- Page 1 Application Note How to use the TOMBAK as a voltage level converter (SYNC Mode) Multiboard Series TOMBAK : Synchronization electronic board...
- Page 2 How to use the TOMBAK as a Voltage Level Converter (SYNC Mode) Pre-requirement: Before using the TOMBAK board, make sure you followed all the instructions mentioned in the Operating Manual 1. Presentation The board can be used as a voltage level converter in every mode that used the Pulse_In signal as a reference signal.
- Page 3 Output signal Input signal 5. Software configuration Launch the ALPhANOV Control Software and click on Connect to start the TOMBAK hardware detection. The software automatically detects the TOMBAK board. A window will appear for each TOMBAK connected to the computer.
- Page 4 The main configuration windows must be configured as follow : • Working Mode window : o Set the Board On o Set the Shaper button to Off o Set the Inverse button to Off unless you need to invert the output signal o Set Advanced Mode to Sync Page 4/6 –...
- Page 5 • Input pulse window : o Configure the Threshold voltage so that the input pulse frequency is detected and the same as your pulse generator system o Set the Division factor to 1 o Set the input pulse Source to Direct •...
- Page 6 6. Main features Input PulseIn voltage (software adjustable 30 mV – 3,3V threshold) Input/output maximum frequency 150 MHz Minimum insertion delay (fine delay deactivated) 12 ns (see fig 2) Minimum insertion delay (0-10ns fine delay) 15 ns (see fig 2) 1 / 3,3 / 5 Volts (hardware setup –...
