power tool. -
Page 5: Controls
WARNING! Keep away from cigarettes, smoke and sparks when refuelling the Removing and Fitting the Chisel demolition hammer. Always refuel in a well-ventilated location. The Full Boar FBT-1100U comes with 2 chisel attachments that require fitting before starting the demolition hammer. On / Off Trigger IMPORTANT! Always lubricate the accessory fitment prior to inserting them into Fig. -
Page 6: Operation
CONTROLS MAINTENANCE KNOW YOUR PRODUCT Rotating the Chisel • Keep the ventilation vents of the demolition hammer clean at all times. 1. Push and hold the accessory rotation lock towards the • After each use, blow air through the demolition hammer housing to ensure it is free accessory to unlock the rotation. -
Page 7: Description Of Symbols
DESCRIPTION OF SYMBOLS CONTENTS 1 x Demolition Hammer Volts Hertz 1 x Pointed Chisel Alternating current Watts 1 x Flat Chisel 1 x Kit Box Revolutions or /min No load speed reciprocation per minute Millimetres Diameter Double insulated Read instruction manual Warning Wear eye protection Wear ear protection... -
Page 8: Warranty
WARRANTY All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device develops a fault, please contact our service department at the address shown on this guarantee card. You can also contact us by telephone using the customer service number shown.
