- Page 1 Installation manual Trichogramma Pack M300 Manual_Pack-M300_en_V1...
- Page 2 Summary : 1. Introduction ________________________________________________ p3 2. Assembly___________________________________________________ p4 3. Setup______________________________________________________ p8 Manual_Pack-M300_en_V1...
- Page 3 Introduction : The trichogramma pack for DJI Matrice 300 is composed of the following elements: - The Trichogramma system T-Drop and its 8 liter tank - The T-Box System - The supports of fixations necessary for its installation - A raised landing gear This manual is intended for the assembly of the pack, For the use of the spreader and the autonomous system please refer to their manual: - T-Drop Manual...
- Page 4 Assembly : 1) Assembling the lower attachment point on the T-Drop: Remove the two M3x6 FHC screws under the screen and replace them with the two M3x10 BHC screws provided to secure the carbon plate of the bottom bracket. Manual_Pack-M300_en_V1...
- Page 5 2) T-Box assembly and top mount on the T-Drop : Use the 4 supplied M3x15 CHC screws to mount the T-Box to the spreader tray by sandwiching the carbon plate of the bracket. (The antennas must be opposite to the screen) Fix with the 4 supplied M3 nuts from the inside of the tank.
- Page 6 3) Cable attachment : Attach the cable to the bracket using the supplied cable tie. Do not run the cable over the GPS Then check that the cable cannot pass through the propeller. Manual_Pack-M300_en_V1...
- Page 7 4) Assembly on the M300: For more ease, the assembly is done with the M300 upside down as for the DJI payload. - Slide the spreader between the two legs until it rests on the stops. - Clip the bottom bracket onto the tube.
- Page 8 Setup : To work with the T-Box, your T-Drop spreader must follow this configuration: ARM : off DROP mode : I/0 This manual is intended for the assembly of the pack, For the use of the spreader and the autonomous system please refer to their manual: - T-Drop Manual - T-Box Manual...
