- Page 1 Hearing Aid User Manual HearClear HC64...
-
Page 3: Table Of Contents
Table Of Contents FDA Required Information ......... 2-5 Package Contents ..........6 Your Product Information ........7 Preface ..............8 HearClear™ HC64 Features ........9 Thick Tube Assembly ........10-11 Batteries..............12 Batteries Cont’d and Choosing Domes ....13 Turning On/Off and Storage .........14 Storing Your HC64 ..........15 How To Talk On The Phone ........16 Cleaning and Maintenance ........17... -
Page 4: Fda Required Information
FDA Required Information WARNING: People younger than 18 should go to a doctor before using this. People younger than 18 years old need specialized care, and using this without a medical evaluation may worsen impairment or disability. A hearing aid user who is younger than 18 should have a recent medical evaluation from a doctor, preferably an ear-nose-throat doctor (an ENT). - Page 5 FDA Required Information at 500 Hz, 1000 Hz, and 2000 Hz WARNING to Hearing Aid Dispenser, Outputs over 132 dB SPL: You should exercise special care in selecting and fitting a hearing aid with a maximum output that exceeds 132 dB SPL because it may impair the remaining hearing of the hearing aid user.
- Page 6 FDA Required Information However, you should know it will not restore normal hearing, and you may still have some difficulty hearing over noise. Further, a hearing aid will not prevent or improve a medical condition that causes hearing loss. People who start using hearing aids sometimes need a few weeks to get used to them.
- Page 7 FDA Required Information • The doctor may refer the person to an audiologist for a separate test, a hearing aid evaluation. • The hearing aid evaluation will help the audiologist select and fit the appropriate hearing aid. A person who is younger than 18 years old with hearing loss should have a medical evaluation by a doctor, preferably an ENT, before buying a hearing aid.
-
Page 8: Package Contents
Package Contents 1) Size 675 Batteries 4) Dome Variety 2) HC64 Hearing Aid 5) Brush/Screwdriver 3) Storage Case Note: Items and quantities shown are for a single hearing aid; quantities may change for a pair. The contents of this package are subject to change any time. -
Page 9: Your Product Information
Your Product Information Record Your HC64 Information: Your Serial Number(s): Warranty Included With Your HC64: Standard 6 Month Manufacturer Warranty (If you purchased an Advanced Care Extended Warranty plan, please see warranty certificate for details.) Tube and Dome Sizes You Use: Battery Size: Size 675 Batteries or Blue... -
Page 10: Preface
Preface Congratulations on becoming the new owner of a HearClear™ HC64! Welcome to the Advanced Affordable Hearing family! Our products have helped thousands of satisfied customers in all corners of the globe. We are passionate about helping you find an affordable solution to your hearing loss challenges. -
Page 11: Hearclear™ Hc64 Features
HearClear™ HC64 Features 1) Earhook 5) Battery Door 2) Volume Control Wheel 6) Thick Tube 3) Trimmer (H, P) Cover 7) Dome 4) Program Button IMPORTANT: Allow 4-8 weeks for your brain to adjust to sounds with your new hearing aids. The more you wear them, the quicker your brain will adjust. Helpful Tip: When you start to use your hearing aids, you may experience your voice sounding “plugged up”... -
Page 12: Thick Tube Assembly
Thick Tube Assembly Thick Tubing Assembly Step 1 Attach the earhook by placing it on top of the brass grooves and turn clockwise until it fits snugly and is aligned with the hearing aid. Step 2 Choose the suitable dome and push it onto the thick tube. - Page 13 Thick Tube Assembly Cont’d Step 6 Trim off any unneeded tubing, leaving 3/16’’ to connect to the earhook (this will overlap). Step 7 Connect the tube to the earhook by gripping the ear hook and firmly pushing until it is securely attached.
