- Page 1 Refrigerator User manual RT29K503JB1 Free Standing Appliance Untitled-1 1 2021-07-29 6:22:41...
-
Page 2: Table Of Contents
Contents Safety information What you need to know about the safety instructions Important safety symbols and precautions: Important safety precautions How to minimize the energy consumption This appliance is intended to be used in household and similar applications such as Additional tips for proper usage Instructions about the WEEE Severe warnings... -
Page 3: Safety Information
Safety information Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efficiently. What you need to know about the safety instructions •... - Page 4 Safety information • Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room must be 1 m in size for every 8 g of R-600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance.
-
Page 5: Important Safety Symbols And Precautions
Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. -
Page 6: Important Safety Precautions
Safety information Important safety precautions Warning; Risk of fire / flammable materials WARNING • When positioning the appliance, ensure the supply cord is not trapped or damaged. • Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. •... - Page 7 • If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center. - Use only the LED Lamps provided by the manufacturer or its service agents.
-
Page 8: How To Minimize The Energy Consumption
Safety information How to minimize the energy consumption • Install the appliance in a cool, dry room with adequate ventilation. • Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (radiator, for example). - Not to block any vents or grilles is recommended for energy efficiency. -
Page 9: This Appliance Is Intended To Be Used In Household And Similar Applications Such As
This appliance is intended to be used in household and similar applications such as - staff kitchen areas in shops, offices and other working environments; - farm houses and by clients in hotels, motels and other residential type environments; - bed and breakfast type environments; - catering and similar non-retail applications. -
Page 10: Instructions About The Weee
Safety information • Temperature rise during defrosting complies with ISO requirements. If you want to prevent an undue rise in the temperature of frozen food while the appliance defrosts, wrap the frozen food in several layers of newspaper. • Do not re-freeze frozen foods that have thawed completely. -
Page 11: Severe Warnings
- Failing to do so may result in an electric shock or fire due to electric leakage. • If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact a Samsung service center. - Failing to do so may result in an electric or fire hazards. - Page 12 - There is a risk of fire or electric shock. • If large amounts of dust or water enter the refrigerator, disconnect the power plug and contact a Samsung Electronics service center. - Otherwise there is a risk of fire.
- Page 13 • Children should be supervised to ensure that they do not play with the appliance. - Keep fingers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.
- Page 14 Safety information • If your refrigerator needs to be repaired or reinstalled, contact your nearest Samsung service center. - Failing to do so may result in an electric shock, fire, problems with the product, or injury. - Unauthorized modifications can cause safety problems.
- Page 15 • Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator to remove bad odors. - This may result in an electric shock or fire. • Do not put a fridge shelf into the refrigerator upside down. The shelf stopper will not work.
- Page 16 Safety information • When moving the refrigerator, be careful not to roll over or damage the power cord. - This may result in an electric shock or fire. • When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
-
Page 17: Installation And Usage Cautions
• Service Warranty and Modification. - Any changes or modifications performed by a 3rd party on this finished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modifications. • Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Page 18 Safety information • Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difficult to use. In addition, the open container can leak and the leaked oil can cause the door bin to crack. After opening an oil container, it is best to keep the container in a cool and shaded place such as a cupboard or pantry.
- Page 19 • Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops) - Deteriorated insulation on electrical parts may cause an electric shock or fire. • Be careful that your fingers are not caught in.
-
Page 20: Installation
Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING • Use the refrigerator only for its intended purpose as described in this manual. • Any servicing must be performed by a qualified technician. •... - Page 21 Optional accessories * Spacer: This helps keep the refrigerator cool. Cool pack: This helps keep the refrigerator cool. Ice tray: Used to make ice. Twist Ice Maker: Used to make ice. * Your refrigerator may not include optional accessories listed above. Provision of optional accessories depends on the model and the country.
- Page 22 Installation To secure more room for storage in the freezer compartment Remove one or more optional accessories such as cool pack(s), shelf or shelves, twist ice maker(s), ice storage bins and their supports, all of which can be removed manually without a tool.
