USB-2504 USB Extender User Manual
Thanks for buying our products! In order to make sure you
use this product correctly, please read the instruction clearly
before installation.
Product Introduction:
This product includes a sender and a receiver, which can
extend USB interface of computer max up to 50 meters by
single cat5e, and receiver support 4-port USB hub.
The product can be widely used in computer, education,
bank, and industry systems.
Product Specification:
L x W x H
Net weight
Extension distance
Cable type
USB standard
Interface
OS support
Power
Driver
Sender power consumption
Receiver power consumption
Sender: 79 mm X 64mm X 25mm
Receiver: 79 mm X 64mm X 25mm
0.2kg
0-50meters
CAT5E, CAT6 UTP, STP cable
Support USB2.0 protocol
USB A, USB B, RJ45
Windows, Linux, Unix etc.
Sender is powered by PC USB,
receiver is with external DC5V 1A
power adaptor
No need driver
5V 100mA
5V 400mA
Advertisement
Related Manuals for Linetek USB-2504
Summary of Contents for Linetek USB-2504
- Page 1 USB-2504 USB Extender User Manual Thanks for buying our products! In order to make sure you use this product correctly, please read the instruction clearly before installation. Product Introduction: This product includes a sender and a receiver, which can extend USB interface of computer max up to 50 meters by single cat5e, and receiver support 4-port USB hub.
- Page 2 Packaging: When you open the packing, you will find: 1. Sender 1pcs 2. Receiver 1pcs 3. DC5V 1A power adaptor 1pcs 4. USB data cable 1pcs 5. User manual Installation: Connection diagram: Installation steps: 1. Prepare T568B standard cat5e cable with cable sequence of Orange-white(1),Orange(2),green-white(3),blue(4),blue-white (5)green(6),brown-white(7),brown(8).
- Page 3 Indicator Instruction: The red LED indicator on sender and receiver is for power supply. Device Indicotr Color Status Remark PC & sender connects well, Keep Green sender ready lighting Sender POWER exchange data with receiver The sender is exchanging Green blinks data with receiver normally Receiver gets power from...
- Page 4 Repair and after sale service: 1. Promises: *One year guarantee for free repair starting purchase date *Provide lifetime repair service, but will charge proper labor and material cost. *Problems caused by man-made reasons, dismantle devices are not included in one year free repair guarantee. 2.
