Summary of Contents for Carnival King 382RBD3G1
- Page 1 User Manual Refrigerated Beverage Dispensers 3 Gallon Bowl: #382RBD3G1 #382RBD3G2 #382RBD3G3 5 Gallon Bowl: #382RBD5G1 #382RBD5G2 #382RBD5G3 12/2022 Info@CarnivalKingSupplies.com | CarnivalKingSupplies.com...
-
Page 2: Table Of Contents
Refrigerated Beverage Dispensers User Manual Table of Contents Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Features &... -
Page 3: Features & Controls
260W 550W 710W Voltage 120V Serial Plate The technical features of the machine are reported on the serial plate attached on the frame . ITEM: 382RBD3G1 MODEL: COLDREAM 1M DESCRIPTION: REFRIGERATED BEVERAGE DISPENSER VOLTAGE: 120V WATTS: 275W GAS/Q. TY: SERIAL #:... -
Page 4: Installation
Refrigerated Beverage Dispensers User Manual Installation Unpacking In order to prevent the oil contained in the air-tight compressor from flowing into the cooling circuit, it is necessary to always carry, store, and handle the machine in a vertical position, following the instructions found on the packaging . If the machine was accidentally or purposely placed in a non- vertical position during transport, before operating the machine it should be kept in a straight position for approximately 30... -
Page 5: Operation
Refrigerated Beverage Dispensers User Manual Operation Preparing The Product Concentrate In order to obtain a homogeneous mix, the product will need to be pre-mixed before being added to the machine . Follow the manufacturer’s recommendations for mixing . Ready-to-Use & Pre-Mixed Concentrates Turn the machine OFF and unplug from power supply . -
Page 6: Cleaning
Refrigerated Beverage Dispensers User Manual Cleaning The machine must be turned OFF and unplugged CAUTION from the power source before cleaning . Empty The Bowl Use the tap lever to empty any remaining liquid into a container . DO NOT Proceed without emptying the bowl . Disassembly (Fig . -
Page 7: Troubleshooting
Refrigerated Beverage Dispensers User Manual Troubleshooting CAUTION Problems marked with this symbol must be handled by a specialized technician . PROBLEM CAUSE SOLUTION The Main Switch is not set to I Set the Main Switch to I The machine is not plugged in Plug the machine into the outlet The machine does not turn ON... -
Page 8: Electrical Diagram
Refrigerated Beverage Dispensers User Manual Electrical Diagram - 3G/1/2/3, 5G/1/2/3 Compressor Exchanger Fan motor Boiler collector E 1,2,3 Evaporator Distributor Capillary Drain Line Liquid Line Suction Line Thermostat Info@CarnivalKingSupplies.com CarnivalKingSupplies.com... -
Page 9: Parts Diagram
Refrigerated Beverage Dispensers User Manual Parts Diagram - 3G/1/2/3, 5G/1/2/3 NO . DESCRIPTION Mixer Paddle S/S Piston O-R for Stainless Steel Tap Bowl Stainless Steel Tap Assembly Push Lever Bowl Gasket Mixer Guiding Shaft Gearbox 110V Gearbox 220V Thermostat Red Switch Black Switch Side Panel Grey Side Panel Red...
