For Safety Using Thank you for purchasing our U-8226 cooling ang heating shock Controller. For proper and effective use of full functions of this instrument, please read and understand this instruction manual well before use. To ensure safety in handling the instrument, please be sure to observe the following warnings/cautions as well as the precautions in this manual.
Page 3
[caution] (1)Please deliver this instruction manual to the final user. (2)Be sure to read this instruction manual before handling the instrument. (3)If you find any questions, errors or omissions, please inform our sales representative. Instruction (4)When you have read this instruction manual, store it safely near the instrument. manual (5)If it is lost, stained or damaged by accident, please inform our dealer where you purchased the instrument or our sales representative.
Table of Contents 1. Installation 1.1.System diagram 1.2 Wiring 1.3 Relay board wiring 2. Menu Overview 3.MONITOR screen 4.MODE SET Screen 4.1 Choose execute pattern 4.2 Execute reserved start time or not 4.3 Execute reserved stand by time or not 4.4 Execute return ambient tempature or not 4.5 Execute Power down or not 5.DEFROST screen...
Page 5
9. Parameter explanation and setup 9.1. How enters “the initial period setup” 9.2 How to change a password 10. Initial period setup 1 10.1 High/low temperature control cycle setup 10.2 PID Setup 10.3 Linear adjust 10.4 Relay output number setup 10.5 Wait function setup 11.
1. Installation 1.1 System diagram Test device DI/DO board Controller PC RS-232C RS-485 1. Controller body connect to DI/DO board. 2. Com port connect to PC. 1.2 Wiring AC power DI/DO Board RS232 Port Transmission output Sensor input (Thermocouple)
1.3 Relay board wiring Number Number Number Back side of product H.ROOM CONV TROUBLE1 H.DUMP. OP -2~3.2VDC TROUBLE2 H.DUMP. CL L.ROOM CONV -2~3.2VDC TROUBLE3 R.DUMP. OP TROUBLE4 R.DUMP. CL T.ROOM CONV -2~3.2VDC TROUBLE5 L.DUMP. OP TROUBLE6 L.DUMP. CL TROUBLE7 H.FAN TROUBLE8 R.FAN TROUBLE9...
Page 8
2. Menu Overview The menu provides all basic operation and setting, It is conventient to choose any function that users need. According to run time, users can know how many Company data time have already spend. 2.1 Monitor A. SV, PV, a program type status. B.
3. MONITOR screen explaining When users have already setup program, the monitor screen provide users to (RUN),(STOP),(ADVANCE), (PAUSE),(HOLD) the programs. The users can see three areas, It includes Low room, High room, Test room. Also can see the present output percent ratio and more the others details. 4.
4.2 Execute reserved start time or not There have two execute methods in reserved start time. RUN: Normal setting, give up reserved start time. Ready: Reserved start time, Month/Day/Hour/Minute. 4.3 Execute reserved stand by time or not When a program have finished running , users can choose TEST END or STANBY . If a user choose TEST END ,when a program have finish running, then a program will test end.
4.4 Execute return ambient tempature or not When a program have finished running , depend on a user demand, back to ambient temp or not. Ambient temp setup range:0~50˚C.Factory default:15~35˚C. 4.5 Execute Power down(Black out resume) or not When a controller is running a program, because unknown factors then a controller power off, after restarting, there are three situations can be selected.
5. DEFROST screen explaining Setup auto defrost function, defrost temperature, defrost time, end defrost. Notice: Auto defrosts or manual defrost is only exist in high temp. 5.1 Auto defrost function Cycle: Calculate auto defrost by cycle. Time : Calculate auto defrost by time. Off : Turn off auto defrost function.
5.3 Defrost time When defrosts the temperature to arrive, defrosts the delay time only then to start to calculate, generally suggested that the time is 5~10 minutes. 5.4 End defrost Users may suppose when the settled experiment ended, whether needs once more to carry out one time to defrost the movement.
6. PROGRAM screen explaining There are four kinds of program to be selected. such as 2Zones,3Zones,Step,Link. Program screen 6.1 Special items for Programs setup 6.1.1 When a program is running, get into stored program can’t change a running program(Red color). 6.1.2 After setup a new program, remember back to MODE SET screen, setup all of function that you need.
6.2 Program type 6.2.1 2 ZONE Pattern(Program) When test condition between heating and cooling, please choose 2ZONE Pattern(Program). Low temp Start Cool Heat start High temp Start Heat Cool start 6.2.2 3 ZONE Pattern(Program) When test condition between heating and ambient temp and cooling, please choose 3ZONE Pattern(Program).
