- Page 1 Split-type Air-Conditioner MXZ-3F54VF2 MXZ-3F68VF2 MXZ-4F72VF2 MXZ-4F80VF2 English INSTALLATION MANUAL...
- Page 2 FOR INSTALLER Required Tools for Installation CONTENTS Level 1. BEFORE INSTALLATION ............1 Scale 2. OUTDOOR UNIT INSTALLATION ..........7 ....... 8 ..9 ..............11 1. BEFORE INSTALLATION MEANINGS OF SYMBOLS DISPLAYED ON INDOOR UNIT AND/OR OUTDOOR UNIT WARNING 1-1.
- Page 3 This manual only describes the installation of outdoor unit. When installing the indoor unit, refer to the installation manual of indoor unit. CAUTION Install an earth leakage breaker depending on the installation place. Do not install the outdoor unit where small animals may live. Perform the drainage/piping work securely according to the installation manual.
- Page 4 FREE SPACE REQUIRED AROUND OUTDOOR UNIT Obstacles above Front (blowing) side open When there is no obstacle in front and on the As long as space indicated in the install the unit where obstacles are behind and on the sides of the unit. Obstacles in front (blowing) only Obstacles in front and behind When there is an obstacle in front of the...
- Page 5 1-4-1. Minimum installation area for Outdoor units EN-4...
- Page 6 15.5 1.84 3.63 3.75 3.95 Floor standing 4.15 4.34 4.54 4.74 EN-5...
- Page 7 1-5. INSTALLATION DIAGRAM gap. Open as a rule if the front and both sides are open tape around the piping. obstacles to both sides WARNING Open as a rule sides and top are open ACCESSORIES PARTS TO BE PROVIDED AT YOUR SITE Indoor/outdoor unit connecting wire*1 antenna wire.
- Page 8 1-6. DRAIN PIPING FOR OUTDOOR UNIT pleted. Service panel <OUTDOOR UNIT> Indoor/outdoor unit connecting wire Lead wire <INDOOR UNIT> EN-7...
- Page 9 or dust. other refrigerant and do not allow air to remain in the lines. hazards. this could lead to a serious impediment to securing product safety. ø6.35 ø9.52 ø12.7 ø15.88 ø22.2 ø25.4 ø28.58 Good No good in the pipe. pipe Tilted Uneven Burred Fig.
- Page 10 4. PURGING PROCEDURES, LEAK TEST, AND TEST RUN 4-1. PURGING PROCEDURES AND LEAK TEST Stop valve cap *4 to 5 turns *Open valve on the gas pipe side of the outdoor unit. Handle High Handle Service port cap • Stop valve Stop valve for LIQUID for GAS...
- Page 11 The setting of Dip Switch on the outdoor controller board can be changed Dip Switch. 4-4. LOCKING THE OPERATION MODE OF THE AIR CONDITIONER (COOL, DRY, HEAT) • Description of the function: [How to lock the operation mode] SW871 to ON. 1 2 3 4 5 6 1 2 3 4 5 6 HEAT...
- Page 12 4-6. LOWERING THE OPERATION NOISE OF THE OUTDOOR UNIT • Description of the function: [How to lower the operating noise] Lower the operating noise 4-7. TEST RUN About the restart protective mechanism Wiring/piping correction function • Stop valves are open. function.
- Page 13 DB/WB DB/WB Manufactured by : Manufactured by : MITSUBISHI ELECTRIC CONSUMER PRODUCTS (THAILAND) CO., LTD. MITSUBISHI ELECTRIC CONSUMER PRODUCTS (THAILAND) CO., LTD. 700/406 MOO 7, TAMBON DON HUA ROH, 700/406 MOO 7, TAMBON DON HUA ROH, AMPHUR MUANG, CHONBURI 20000, THAILAND...
- Page 14 DECLARAÇÃO DE CONFORMIDADE CE EU-OVERENSSTEMMELSESERKLÆRING MITSUBISHI ELECTRIC CONSUMER PRODUCTS (THAILAND) CO., LTD 700/406 MOO 7, TAMBON DON HUA ROH, AMPHUR MUANG, CHONBURI 20000, THAILAND hereby declares under its sole responsibility that the air conditioners and heat pumps described below for use in residential, commercial and light-industrial environments: erklärt hiermit auf seine alleinige Verantwortung, dass die Klimaanlagen und Wärmepumpen für das häusliche, kommerzielle und leicht-industrielle Umfeld wie unten beschrieben:...
- Page 15 Importer: Capronilaan 46, 1119 NS, Schiphol Rijk, The Netherlands French Branch 25, Boulevard des Bouvets, 92741 Nanterre Cedex, France German Branch Belgian Branch Autobaan 2, 8210 Loppem, Belgium Irish Branch Italian Branch (MB), Italy Norwegian Branch Gneisveien 2D, 1914 Ytre Enebakk, Norway Spanish Branch Scandinavian Branch UK Branch...
