- Page 1 Owner’s Manual VV2-151 *VV2-271 *VV2-361 * Indicates Item is available by special order only.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS - PLEASE READ ENTIRE MANUAL PRIOR TO USE The Vericom RAV series is designed to support audio/video equipment. The total weight capacity for the Vericom VV2 series: VV2-151 500 lbs VV2-271 750 lbs VV2-361 850 lbs Each 3U shelf supports up to 80 lbs, each 2U shelf supports up to 50 lbs, and each 1U shelf supports up to 30 lbs.
- Page 4 Supplied Parts and Hardware [G] KEY X 2 [D] LEVELER X 4 [B] CASTER X 4 [C] M5X10 SCREW X 16 [A] CABINET X 1 [F] STRAP- 1 Per Shelf [E] BACKSTOP- 1 Per Shelf VV2-151 VV2-151 VV2-271 VV2-271 VV2-361 VV2-361...
- Page 5 Install Levelers and Casters NOTE: Install the levelers completely in. Adjust Levelers Adjust the levelers [D] to level the rack. Tighten nuts [N] until they are flush with the bottom of the rack. CAUTION: To avoid potential injury or property damage, always ensure that your rack is level...
- Page 6 Adjust Rack Rails Remove the shelves and blanking panels before adjusting the rails. Adjust the right and left rails evenly. NOTE: For Clarity, the front door, top and side panels are not shown.
- Page 7 Adjust Shelves and Blanking Panels NOTE: Align the bottom of the shelf or blanking panel with the lines on the rack rail. Blanking Panel Line Line Blanking Panel...
- Page 8 Verify the Ground Wire has been Installed If the ground wire has not been installed, install the wire now by attaching one end to the door ground stud, and the other end of the ground wire to the ground stud on the bottom of the rail.
- Page 9 Load Your Components CAUTION: To prevent tipping, always load the rack from the bottom up, and load the heaviest items in the rack first. 50% of the total weight should be mounted in the lower 1/3 of the rack. Rack Shelf Backstops Note: Rear view with back panels removed.
- Page 10 Remove Cable Access Panels for Cable Management...
- Page 11 Manage Cables Adjust location of tie bars. Use tie bars to bundle cables and wires. Tie Bar...
- Page 12 Switch Back Panels To switch the position of the back panels: 1. Remove large upper panel. 2. Remove small lower panel and frame. 3. Fit bottom of large panel into rack frame and angle the panel up until sliding locks snap into place.
- Page 13 Reverse the Front Door Remove the door: 1. Remove the door grounding wire from bottom of rack and the door. 2. Turn upper door pin to release from locking tab and pull down to release door from rack. Lift door from rack frame. 3.
- Page 14 Reverse the Front Door- Continued Flip the door: 5. Rotate the door 180° 6. Fit spacer onto bottom pin and fit bottom pin into bottom mounting hole in rack. 7. Turn upper pin to release from locking tab and pull down. Fit pin into upper mounting hole in rack.
- Page 15 Reverse the Front Door- continued Flip the door handle: Flip the door handle. Remove screws and bracket. Reattach screws and bracket. Loosen the locking cam screw. Flip the locking cam tab to the Tighten the locking cam screw. side nearest the edge of the door.
- Page 16 Install Fan for Additional Ventilation CAUTION: Avoid damage to your components due to overheating. Make sure that there is adequate space between each unit for proper airflow. Operating temperature inside the rack must not exceed 104°F (40°C). To install fan: Remove the vented panel.
- Page 17 Add Keyed Lock to Door Remove plug from side panel. Install keyed lock (purchased seperately) in plug hole.
- Page 18 Ganging Racks Remove side panels on sides Move racks together until sides to be connected. are touching. IMPORTANT Make sure both racks are level with each other. Fit 4 ganging clips into frame slots. Press down on clips to secure. IMPORTANT Make sure all 4 ganging clips are fully engaged.
