- Page 1 INbob003V03_GL 840-174_840-175 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
- Page 4 13-1 13-2 17-1 17-2...
- Page 6 Step 1: Roller assembly Keep the rollers aligned, assemble the roller with the connectors and secure it with the corresponding bolts as figure below: Step 2: Torsion bar and arm assembly: keep the four face aligned , connect the torsion bar with the connectors and secure it with the corresponding bolts as figure below: Then assembly the arm to the torsion bar as figure below.Two arms need in the same direction, the rope of arm cannot be unlocked until the whole assembly are...
- Page 7 Step3: Front bar assembly Connect the front bar with connectors and secure it with the corresponding bolts as figure below:.(please keep the front bar aligned). Step4:Front bar wrist support assembly: Slide the front bar feet into the front bar without tightening.As shown in the figure below:...
- Page 8 Step 5: Arms with front bar assembly: Put front bar feet bolt through the hole of small arm, then position the front bar. After positioning, tighten the nut with wrench, as fgure below: Step 6: Link the self-locking nut Link the self-locking nut into screw which at the bottom of the screw in front bar feet by a wrench, stop when the thread:leakage 1 ~ 2 laps.As shown in the figure below: ATTENTION: BEFORE BLOCKING THE NUT.ENSURE THAT THE ARMS ARE PROPERLY ALIGNED.
- Page 9 Step7: Left roller support with gear box assembly: Hammer the left roller support with gear box into the left end of torsion bar by wood hammer, then tighten the left hexagon bolt by 5mm. As shown in the figure below: Step 8: Fabric and valance assembly: Open the fabric bag, Spread out both fabric 14A and valance 14B and use the cloth guiding wire to line through the fabric.As shown in the figure below:...
- Page 10 Step 9: Roll in the fabric on the roller Roll in the fabric on the roller, pay attention to the fabric direction needed, as shown in the figure below: Please face up the fabric when assembling.Keep the same spacing X at both ends. Spread the fabric slowly in case of damage.
- Page 11 Step 11: Right roller support assembly: Insert the shaft of roller into roll tube plug，meanwhile insert the torsion bar into the right roller supports with hitting. Then tighten the right hexagon bolt by 5mm Hexagon wrench.As shown in the figure below: Step 12: Assemble to make a whole awning Make the valance through groove of front bar, pay attention to the direction and make sure the left and right sides on average, then hitting the cover of front bar into...
- Page 12 8'-13' 3pcs 3pcs 6pcs 6pcs...
- Page 13 8"(20.5cm) 8-13 '(2.5-4m).
- Page 14 < 10.8'(3.5m) 10.8-14'(3.5-4m) ≥3.9"(10cm) ≥3.9"(10cm)
- Page 15 3.15"(8cm) “ 0.55"(14mm)
- Page 16 0.75"(19mm)
