1. Features
-
-
High performance filters for modern hydraulic systems
_
Modular system
Compact design
Minimal pressure drop through optimal flow design
Visual/electrical/electronic maintenance indicator
Threaded connections
Vacuum gauge serial production
Quality filters, easy to service
Quick-lock design and shut off valve
Equipped with highly efficient glass fibre Sm-x filter elements
Beta rated elements according to ISO 16889 multipass test
Elements with high differential pressure stability and dirt holding
capacity
NPT- and SAE-connections on request
Worldwide distribution
Suction Filter
Pi 160
Advertisement
Table of Contents
Related Manuals for MAHLE Pi 1607 Series
Summary of Contents for MAHLE Pi 1607 Series
- Page 1 Suction Filter Pi 160 1. Features High performance filters for modern hydraulic systems Modular system Compact design Minimal pressure drop through optimal flow design Visual/electrical/electronic maintenance indicator Threaded connections Vacuum gauge serial production Quality filters, easy to service Quick-lock design and shut off valve Equipped with highly efficient glass fibre Sm-x filter elements Beta rated elements according to ISO 16889 multipass test Elements with high differential pressure stability and dirt holding...
- Page 2 2. Flow rate/pressure drop curve complete filter y = differential pressure ∆p [bar] x = flow rate V [l/min] 3. Symbols Suction Filter Pi 160 up to NG 315...
- Page 3 4. Order numbers Example for ordering filters: 1. Housing design 2. Filter element V=100 l/min, pressure gauge, Sm-x 25 Type: Pi 1615-366 Type: 852 754 Sm-x 25 Order number: 77774813 Order number: 77730195 4.1 Housing design Nominal size* with with NG [l/min] Order with...
- Page 4 5. Technical specifications Design: suction filter with shut off valve Installation: horizontally under oil level or vertically above oil level with optional extension pipe Temperature range: -10 °C to +120 °C (other temperature ranges on request) Filter head material: GDAL Filter housing material: Sealing material: NBR/AL...
- Page 5 Please always ensure 4 . Dry element with pressured-air from the clean side to the dirt that you have original MAHLE spare elements in stock: Disposable side; the cleaning efficiency is about 60–70% elements (Mic or Sm-x) cannot be cleaned.
- Page 6 78308892 Pressure gauge (-1 to 1.5 bar) 77548027 Seal kit for filter housing + filter element 77874563 77904840 EPDM 77904857 MAHLE Filtersysteme GmbH Industriefiltration Schleifbachweg 45 D-74613 Öhringen Phone +49 (0) 7941/67-0 Fax +49 (0) 7941/67-23429 industriefiltration@mahle.com www.mahle-industrialfiltration.com 78356396.03/2008 Suction Filter Pi 160 up to NG 315...
