10908080250
4/21
Lionel
CW-80 Transformer
Owner's Manual
TOY TRANSFORMER—CAUTI O N—ELECTRI C TOY
ATTENTI O N—JOUET ÉLECTRI Q UE
NOT RECOMMENDED FOR CHI L DREN UNDER FOURTEEN YEARS OF AGE. AS WI T H
ALL ELECTRI C PRODUCTS, PRECAUTI O NS SHOULD BE OBSERVED DURI N G HANDLI N G AND USE TO
PREVENT ELECTRI C SHOCK.
DÉCONSEI L LÉ AUX ENFANTS DE MOI N S DE QUATORZE ANS. COMME POUR TOUS LES PRODUI T S ÉLECTRI Q UES, DES
PRÉCAUTI O NS DOI V ENT ÊTRE OBSERVÉES LORS DE LA MANI P ULATI O N ET DE L' U TI L I S ATI O N POUR ÉVI T ER LES
CHOCS ÉLECTRI Q UES.
TRANSFORMER RATINGS— MODEL: CW-80
I N PUT: 120 VAC, 60 Hz ONLY.
AC OUTPUT: 18 V; 80 VA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CW-80 and is the answer not in the manual?

Questions and answers

Related Manuals for Lionel CW-80

Summary of Contents for Lionel CW-80

  • Page 1 PRÉCAUTI O NS DOI V ENT ÊTRE OBSERVÉES LORS DE LA MANI P ULATI O N ET DE L' U TI L I S ATI O N POUR ÉVI T ER LES CHOCS ÉLECTRI Q UES. TRANSFORMER RATINGS— MODEL: CW-80 I N PUT: 120 VAC, 60 Hz ONLY.
  • Page 2 Thank You! hank you for your purchase of the Lionel CW-80 Transformer! This device combines a high output control unit and an internal power supply, providing your railroad with 80 watts and five amps of alternating current. With a variable accessory voltage, the CW-80 Transformer features the precision control your layout needs! Read this manual thoroughly before using your Transformer.
  • Page 3 Déclarations de la FCC et CNR Avertissement : Tout modification ou changement apporté à cet équipement sans l'approbation expresse de la partie responsable de sa conformité risque d'annuler le droit de l'utilisateur à se servir de cet équipement. Notes : Cet équipement a été testé et déclaré conforme aux limites pour appareils numériques de classe B, selon la section 15 des règlements de la FCC.

  • Page 4: Table Of Contents

    Operating your CW-80 Transformer safely Wall pack power supply Wiring your CW-80 Transformer Connecting the FasTrack terminal section Operating your trains with the CW-80 Transformer Experiencing the features of the CW-80 Transformer 11-12 Setting the accessory output Powering your layout with the CW-80 Transformer...

  • Page 5: Operating Your Cw-80 Transformer Safely

    • The CW-80 Transformer is intended to be used indoors. Do not use this device if water is present. Serious or fatal injuries may result. •...

  • Page 6: Wall Pack Power Supply

    Not recommended for children under 14 years of age. As with all electric products, precautions should be observed during handling and use to prevent electric shock. TOY TRANSFORMER MODEL: CW-80 INPUT: 120V AC, 60Hz OUTPUT: 18V AC, 80W For the safety of children, the toy transformer must be periodically examined by parents...
  • Page 7 électriques, des précautions doivent être observées lors de la manipulation et de l'utilisation pour éviter les chocs électriques. TRANSFORMATEUR JOUET MODÈLE: CW-80 ENTRER: 120V AC, 60Hz EXPORTER: 18V AC, 80W Pour la sécurité des enfants, le transformateur de jouet doit être examiné périodiquement par les parents, ce qui peut entraîner un risque d'incendie, d'électrocution ou de blessure (comme...

  • Page 8: Wiring Your Cw-80 Transformer

    16-gauge wire to con- nect your CW-80 Transformer to the track. Use the stripped ends of the wires, or spade-shaped connectors on all CW-80 Transformer connections, with no more than two wires on each terminal.
  • Page 9 4. Attach a third wire to the Transformer terminal labeled “B” and connect it to your accessories. 5. Attach a final wire from your accessories to the Transformer terminal labeled “U”. 6. Plug the CW-80 Transformer into your wall outlet (120 volts). TRACK ACCESSORY 0-18 VAC...

  • Page 10: Connecting The Fastrack Terminal Section

    TRACK posts. Two wires are attached to the underside of the FasTrack terminal section (available separately, 6-12016). Attach the spade-shaped connectors at the ends of these wires to the CW-80 Transformer. Be sure that the connections are secure. Follow these steps and refer to Figure 3.

  • Page 11: Operating Your Trains With The Cw-80 Transformer

    The Indicator Light will be green during normal operation. The light will change to red and flash if you exceed the power limit of the CW-80. The light will stay red and stop flashing if the power limit is exceeded for more than three seconds.
  • Page 12 Do not activate horns, whistles, or bells on RailSounds-equipped locomotives until track power has been turned on for a few moments, or a continuous horn/whistle or bell sound may occur. To correct this problem, simply turn off the CW-80 Transformer, then turn it back on.

  • Page 13: Setting The Accessory Output

    Setting the accessory output ake control of your Lionel empire with your CW-80 Transformer! You choose how much power your accessories need. Your CW-80 Transformer features a programmable accessory output. The ability to control the voltage allows you to set the speed of your accessory motors and the inten- sity of your lights.

  • Page 14: Powering Your Layout With The Cw-80 Transformer

    Powering your layout with the CW-80 Transformer our CW-80 Transformer provides a total output of five amps. The track outputs will deliver all of this power to the track when no accessories are connected to the Transformer. Keep in mind that connected accessories borrow some of this power. For example, if the accessories require two amps of the total five-amp capacity of the Transformer, you have three amps available for track power.

  • Page 15: Troubleshooting

    Switch the wire connections at the Lockon or Controller Terminals. Be sure that the U post is con- nected to the outside rail and the A post is connected to the inside rail. The following Lionel marks are used throughout this Owner’s Manual and are protected under law. All rights reserved.

  • Page 16: Limited Warranty/Lionel Service

    Lionel LLC or any Lionel Authorized Service Station MUST be accompanied by the original receipt for purchase (or copy) from an Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
