INSTALLATION AND SERVICE MANUAL
For Installation of Large Arizona 2 light column dia 225mm LED.
Model. AR-20973 and AR-20974
Product drawing (dimensions)
IP65 CLASS I IK08
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-1 standard.
Technical amendments and modifications techniques reserved.
L i g m a n L i g h t i n g
Europe Headquarters
Ligman Europe s.r.o.
VGP Park Usti nad Labem, P 2
Prestanov 113
403 17 Prestanov
Czech Republic
Tel. +420 608 740 504
sales.cz@ligman.com
|
www.ligman.com
4
2,3
TOOL
6
CABLE SIZE : 3x1.0mm
Torque :0.25Nm.
5
Torque : 3.0 Nm.
Thailand Headquarters
Ligman Lighting Co., Ltd.
17/2 Moo 4, Monthong, Bangnampreaw
Chachoengsao 24150 Thailand
Tel : +66 (2) 7339140
info@ligman.com
M AR-20973/16/03/18/EV.2
1/2
1
3
20 30
²
N
L
6
Torque : 3.0 Nm.
2
4
Torque :2.0Nm.
7
Ligman Ltd
Regus House, Victory Way
Crossways Business Park
Dartford DA2 6QD
Tel. 0800 975 0622
sales.uk@ligman.com
FM-TS-13-1/13-03-2561/REV.4