-
Page 23: Step-By-Step Installation
Step-by-step installation STEP 1 Select a site Site requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for opening and closing the door • Away from a heat source •... - Page 24 Installation Clearance See the pictures and table below for space requirements for installation. Model RT42, RT38 1275 1001 115° RT39, RT35 1275 1001 115° RT37, RT32 1221 1040 135° RT34, RT29 1221 1040 135° (unit: mm) 01 100 mm 02 more than 50 mm recommended English Untitled-1 24 2021-07-29...
- Page 25 STEP 2 Spacing (applicable models only) 1. Open the door and locate the provided spacers (x2). 2. Unpack both spacers and attach them to the rear of the refrigerator as shown. They help ventilate air to the rear wall and save power consumption. STEP 3 Flooring •...
- Page 26 Installation CAUTION Before moving the refrigerator, make sure to turn the levelling feet counter clockwise so that the bottom of the refrigerator at least 66 mm from the floor. STEP 5 Initial settings By completing the following steps, the refrigerator should be fully functioning. 1.
-
Page 27: Operations
Operations Feature panel Fridge To ensure optimal performance, we recommend setting the temperature to Optimal or • To decrease the temperature for strong cooling, set the temperature control to level 5-6. • To increase the temperature for weak cooling, set the temperature control to level 1-2. - Page 28 Operations Freezer To make ice in summer (above 35 °C), set the freezer temperature to Optimal. RT35/38 • To increase the temperature, slide/turn the temperature control to the right. • To decrease the temperature, slide/ turn the temperature control to the left. In winter, slide/turn the temperature control to the right-most end.
-
Page 29: Special Features
Special features The actual image and special functions of your refrigerator may differ, depending on the model and the country. Ice making (applicable models only) Twist ice maker 1. Open the freezer door, and slide open the ice tray. 2. Fill the tray with water up to the maximum level (A) marked on the inner rear of the tray. - Page 30 Operations To empty the ice tray, hold both ends of the tray and gently twist to remove the ice cubes. Water dispenser (applicable models only) With the water dispenser, you can dispense water without opening the fridge door. The water tank must be filled with potable water before use. To fill the water tank with potable water Open the door and locate the water tank that is located in the door shelf area.
- Page 31 3. Reinsert the water tank and close the door. Make sure the water outlet of the water tank faces forward. 4. Put a water glass under the water outlet of the dispenser, and gently push the dispenser lever to dispense water. Make sure the water dispenser is unlocked.
-
Page 32: Maintenance
Maintenance Handle and care Freezer and fridge shelves • To remove a shelf, first open the door completely. Pull the shelf forward, lift up, and then pull out. • When reinserting the shelf, make sure the “Front” label of the shelf faces forward. -
Page 33: Cleaning
(A). Replace the filter, and then reinsert the case. Lamps The lamps are not user-serviceable. To replace the lamps of the refrigerator, contact a local Samsung service centre. English Untitled-1 33 2021-07-29 6:22:44... -
Page 34: Troubleshooting
Troubleshooting If you encounter an abnormal situation with the refrigerator, first check the table below and try the suggestions. General Temperature Symptom Possible causes Solution • Power cord is not plugged in • Properly plug in the power properly. cord. •... - Page 35 Odors Symptom Possible causes Solution • Clean the refrigerator and • Spoiled food. remove any spoiled food. Refrigerator has odors. • Make sure strong smelling • Food with strong odors. food is wrapped airtight. Condensation Symptom Possible causes Solution • Remove the moisture and do •...
-
Page 36: Do You Hear Abnormal Sounds From The Refrigerator
Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal. • When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting. - Page 37 • As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling! • As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working.
- Page 38 Memo Untitled-1 38 2021-07-29 6:22:45...
- Page 39 Memo Untitled-1 39 2021-07-29 6:22:45...
- Page 40 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site 0800 726 786 (All Product) NEW ZEALAND www.samsung.com/nz/support 0800 6 726 786 (Support for Smart Mobile Devices)
