Espresso Coffee Machine
Model : i-Creo

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i-Creo and is the answer not in the manual?

Questions and answers

Related Manuals for Dong Gu Co i-Creo

Summary of Contents for Dong Gu Co i-Creo

  • Page 1 Espresso Coffee Machine Model : i-Creo...

  • Page 2: Table Of Contents

    Table of Contents 1. Table of Contents ..................1 2. Components & Accessories ................2 3. Safety Precautions ..................3 4. Installation and Operation 4-1. Installation Conditions ................5 4-2. Installing/Removing the Bean Canister ............. 6 4-3. Filling the Bean Canister .................

  • Page 3: Components & Accessories

    Components Bean Canister Safety cap Front panel Pressure meter Coffee nozzle Bean residue box Tray Grill Accessories Spare fuse Manual Bean Canister Bean Container Box driver (2 ea) Fixing Lever (2 ea) Drain hose Hose band O-ring Cleaning brush (1 ea) (1 ea) (1 ea)

  • Page 4: Safety Precautions

    Safety Precautions This coffee machine is used for making espresso out of coffee beans. Keep this manual close to the product and make it easily accessible to anyone who wants to use it. If you need information other than what this manual provides, or if there is a problem that cannot be solved by the solution provided, please contact our service center.
  • Page 5 The conditions described below will void the product warranty, and Donggu Electronics assumes no liability for product defects caused by the following: Caution * Defects caused by improper use (caused by ignoring the instructions) * Problems caused by repairs performed by parties other than our authorized service centers * Problems caused by unauthorized change of the power cord * Problems caused by unauthorized modification or alternation of part of the product...

  • Page 6: Installation And Operation

    Installation and Operation * This coffee machine must be installed and operated for the first time by a service technician authorized by the manufacturer. * Be sure to use a direct supply of water system with a water filter. (Use the 1/4" water purifier hose to connect to the product.) At least 25 cm * Please connect the power cord to a dedicated power outlet.

  • Page 7: Installing/Removing The Bean Canister

    Installing/Removing the Bean Canister [Installing the Bean Container] Bean Canister Bean Canister Bean Canister Fixing Lever Fixing Lever Bean Canister Fixing Lever * Insert the ① bean Canister fixing levers in the left and right directions as shown in the picture and push them in completely.

  • Page 8: Adjusting The Grind Level

    Installation and Operation Adjusting the Grind Level * The default grind level of this product is set to fine grind. Left grinder Right grinder Front panel Finer Finer Safety cap Coarser Coarser Box driver Bean residue * Adjust the size of the grind by using the box screwdriver provided with the product.

  • Page 9: Lifting The Front Panel

    Lifting the Front Panel Door Snap Door Snap Lift the coffee nozzle Press until the protruding door Lift the front panel. handle completely and snaps (L/R) inward. pull out the tray. ※ Refer to the image in the Cleaning item on Rinsing the Brewer the left side of the Administrator Mode screen.

  • Page 10: Cleaning The Coffee Nozzle

    Installation and Operation to form a lump that can cause clogging. place it back to the product. Cleaning the coffee nozzle Press both sides of the coffee nozzle to Remove the lower part of the nozzle as shown remove the lower part of the nozzle. in the figure, wash it clean, and assemble it back to the coffee nozzle.

  • Page 11: Start Screen

    Start screen * When the coffee machine is connected to the power source, it turns on and starts the initial booting process (Android). * Click the power icon to switch to the product initialization step. * Reinforced glass is used for the control panel.

  • Page 12: Single Sale

    Installation and Operation Single Sale * Single Sale is used to process single sale of the tapped drink menu only. Menu * Place the cup under the coffee nozzle * and tap the icon of the desired drink to start extracting the selected drink. Menu * The name of the selected drink and extraction process are shown in order on the screen.

  • Page 13: Multi-Sale

    Multi-Sale * Multi-Sale is used to process continuous multiple sales of several drink menus, and up to 10 cups can be selected. * When selected, the selected Menu drink is added to the column on the left side, and the number of cups will be shown on the screen.

  • Page 14: Administrator Mode

    Administrator Mode Entering Administrator Mode * Enter Administrator mode by tapping the icon on the upper right corner of the standby screen. Menu * The initial password is set to "1111" when the product is shipped. * Enter the password and tap OK to enter Administrator mode.

