SUMAKE
Specification:
Capacity
Punch Hole
Punch Stroke
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
Air Punch & Flange
ST-6652DA
1.2 mm
Dia. 8 mm
4mm
10" (250 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.53 lbs (1.15 kg)
Noise and Vibration:
Vibration
EN ISO 20643
Sound Pressure Level
No Load:
3.97 m/s²
Sound power level
Uncertainty
²
K= 1.5 m/s
Noise
Remark
EN ISO 15744
Please always
load: 70.6 dB(A)
wear ear
protector at
environment
noise level >
load: 81.6 dB(A)
80 dB(A) due
to risk of
impaired
Uncertainty
hearing!
K= 3dB
ST-6652DA-S-2010C-D5F
Advertisement
Related Manuals for Sumake ST-6652DA
Summary of Contents for Sumake ST-6652DA
- Page 1 80 dB(A) due Air Hose (I.D.) to risk of Air Pressure 90 psi (6.3 bar) impaired Uncertainty Uncertainty hearing! ² K= 1.5 m/s K= 3dB Net Weight 2.53 lbs (1.15 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-6652DA-S-2010C-D5F...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AIR PUNCH & FLANGE Model/ Serial No.：ST-6652DA to which this declaration applies, complies with these normative documents: Machinery Directive: 2006/42/EC ...
- Page 3 There is no user serviceable part inside this tool. mechanism, and may cause trouble. So, install an air Sumake is a manufacturer and exporter of air tools Please send the tool to a qualified personnel or our filter and on oiler between the compressor and the since established.
- Page 4 ST-6652D, ST-6652DA, ST-6652DS AIR PUNCH & FLANGE PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 6652D-01 Set Screw (M6x6) 6652D-17 O-Ring 6652D-03 Clamp [ST-6652D, ST-6652DS] 6652D-18 Support Ring 6652DA-03 Clamp [ST-6652DA] 6652D-19 Piston 6652D-04 Punch Die [ST-6652D] 6652D-20 O-Ring (ID7.8x1.9)