6.3 2 Zone pattern set When test condition between heating and cooling. 2Zone setup 6.3.1 Test name type in Users can type in any test name that they like. Test name make a program easy to remember. 6.3.2 Patterns number Choose Patten number before others setup, because pattern number is different, then setup will be different.
Page 17
6.3.3 Patterns cycle Pattern cycle that mean how many times in running, range limit in 1~9999. 6.3.4 Start test from… Start according to the demand by high temperature or low temperature starts to test. 6.3.5 Wait temp Setup wait temp in high temp or low temp, when temp achieve wait temp, a controller will get into wait mode.
Page 18
6.3.6 Delete a pattern Delete a pattern according to user’s demand. 6.3.7 setup a pattern operate condition Setup pattern operate condition, it include test temperature, spend time, pre wait range, wait mode on/off,time signal on/off. 6.3.8 Running a pattern After setup all the others settings, then push RUN button, the screen will jump to MONITOR screen, start running a program.
6.4 3 Zone and Step Because 3Zone and Step, their setup are the same with 2Zone, so we don’t explain them in here, only show photos in below. Step setup 3Zone setup 6.5 Link pattern Link pattern combine 2 zone, 3zone,step.In Link pattern screen have six block, provide users to input 2 zone,3zone,step programs.
Page 20
7.TROUBLE HISTORY screen explaining In the screen, you can see trouble message that ever happen in the past. Trouble message include trouble name and date/time. When a controller has an error, it will appear a trouble message, and then users can push RST button back to normal system. That trouble message will save to trouble history.
8.OTHERS screen explaining This screen provide users to adjust system clock, change language, setup back light, adjust LCD contrast, record maintenance, change machine ID, view firmware version. 8.1 Time adjust Adjust a system clock, YY/MM/DD/HH/MM. 8.2 Language change Change language between Chinese and English. 8.3 Back Light on Back light means if users don’t touch panel too long time, the screen will get into dark.
9. Parameter explanation and setup 9.1 How enters “the initial period setup” The following chart, after 1, 2 orders will hold back touches controls the screen to appear the password picture, after this time please input the password to press the enter key to enter. Picture 1 Picture 2 ※...
Page 23
9.2 How to change a password In the OTHERS screen, after 1, 1, 2, 3, 4, 1, 4 orders will hold back touches controls the screen to appear the password picture. 1. Picture left bottom corner 2. Picture left top corner 3.
10. Initial period setup 1 10.1 控制周期-The high low temperature control cycle setup (in 01-99 second scope may establish) This part will involve the control sensitivity, the controller rests on gap time of cycle decision output the hypothesis. Example 1: SSR (voltage) outputs, the temperature control cycle is 1 second, the controller demonstration output percentage is 40%, its significance is: SSR output ON 0.4 second, OFF 0.6 second.
Page 25
10.2.1 PID control movement direction Fixes for the counter movement (heating) [REVERSE] 10.2.2 PID ZONE division chart and case 【1】 【2】 【3】 【4】 【5】 【6】 -200 【1】 :SV < T1 【2】 :T1 ≦ SV < T2 【3】 :T2 ≦ SV < T3 【4】...
Page 26
10.2.4 AUTO TUNING method In carries out the high temperature test perhaps the low temperature test, after 1, 2 orders holds back touches controls the screen, namely can in the picture white block place appearance “TUNING and the start” string; So long as clicks starts the key, then the controller acts according to the system immediately the condition, makes PID the self regulating to decide the movement;...
Page 27
10.3 線性回歸- Linear adjust This function supplements and corrects for temperature SENSOR, may revise gets older SENSOR the error or revises the non-linear curve for the linear curve; The preheating area temperature, the precooling area temperature, the test area temperature, the freezer temperature have 5 adjusting points individually.
Page 28
10.4 出力 RELAY No. 設定 – Relay output number setup The RELAY output, the altogether 22 spots (No.1 ~ 22), may change the output position willfully. May cut the function to be as follows: DAMPER HIGH OPEN、DAMPER HIGH CLOSE、DAMPER ROOM OPEN、DAMPER ROOM CLOSE、DAMPER LOW OPEN、DAMPER LOW CLOSE、FAN HIGH、FAN ROOM、FAN LOW、TIME SIGNAL 1、TIME SIGNAL 2、CONT、REF.
10.5 待機設定- Wait function setup 1. 預熱待機溫度-Preheating waiting temperature You may depend on condition or the system ability of the experimental establish the preheating area to wait for an opportunity the temperature. May establish the temperature range: - 00 ~ - 99˚C. 2.