  • Page 15: Administrator Mode Screen

    Administrator Mode Screen * The following screen appears if you enter Administrator mode: ADMINISTRATOR SALES SALES MENU SYSTEM CONFIGURATION MANAGEMENT MANAGEMENT SETTING ERROR LOAD MACHINE INFORMATION INFORMATION TEST SETTING * Tap the icon of the mode you wish to check or configure the settings for to enter the mode.

  • Page 16: Sales Management

    Administrator Mode Sales Configuration Settings [Multi-Sale] * For more details on SALES CONFIGURATION how to use Multi-Sale, see the Multi-Sale page. Singular Sales Free of charge Test Sales Continuously Sales * Tap the < icon on the upper left corner to return to Administrator mode. * Free of charge: Runs a normal sales operation (No Beans state will be detected) * Test Sales: Runs a test for sales operation (No Beans state will not be detected) * Auto mode...

  • Page 17: Menu Management

    MENU MANAGEMENT * You can manage menus by changing the order of drinks, set the recipe, register and set a new menu, etc. in this mode. * Scroll up/down the MENU MANAGEMENT screen in the drink column on the right to navigate the screen.
  • Page 18 Administrator Mode * You can scroll MENU MANAGEMENT up/down the screen MicroSetting to move between the recipe settings items. PRODUCT TYPE COUNTED PRODUCT SELECT GRINDER COFFEE QUANTITY WATER QUANTITY PRE-INFUSE DELAY PRE-INFUSE INITIAL PRESSURE BYPASS SEQUENCE BYPASS WATER * Tap the icon on the upper right corner to return to Administrator mode without saving the changes.
  • Page 19 [Change Drink Image/Name] * Tap an image among the drink images in the column on the right to update the image of the drink. * Tap the name of the drink on the left to go to the keyboard screen. You can add numbers, English letters, icons, etc.

  • Page 20: System Setting

    Administrator Mode SYSTEM SETTING * Tap the < icon on the SYSTEM SETTING upper right corner to return to Administrator Password mode without saving the changes. Time Language Wallpaper [Password] * Tap four digits followed by OK to reset the password. * If a wrong number is tapped by mistake, tap DEL to delete the last entered one.
  • Page 21 [Language Settings] * Tap the Language item on the right to go to the settings screen. * Tap the < icon on the SYSTEM SETTING upper right corner to return to Administrator Password mode without saving the 한국어(Korean) changes. Time Language Wallpaper * Select a language and tap the <...

  • Page 22: Error Information

    Administrator Mode ERROR INFORMATION ERROR INFORMATION Date Report Brewer Error Brewer Error Bypass Error * Tap the < icon on the upper right corner to return to administrator mode. * The date and details of errors that occurred will be shown on the screen. * Tap the <...
  • Page 23 [LOAD TEST] LOAD TEST * Tap the ▷ icon to start the load test. * During the load test, tap the icon to cancel (stop) the test. * When testing is complete, tap the < icon on the upper right corner to return to administrator mode.

  • Page 24: Machine Setting

    Administrator Mode MACHINE SETTING MACHINE SETTING MACHINE ON/OFF Energy Saving Cake Count Rinsing Temperature System power-off after rinsing * Tap the < icon on the upper right corner to return to administrator mode. [Energy saving] * This feature is used to set the time for turning on/off automatically daily or on a set day of the week. * Tap the day of the week to turn on the feature.
  • Page 25 [Rinsing Frequency] * This feature is used to set the frequency for the automatic rinsing of the brewer while the product is turned on. MACHINE SETTING Energy Saving Cake Count Rinsing Rinsing Temperature * Tap the < icon on the upper right corner to return to administrator mode. * Scroll down/up the number part to set the frequency.

  • Page 26: Information

    Administrator Mode INFORMATION INFORMATION PRODUCT S/N USER INFO LCD S/N SLAVE BOARD VERSION LCD APP VERSION FIRMWARE VERSION * Tap the < icon on the upper right corner to return to administrator mode. * The version and specifications of the control parts/circuits of the product are displayed, and the version information will be updated automatically when updating the product.
  • Page 27 Dong Gu Electronics Co., Ltd 6, Dunchon-daero 497beon-gil, Jungwon-gu, Sungnam-si, Gyeonggi-do, Korea Tel. 82-31-731-3600 ext. 731~733 Fax. 82-31-733-1155 Web site. http://www.venusta.co.kr...
