Summary of Contents for Advanced Affordable Hearing HearClear HCZ3
- Page 1 Hearing Aid User Manual HearClear™ HCZ3...
-
Page 3: Table Of Contents
Table Of Contents FDA Required Information ........... 2-5 Package Contents ............6 Your Product Information ..........7 Preface................8 HearClear™ HCZ3 Features ..........9 HearClear™ HCZ3 Assembly ..........10 Batteries................11 Choosing Domes ............. 12-13 Turning On/Off ..............14 Storing Your HCZ3 ............15 How To Put Your HCZ3 On ..........16 How To Talk On The Phone ..........17 Thick Tube Assembly .......... -
Page 4: Fda Required Information
FDA Required Information WARNING: People younger than 18 should go to a doctor before using this. People younger than 18 years old need specialized care, and using this without a medical evaluation may worsen impairment or disability. A hearing aid user who is younger than 18 should have a recent medical evaluation from a doctor, preferably an ear-nose-throat doctor (an ENT). - Page 5 FDA Required Information at 500 Hz, 1000 Hz, and 2000 Hz WARNING to Hearing Aid Dispenser, Outputs over 132 dB SPL: You should exercise special care in selecting and fitting a hearing aid with a maximum output that exceeds 132 dB SPL because it may impair the remaining hearing of the hearing aid user.
- Page 6 FDA Required Information However, you should know it will not restore normal hearing, and you may still have some difficulty hearing over noise. Further, a hearing aid will not prevent or improve a medical condition that causes hearing loss. People who start using hearing aids sometimes need a few weeks to get used to them.
- Page 7 FDA Required Information • The doctor may refer the person to an audiologist for a separate test, a hearing aid evaluation. • The hearing aid evaluation will help the audiologist select and fit the appropriate hearing aid. A person who is younger than 18 years old with hearing loss should have a medical evaluation by a doctor, preferably an ENT, before buying a hearing aid.
-
Page 8: Package Contents
Package Contents Size 13 Batteries Cleaning Filament HCZ3 Hearing Aid Dome Variety Storage Case Brush/Screwdriver Note: Items and quantities shown are for a single hearing aid; quantities may change for a pair. The contents of this package are subject to change any time. -
Page 9: Your Product Information
Your Product Information Record Your HCZ3 Information: Your Serial Number(s): Warranty Included With Your HCZ3: Standard 6 Month Manufacturer Warranty (If you purchased an Advanced Care Extended Warranty plan, please see warranty certificate for details.) Tube and Dome Sizes You Use: Battery Size: Size 13, or orange 10mm... -
Page 10: Preface
Preface Congratulations on becoming the new owner of a HearClear™ HCZ3 hearing aid! Welcome to the Advanced Affordable Hearing family! Our products have helped thousands of satisfied customers in all corners of the globe. We are passionate about helping you find an affordable solution to your hearing loss challenges. -
Page 11: Hearclear™ Hcz3 Features
HearClear™ HCZ3 Features Microphone Battery Door Volume Control Wheel Hearing Tube Trimmer (H, P) Cover Dome Program Button Important: Allow 4-8 weeks for your brain to adjust to sounds with your new hearing aids. The more you wear them, the quicker your brain will adjust. Helpful Tip: When you start to use your hearing aids, you may experience your voice sounding “plugged up”... -
Page 12: Hearclear™ Hcz3 Assembly
HearClear™ HCZ3 Assembly Assembling the HearClear™ HCZ3 With these 3 simple steps, you’ll have your hearing aid assembled in no time! If you purchased the Power Upgrade please go to “Power Upgrade (Thick Tubing) Assembly” on page 18. Step 1 Select the hearing tube with the blue numbering for the hearing... -
Page 13: Batteries
Batteries Putting A New Battery In Your HCZ3 Step 1 The HCZ3 uses a size 13 hearing aid battery. When placing a new battery in your HCZ3, grip the HCZ3 and press your thumb against the swinging door. Step 2 Remove the protective foil sticker from the new battery. - Page 14 Batteries Cont’d and Choosing Domes Low Battery Warning When the battery life is expiring, you will hear a low battery warning (one short beep). This warning will continue intermittently until you replace the old battery with a fresh new one. After the first warning, it is normal to experience some reduction in sound quality.
-
Page 15: Choosing Domes
Choosing Domes Cont’d Double Domes Double closed domes are intended for people with significant to severe losses. Double closed domes have a “double dome” appearance with the second dome acting as an additional sound seal. In addition to providing the same functionality as regular closed domes, double closed domes can provide additional volume and less feedback. -
Page 16: Turning On/Off
Turning On/Off Turning Your HCZ3 ON/OFF Turning ON the HCZ3 Once the battery is gently inserted with the positive side facing up, there will be a 10 second delay before the HCZ3 begins to operate. Turning OFF the HCZ3 Simply open the battery door (and keep it open) to turn off the device. -
Page 17: Storing Your Hcz3
Storing Your HCZ3 Storing Your Device Store your hearing aid with the battery door open in a safe, dry, cool place until the next use. (Note: Remember to remove the battery if your hearing aid is not being used for long periods of time.) Also, remove your hearing aid(s) while sleeping, to allow your ear canals to dry. -
Page 18: How To Put Your Hcz3 On
How To Put Your HCZ3 On How To Put Your Hearing Aid On Step 1 Once assembled, hang the hearing aid so it rests over the top of your ear. Step 2 Gently insert the dome end of the tube into your ear canal until it fits snuggly and comfortably (it should be completely inside your ear canal opening). -
Page 19: How To Talk On The Phone
How To Talk On The Phone How To Talk On The Phone Talking on the phone can often lead to feedback from your hearing aid. Follow these steps to have the best phone experience with the HCZ3. Step 1 Set the program on your HCZ3 to 4 to reduce the feedback while on the phone. -
Page 20: Thick Tube Assembly
Thick Tube Assembly Power Upgrade (Thick Tubing) Assembly If you were advised to use the Power Upgrade (an earhook and thick tubing), please read all the directions below to fit your tubing properly. How To Attach The Earhook and Thick Tubing Your hearing aid is sent to you with the standard thin tubing already attached. - Page 21 Thick Tube Assembly Cont’d Step 4 Hang the hearing aid over the top of your ear (with just the earhook attached). Step 5 Gently push the dome end of the tube into your ear canal until it fits snugly and comfortably. Step 6 Hold the open end of the tube up to earhook, noting that there...