Page 30
11.1 N2GAS 延遲時間設定- N2GAS delay time setup Setup scope: 0 ~ 99 minutes 11.1.1 Acts the condition The high-temperature test or the normal temperature experiment ended, carried out toward the cold temperature test, “N2GAS” the output was only then effective. 1.
Page 31
11.2.1 Acts the condition 1. Cold temperature test condition REF.1 output contacts ON time, against perspiration output contact “ON” 2. High-temperature test or normal temperature experiment condition The test area PV value < [against perspiration initial temperature], against perspiration output to contact ON.
Page 32
11.3.2 Freezer movement condition The freezer output1(REF.1):Starts from the controller starts, the output contact has maintained at “ON” condition. The freezer strives .2(REF.2): After freezer .1 output contacts “ON”, the freezer temperature's PV value is equal to when or is smaller than “REF.2 the movement temperature SV value”, the freezer .2 output contacts have maintained at “ON”...
Page 33
11.3.4 Freezer movement characteristic chart 【Freezer 1 output】 Again starting time [REF.1 starts again prevents time]≦[again starting time]Condition REF 1 starts again prevents the time Freezer 1 outputs [REF.1 starts again prevents time]>[again starting time]Condition REF 1 starts again prevents the time Freezer 1 outputs This sector OFF [STOP][PAUSE][END]...
Page 34
11.3.5 CONT 出力- CONT output 1. Setup 1-1. Controls the range of validity. LSV :-99.9 ~ 99.9˚C. MSV:-99.9 ~ 99.9˚C. 1-2. Operating point (almost) scope Lu:0.0 ~ 9.9˚C. Hd:0.0 ~ 9.9˚C. 1-3. Movement choice of direction HIGH or LOW 2. Control requirement “CONTROL”...
Page 35
11.4 DAMPER 出力設定- DAMPER output setup 延遲時間 11.4.1 - Delay time 1. May scope of the setup: 0 ~ 9 seconds 2. Movement definition: DAMPER output in cut time (i.e. when experimental cut), output of contact after the corresponding must wait till establishes the delay time which arrives, only then output “ON”.
Page 36
出力動作 11.4.3 - Output movement :Maintains or relieves Output contact choice “ON/OFF” time, this function is only then effective; If chooses “ON” time, then the output movement maintains at “maintains” the condition. 1.保持- Maintenance The correspondence enters the strength contact arrives locates, the output movement maintains “ON”...
Page 37
11.4.4 DAMPER movement and characteristic chart ( ●=OPEN,X=CLOSE ) Revolution Normal High Maintains warm output temp temperature DEFROST stop temp test test waiting waiting test high DAMP. 1 × × ● × × × temperature test ● normal DAMP. 2 ×...
Page 38
< Movement choice elementary action> Above-mentioned, output contact choice[ON/OFF]Time, this function is only then effective. (Maintains) condition (Relieves) condition Opens Closes Opens Closes OPEN output CLOSE output OPEN input CLOSE input ※Figure above expression delay time = 0 second condition, experimental cut at the same time DAMPER output “ON”.
Page 39
FAN movement The FAN movement and the DAMPER output setup related association, acts the data sheet to be as follows: <Output contact choice: “ON/OFF”/output movement: “relieves”> 1. In STOP 2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER CLOSE OPEN CLOSE OPEN CLOSE OPEN 3 ZONE LIMIT STEP...
Page 40
2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER 3 ZONE CLOSE OPEN OPEN LIMIT CLOSE NEUTRAL HIGH High temp test NEUTRAL ROOM OPEN Test wait NEUTRAL OPEN 2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER 3 ZONE OPEN OPEN CLOSE LIMIT NEUTRAL HIGH OPEN temp test NEUTRAL...
Page 41
2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER 3 ZONE CLOSE OPEN CLOSE OPEN CLOSE OPEN LIMIT CLOSE NEUTRAL HIGH Defrosting OPEN 、 CLOSE High NEUTRAL ROOM Temp OPEN Pre-heating CLOSE NEUTRAL OPEN <Output contact choice: “ON/OFF”/output action: “maintains”> 1. In STOP 2 ZONE DAMP.HIGH DAMP.ROOM...
Page 42
2. In REVOLUTION 2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER CLOSE OPEN CLOSE OPEN CLOSE OPEN 3 ZONE LIMIT CLOSE Pre-warm NEUTRAL HIGH waiting OPEN CLOSE Maintains NEUTRAL OPEN CLOSE waiting NEUTRAL OPEN 2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER CLOSE OPEN CLOSE OPEN CLOSE...
