Summary of Contents for Carnival King 382SMM1
- Page 1 User Manual Frozen Beverage Dispenser #382SMM1 #382SMM2 #382SMM3 5018325 5018325 09/22 Info@CarnivalKingSupplies.com | CarnivalKingSupplies.com...
-
Page 2: Table Of Contents
Frozen Beverage Dispenser User Manual Table of Contents Safety ....................................2 Components, Features & Controls ..........................3 Main Components ..................................3 Technical Features ..................................3 Serial Plate ....................................3 Main Control ....................................3 Bowl Control ....................................3 Installation ..................................4 Unpacking ....................................4 Positioning .................................... -
Page 3: Components, Features & Controls
PRESSURE CLASS Positioned underneath each bowl. Serial Plate The technical features of the machine are reported on the serial plate attached on the frame. ITEM: 382SMM1 SPECS: 1 x 1.6 GAL VOLTAGE: 120V WATTAGE: 350W 5018325 5018325 GAS/Q.TY: R513 - Gr. 140 PRESSURE: HIGH - 186 PSI;... -
Page 4: Installation
Frozen Beverage Dispenser User Manual Installation CAUTION Unpacking Remove the carton box and the plastic bag. Make sure that the machine is intact and has not been damaged during transport. Dispose of any packaging materials properly, keeping any that you may need for future moves. Positioning Place the machine on a sturdy horizontal surface. -
Page 5: Operation
Frozen Beverage Dispenser User Manual Operation Before using the machine, all food contact surfaces and components must be cleaned CAUTION and sanitized in accordance to the Washing & Sanitizing section of this manual. Preparing The Product Fig. 2 Concentrate In order to obtain a homogeneous mix, the product will need to be premixed before being added to the machine. -
Page 6: Cleaning
Frozen Beverage Dispenser User Manual Cleaning The machine must be turned OFF and unplugged CAUTION from the power source before cleaning. Empty the Bowl (Skip this step if this is the initial cleaning) Use the tap lever to empty any remaining liquid into a container. DO NOT proceed without emptying the bowl. -
Page 7: Washing & Sanitizing
This cleaning should be performed at least once a month. CAUTION The machine must be turned OFF and unplugged from the power source before cleaning. 382SMM1, 382SMM2, 382SMM3 (Fig. 14) • Remove the left side stainless steel panel by unscrewing the Fixing Knob. -
Page 8: Reassembly
Frozen Beverage Dispenser User Manual Reassembly CAUTION All washed and/or sanitized parts must be completely dry before being When cleaning carefully reassembled. Some components must be lubricated in order to or lifting, DO NOT GRAB work efficiently. A tube of lube is included with each machine. THE MACHINE BY THE Fig. -
Page 9: Rinse Cycle
Frozen Beverage Dispenser User Manual Rinse Cycle After cleaning, it is necessary to run a rinse cycle before loading product. Fill the bowl with clean water to the MAX Fill Line. Turn the Main Power Switch ON (I). Turn the Spiral Blade ON (I). Let the machine run for 5 minutes. -
Page 10: Troubleshooting
Frozen Beverage Dispenser User Manual Troubleshooting CAUTION Problems marked with this symbol must be handled by a specialized technician. PROBLEM CAUSE SOLUTION The Main Switch is not set to I Set the Main Switch to I THE MACHINE The machine is not plugged in Plug the machine into the outlet DOES NOT TURN ON... -
Page 11: Electrical Diagrams
Frozen Beverage Dispenser User Manual Electrical Diagrams 382SMM1 382SMM2 382SMM3 Italiano English Francaise Espanol Italiano English Francaise Espanol Interruttore luminoso Main power switch Interrupteur général Interruptor general Interruttore luminoso Main power switch Interrupteur général Interruptor general G 1,2,3 Motoriduttore Motor-gearbox... - Page 12 Frozen Beverage Dispenser User Manual Info@CarnivalKingSupplies.com CarnivalKingSupplies.com...
-
Page 13: Parts Diagrams
Frozen Beverage Dispenser User Manual Parts Diagram - SMM1 CODE DESCRIPTION CODE DESCRIPTION 3016 2145 Evaporator Cover 3014 Curved Profile 3007,01 Transmission Shaft 3015 Bowl 2111 Metal Ring M25 2150 Rotation Pin 2123 Evaporator Cover Inner OR (Small) 2117 Tap Lever Evaporator Cover Inner OR (Large) 2149 Fixing Knob... - Page 14 Frozen Beverage Dispenser User Manual Info@CarnivalKingSupplies.com CarnivalKingSupplies.com...
- Page 15 Frozen Beverage Dispenser User Manual Parts Diagram - SMM2 CODE DESCRIPTION CODE DESCRIPTION 3016 3007,01 Transmission Shaft 3014 Curved Profile 2111 Metal Ring M25 3015 Bowl 2123 Evaporator Cover Inner OR (Small) 2150 Rotation Pin Evaporator Cover Inner OR (Large) 2117 Tap Lever 2159...