-
Page 14: Batteries
Batteries Putting A New Battery In Your HC64 Step 1 The HC64 uses a size 675 hearing aid battery. When placing a new battery in your HC64, grip the HC64 firmly. Press your thumb against the swinging door. Step 2 Remove the protective foil sticker from the new battery. -
Page 15: Batteries Cont'd And Choosing Domes
Batteries Cont’d and Choosing Domes Low Battery Warning When the battery life is expiring, you hear a low battery warning (one short beep). This warning will continue intermittently until you replace the old battery with a fresh new one. After the first warning, it is normal to experience some reduction in sound quality. -
Page 16: Turning On/Off And Storage
Turning On/Off and Storage Turning Your HC64 On/Off And Storage Turning ON the HC64 Once the battery is gently inserted with the positive side facing up, there will be a 10 second delay before the HC64 begins to operate. Turning OFF the HC64 Simply open the battery door (and keep it open) to turn off the device. -
Page 17: Storing Your Hc64
Storing Your HC64 Recommended Products If your living situation has a high humidity that can cause extra perspiration, we recommend that you purchase either a Dry Aid Jar or a Dry and Store Box . By simply keeping your HC64 in either of these products overnight, you will extend the life of your hearing aid. -
Page 18: How To Talk On The Phone
How To Talk On The Phone How To Talk On The Phone Talking on the phone can often lead to feedback from your hearing aid. Follow these steps to have the best phone experience with the HC64. Step 1 Set the program on your HC64 to 3 to reduce the feedback while on the phone. -
Page 19: Cleaning And Maintenance
Cleaning and Maintenance Cleaning and Maintenance Helpful Tip: Regular cleaning of both your ears and hearing aids will keep them working in top condition, and help get the most out of your hearing experience. Earwax buildup is a very common issue that can be solved with simple daily hygiene practices. -
Page 20: Volume And Program Settings
Volume and Program Settings How To Adjust Volume To adjust the volume, rotate the volume control wheel with your fingertip up and down. The numbers on the wheel indicate the current volume setting. 1 being the lowest volume setting and 4 being the loudest. (Note: Rotate the volume wheel slowly to avoid a sudden loud burst of noise.) •... -
Page 21: Hc64 Trimmer Adjustments
HC64 Trimmer Adjustments H Trimmer Use to eliminate feedback or increase clarity. Turn clockwise for increased clarity. Turn counter clockwise for reduced feedback. P Trimmer Controls the maximum output sound level. Turn clockwise for maximum sound amplification. Issues Speech Own voice too boomy/echoes Loud speech is too loud Speech understanding in quiet is poor... -
Page 22: Troubleshooting
Troubleshooting Problem: Hearing Aid Has Weak Or No Sound Possible Causes Solutions To Try No battery or it is Make sure to insert inserted improperly the battery correctly Dead or Replace the battery low battery with a fresh new one Thoroughly clean your ears Excessive ear wax and consult your physician... - Page 23 Troubleshooting Cont’d Problem: Whistling, Noise and Feedback Occurring Possible Causes Solutions To Try Loose insertion of Remove and re-insert hearing instrument so it fits better Excessive ear wax Thoroughly clean your ears and consult your physician Object (such as your hand or headset) is Remove the object and close to the hearing...
- Page 24 Troubleshooting Cont’d Problem: Sound Is Distorted Or Unclear Possible Causes Solutions To Try Low battery Replace the battery with a new one Dust or lint has Rotate the Volume Control Wheel up collected in and down a few times controls Trapped Consider leaving your hearing aid moisture...
-
Page 25: Technical Information
Technical Information Technical Information Testing Diagram Technical Data HC 64 Peak OSPL 90 (dB SPL) Peak OSPL 90 (dB SPL) Note: The HFA full on Gain (dB) Manufacturer Total Harmnic Distort: reserves the right to modify 500Hz(%) the technical 800Hz(%) specifications of the 1600Hz(%) product without... -
Page 26: Benefits Of 2 Hearing Aids
Benefits Of 2 Hearing Aids Ears Are Designed To Work Together Your brain is designed to use both ears working together to fully understand what you hear. Studies have shown that the benefit of wearing 2 hearing aids can be up to 3 times more than wearing just one. -
Page 27: Warranty, Repairs And Returns
Warranty, Repairs and Returns Warranty and Repairs Your hearing aid comes with a 6 month warranty against manufacturer defects from the date you receive your order. If our examination determines that the unit failed to work due to parts, materials or workmanship, we will repair or replace it for free. -
Page 28: Special Statements And Information
Special Statements and Information Special Statements Regarding Hearing Aids Hearing aids will not restore normal hearing and will not prevent or improve a hearing impairment resulting from organic conditions. Allergic reactions to hearing aids are unlikely. However, if you experience itching, redness, soreness, inflammation or a burning sensation in or around your ears, inform your hearing health care professional and contact your physician. -
Page 29: Information Cont'd
Information Cont’d hearing aid if the hearing aid dispenser determines through inquiry, actual observation or review of any other available information concerning the prospective user, that the prospective user has any of the following conditions: Visible congenital or traumatic deformity of the ear. (ii) History of active drainage from the ear within the previous 90 days. - Page 30 Information Cont’d loss has been medically evaluated and that you may be considered a candidate for a hearing aid. The physician will refer you to an audiologist or a hearing aid dispenser, as appropriate, for a hearing aid evaluation. The audiologist or hearing aid dispenser will conduct a hearing aid evaluation to assess your ability to hear with and without a hearing aid.
- Page 31 Information Cont’d Children With Hearing Loss In addition to seeing a physician for a medical evaluation, a child with a hearing loss should be directed to an audiologist for evaluation and rehabilitation since hearing loss may cause problems in language development and the educational and social growth of a child.
- Page 32 04.23 Advanced Affordable Hearing, LLC. Tel: 1-888-570-274 Fax: 1-877-308-1820 Website: www.AdvancedHearing.com Email: support@advancedaffordablehearing.com HearClear™ is a trademark of Advanced Affordable Hearing, LLC. All rights reserved. Copyright ©2023 Advanced Affordable Hearing. All Rights Reserved.