Page 43
DAMP.HIGH DAMP.ROOM DAMP.LOW 3 ZONE DAMPER OPEN CLOSE OPEN LIMIT NEUTRAL HIGH OPEN Normal CLOSE temp NEUTRAL test ROOM NEUTRAL OPEN 2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER OPEN OPEN OPEN 3 ZONE LIMIT NEUTRAL HIGH Defrosting OPEN 、 High NEUTRAL ROOM Temp OPEN...
Page 44
<Output contact choice: “opens”> 1. In STOP 2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER CLOSE OPEN CLOSE OPEN CLOSE OPEN 3 ZONE LIMIT STEP CLOSE NEUTRAL HIGH In STOP OPEN In PAUSE CLOSE In FINISH NEUTRAL ROOM OPEN INTERRUPT CLOSE NEUTRAL OPEN 2.
Page 45
2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER CLOSE 3 ZONE LIMIT CLOSE NEUTRAL HIGH High temp NEUTRAL test OPEN NEUTRAL OPEN 2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER CLOSE 3 ZONE LIMIT NEUTRAL HIGH OPEN temp NEUTRAL test OPEN CLOSE NEUTRAL DAMP.HIGH DAMP.ROOM DAMP.LOW 3 ZONE...
2 ZONE DAMP.HIGH DAMP.ROOM DAMP.LOW DAMPER 3 ZONE LIMIT NEUTRAL HIGH Defrosting OPEN 、 High NEUTRAL Temp OPEN Pre-heating NEUTRAL OPEN 12. Initial period setup 3 12.1 溫度可設定範圍- The temperature may establish the scope 高溫試驗-High-temperature test: 0.0 ~ 320.0˚C ※Default factory setting value: 0.0 ~ 300.0˚C 低溫試驗-Cold temperature test: - 200.0 ~ 100.0˚C ※Default factory setting value: - 199.9 ~ 0.0˚C...
Page 47
12.2 異常設定- Unusual setup 接點入力 - Contact input 1. 編集-Arranges the collection (unusual name hypothesis) Choice “half-angle” time, may edit 28 writing most greatly (British digit/symbol); Choice “double-byte” time, may edit 14 writing most greatly (Japanese Chinese character/UK digit/symbol); May also “the half-angle” and “the double-byte” the blending edition. 2.
Page 48
異常 DAMPER - Damper unusual condition In this project the function has done fixedly for the heating chamber, the test chamber and the low greenhouse DAMPER movement unusual condition distinction. 1. Movement principle: “ON” starts from the DAMPER output to calculate, in establishes in the time horizon, DAMPER has not arrived at the localization, is TROUBLE occurs time.
Page 49
冷凍機保護 - Freezer protection In the project the function makes the unusual condition distinction which fixedly protects for the freezer 1. Movement principle: When has not satisfied the standard, TROUBLE condition occurrence. 2. Setup project : Divides into “arranges the collection”, “the unusual condition time”, “the movement compartment”...
Page 50
T1 movement chart Normal movement TROUBLE movement Freezer .1 outputs Freezer temperature PV REF.2 SV ±Acts the compartment TROUBLE occurs T2 movement chart TROUBLE movement Normal movement.1 TROUBLE movement.1 Freezer temperature PV REF.2 SV ±Acts the compartment TROUBLE occurs...
Page 51
Normal movement.2 TROUBLE movement.2 Freezer temperature PV REF.2 SV ±Acts the compartment TROUBLE occurs 12.3 異常歷史資料- Unusual historic information This function the unusual condition personal history which occurs in the past for the storage, may store up 100 material most greatly; When the personal history surpasses above 100, after advanced leaves the first principle which continues the retention has the unusual personal history.
Control requirement According to high temperature temperature SV and row of wind temperature SV the corresponding relationships, decided when [EXHAUST] does contact outputs. When high-temperature test execution, take high-temperature test temperature SV as the determination object; When preheating experimental execution, take preheating temperature SV as the determination object. Acts the condition HIGH MODE Controlled member temperature >...
Page 53
13.2 除霜溫度控制- Defrosting temperature control This function is refers to when the execution defrosts the movement, whether the precooling area temperature does control assigning. 1. 有-enable: Defrosted the conclusion temperature according to the hypothesis to carry out the PID control. 2.
14. Initial period setup 5 14.1 Experiment mode selection Divides into 2 ZONE, 3 ZONE, STEP, the LINK four kind of patterns; 14.2 積算通電時間-Accumulation time This function is the indicator makes a nulling operation movement to the controller current cumulative time. 15.
