Cycling Bearing Tool
Operation Manual
SRC-TT-B006D
Taiwan Utility Model Patent No. M407311 / M457655
Japan Utility Model Patent No. 3174226 / 3183510
PROC Utility Model Patent No. ZL201120553594.0/ ZL201320080197.5
Australian Utility Model Patent No.2013100311
Global Patent Pending
www.cemabearing.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRC-TT-B006D and is the answer not in the manual?

Questions and answers

Summary of Contents for Gema SRC-TT-B006D

  • Page 1 Cycling Bearing Tool Operation Manual SRC-TT-B006D Taiwan Utility Model Patent No. M407311 / M457655 Japan Utility Model Patent No. 3174226 / 3183510 PROC Utility Model Patent No. ZL201120553594.0/ ZL201320080197.5 Australian Utility Model Patent No.2013100311 Global Patent Pending www.cemabearing.com...
  • Page 2: Product Feature

    SRC-TT-B006D Operation Manual Product Feature ⚫ It can replace External BB Bearings / Press Fit Bearings and cups on bike frame directly and easily. ⚫ It is recommended for Cycling Shop or Repair Center using. Function Compatible To The Following Bottom Bracket Systems ●...
  • Page 3: Parts List

    Parts List Item Picture Parts List CEMA No. Extractor Tube SRC-TT-B006D-03 Adapter 22mm x 24 mm SRC-TT-B006D-04 22mm x 30 mm SRC-TT-B006D-05 25mm x 30 mm SRC-TT-B006D-06 Bearing Removal Ring SRC-TT-B006D-08 24mm Bearing Removal Ring SRC-TT-B006D-09 30mm Bearing Removal Ring...
  • Page 4: Operation