-
Page 22: Cleaning And Maintenance
Cleaning and Maintenance Cleaning and Maintenance Helpful Tip: Regular cleaning of both your ears and hearing aids will keep them working in top condition, and help get the most out of your hearing experience. Earwax buildup is a very common issue that can be solved with simple daily hygiene practices. -
Page 23: Cleaning Tubes
Cleaning Tubes How To Clean Your Hearing Tubes If there is a blockage inside your hearing tube caused by ear wax or some other object use the following steps to clear the tube. Step 1 Pinch the hard clear plastic pyramid attached to the hearing aid and turn counterclockwise until removed. -
Page 24: Volume And Program Settings
Volume and Program Settings How to Adjust Volume To adjust the volume, rotate the volume control wheel with your fingertip up and down. The numbers on the wheel indicate the current volume setting. 1 being the lowest volume setting and 4 being the loudest. (Note: Rotate the volume wheel slowly to avoid a sudden loud burst of noise.) •... -
Page 25: Hcz3 Trimmer Adjustments
HCZ3 Trimmer Adjustments H Trimmer Use to eliminate feedback or increase clarity. Turn clockwise for increased clarity. Turn counter clockwise for reduced feedback. P Trimmer Controls the maximum output sound level. Turn clockwise for maximum sound amplification. Issues Speech Own voice too boomy/echoes Loud speech is too loud Speech understanding in quiet is poor... -
Page 26: Troubleshooting
Troubleshooting Problem: Hearing Aid Has Weak Or No Sound Possible Causes Solutions To Try No battery or it is Make sure to insert the battery inserted improperly correctly Dead or low battery Replace the battery with a fresh new Excessive ear wax Thoroughly clean your ears and consult your physician Volume is set too low... - Page 27 Troubleshooting Cont’d Problem: Whistling, Noise and Feedback Occurring Possible Causes Solutions To Try Loose insertion of Remove and re-insert so it fits better hearing instrument Excessive ear wax Thoroughly clean your ears and consult your physician An improper dome Try using a closed or double dome instead style or size is being used.
- Page 28 Troubleshooting Cont’d Problem: Sound Is Distorted Or Unclear Possible Causes Solutions To Try Low battery Replace the battery with a new one Dust or lint has Rotate the Volume Control Wheel collected in up and down a few times controls Trapped moisture Consider leaving your hearing aid in uncooked rice or a dehumidifier overnight...
- Page 29 Technical Information Technical Information Testing Diagram Technical Data HCZ3 Peak OSPL 90(dB SPL) HFA OSPL 90(dB SPL) Peak Gain (dB) Note: The Reference Test Gain (dB) manufacturer reserves the HFA full on Gain (dB) right to modify Total Harmonic Distortion the technical 500Hz (%) specifications...
-
Page 30: Benefits Of 2 Hearing Aids
Benefits Of 2 Hearing Aids Benefits Of Wearing Two Hearing Aids Ears Are Designed To Work Together Your brain is designed to use both ears working together to fully understand what you hear. Studies have shown that the benefit of wearing 2 hearing aids can be up to 3 times more than wearing just one. -
Page 31: Warranty, Repairs And Returns
Warranty, Repairs and Returns Warranty and Repairs Your hearing aid comes with a 6 month warranty against manufacturer defects from the date you receive your order. If our examination determines that the unit failed to work due to parts, materials or workmanship, we will repair or replace it for free. -
Page 32: Special Statements And Information
Special Statements and Information Special Statements Regarding Hearing Aids • Hearing aids will not restore normal hearing and will not prevent or improve a hearing impairment resulting from organic conditions • Allergic reactions to hearing aids are unlikely. However, if you experience itching, redness, soreness, inflammation or a burning sensation in or around your ears, inform your hearing health care professional and contact your... - Page 33 Information Cont’d through inquiry, actual observation or review of any other available information concerning the prospective user, that the prospective user has any of the following conditions: Visible congenital or traumatic deformity of the ear. (ii) History of active drainage from the ear within the previous 90 days.
- Page 34 Information Cont’d appropriate, for a hearing aid evaluation. The audiologist or hearing aid dispenser will conduct a hearing aid evaluation to assess your ability to hear with and without a hearing aid. The hearing aid evaluation will enable the audiologist or dispenser to select and fit a hearing aid to your individual needs.
- Page 36 05.23 Advanced Affordable Hearing, LLC. Tel: 1-888-570-2740 Fax: 1-877-308-1820 Website: www.AdvancedHearing.com Email: support@advancedaffordablehearing.com HearClear™ is a trademark of Advanced Affordable Hearing, LLC. All rights reserved. Copyright ©2023 Advanced Affordable Hearing. All Rights Reserved.