    Operation: ⚫ Shimano External BB and Press Fit Bearing Replacement Step 1. Remove dust cap. Step 2. Place bearing removal ring (OD24mm,PN: SRC-TT-B006C-08) on extractor tube, then put through the frame. Step 3. Insert thread screw and fit bearing cup. Tighten screw to remove bearing. Step 4.
  • Page 5 ⚫ Shimano PF BB(86/92) Bearing Replacement Step 1. Remove dust cap. Step 2. Place bearing removal ring (OD24mm, PN: SRC-TT-B006C-08) on extractor tube, then put through the frame. Step 3. Fit bearing cup, tighten screw to remove bearing, remove another one with the same way.
  • Page 6 ⚫ Shimano PF BB Set Replacement Step 1. Place BB set onto adapter(OD24mm), and external bearing cup(OD24mm). Step 2. Place both side tightly to the frame, and tighten the screw to install the bearing set into the frame. Step 3. Place the removal ring (24mm, PN:SRC-TT-B006C-08) onto the extractor tube and insert into BB.
  • Page 7 ⚫ SRAM External BB Bearing Replacement Step 1. Remove dust cap. Insert the extractor tube through the Non Drive side bearing, lock the external cup, and tighten the screw to remove the bearing. Step 2. Place the removal ring(24mm PN: SRC-TT-B006C-08,) then insert the extractor tube through the Drive side bearing, lock the external cup, and tighten the screw to remove the bearing.
  • Page 8 ⚫ SRAM PF BB Bearing Replacement Step 1. Remove dust cap. Insert the extractor tube through the Non Drive side bearing, lock the external cup, and tighten the screw to remove the bearing. Step 2. Place the removal ring(24mm, PN: SRC-TT-B006C-08) then insert the extractor tube through the Drive side bearing, lock the external cup, and tighten the screw to remove the bearing.
  • Page 9 ⚫ SRAM PF BB Set Replacement Step 1. Place BB set onto adapter(OD22mm), and external bearing cup(OD24mm). Step 2. Place both side tightly to the frame, and tighten the screw to install the bearing set into the frame. Step 3. Remove the bearings from the frame, and insert the extractor with the removal ring(30mm) into frame.
  • Page 10 ⚫ BB30/PF30/PF386 Bearing Replacement Step 1. Remove dust cap. Insert the extractor tube with the removal ring (30mm, PN: SRC-TT-B006C-09) through the frame to the bearing, insert the screw through the tube to fit the cup. Step 2. Tighten the screw to remove the bearing, repeat process for the other one. Step 3.
  • Page 11 ⚫ PF30/PF386 BB Set Replacement Step 1. Place BB set onto adapter(30mm). Step 2. Place both side tightly to the frame, fit the external bearing cup and tighten the screw to install the bearing set into the frame. Step 3. Place the removal ring (30mm) onto the extractor tube and insert into BB. Step 4.
  • Page 12 ⚫ PF30 Adapter Set Replacement Step 1. Place BB set onto adapter (24mm), and external bearing cup(OD24mm). Step 2. Place both side tightly to the frame, and tighten the screw to install the bearing set into the frame. Step 3. Insert the extractor tube with the removal ring (30mm, PN: SRC-TT-B006C-09) through the frame to the bearing.
  • Page 13 ⚫ InterLock BB Installation Step 1. Press one side of the bottom bracket into the bracket shell, and then insert the other half into the bracket shell. Step 2. Insert the bottom bracket adapter (SRC-TT-B014/B015) and tighten the thread screw. Step 3.
  • Page 14 ⚫ InterLock BB Removal Step 1. Insert the bottom bracket adapter (TT-B014/B015), and then remove one side of the bottom bracket. Adapter Tool → PN: SRC-TT-B014, for BSA24mm Spindle PN: SRC-TT-B015, for 30mm Spindle,BB386,BB38624,PF30 Step 2. Insert the thread screw into the external bearing cup. Place the spacer between the external bearing cup and bottom bracket.
  • Page 15 ⚫ InterLock Bearing Removal Step 1. Remove the dust cap. Insert the extractor tube through bottom bracket and install the correct size of the removal ring. Bearing ID: 24~25mm→use 24mm removal ring, PN: SRC-TT-B006C-08 Bearing ID: 30mm→use 30mm removal ring, PN: SRC-TT-B006C-09 Step 2.
  • Page 16 ⚫ InterLock Bearing Replacement Step 1. Place the new bearing onto the correct size of adapter. Step 2. Insert the screw to the new bearing with the adapter then insert it through the bottom bracket. Install the bearing cup on the other side of the screw. Step 3.
  • Page 17 ⚫ InterLock Hand Adapter Removal Step 1. Select the Gasket (PN:SRC-TT-B006C-07). And insert the thread screw with Gasket through the frame to the hand adapter. Step 2. Insert the thread screw into the spacer (BB86/PF30/386) and the external bearing cup. Then lock the external bearing cup. Step 3.
  • Page 18 ⚫ BSA386/ITA386 BEARING Replacement Step 1. Prepare SRC-TT-B006D-16/SRC-TT-B006D-13(Gasket)/SRC-TT-B006-14(Screw) Step 2. Insert SRC-TT-B006D-13(gasket) with SRC-TT-B006-14(screw) through BB Step 3. Use SRC-TT-B006D-16 and fasten SRC-TT-B006-14(screw) with Allen key Step 4. Rotate with gasket and screw to remove the BB - 17 -...
  • Page 19 Step 1. SRC-TT-B006D-16 3 in 1 cup for M10+Shimano BB+ FSA 30 BB 2. SRC-TT-B006D-17 3 in 1 cup for 3/4 square hole+ Shimano BB + FSA 30 BB Step 2. Use wrench to press in from one side and screw in the other side slowly Step 3.
  • Page 20 BOTTOM BRACKET REPLACEMENT TOOL B006 Removal and Installation of BB30/BB86/ BB386/PF30/BB90 BEARING PULLER B004 Removal of wheel bearings HUB BEARING PRESS B008 Installation of wheel bearings TAIWAN Head Office 6F-1, No.8, Taiyuan 1 St., Zhubei City, Hsinchu County, Taiwan TEL: 886-3-5601270 FAX: 886-3-5601290 service@cemabearing.com Edit 2021...
