T'nB BUDDY - Bluetooth TWS Earbuds Manual

Table of Contents

Contents

1 INCLUDED
2 CHARGING THE EARBUDS
3 SYNCING THE EARBUDS FOR THE FIRST TIME
4 PAIRING THE EARBUDS
5 TURNING HEADSET ON/OFF
- 5.1 USING 2 EARBUDS
- 5.2 USING EARBUDS SEPARATELY
6 MEDIA KEY FUNCTIONS
7 Documents / Resources
- 7.1 Download manual

INCLUDED

Contants package

These earphones are not water resistant. To prevent any damage or malfunction, do not expose the earphones to moisture, perspiration, leaks or splashes, and do not immerse the earphones under water.

CHARGING THE EARBUDS

The earbuds come with a built-in rechargeable battery.
Before using it for the first time, we recommend you charge the battery fully. Only use the supplied USB cable to charge the earbuds.
A full charge of the battery takes around 1 hour for each earbud. When the battery is fully charged, the LED light will turn blue. Disconnect the earbud at this point. The earbud will then be ready for use.
When the battery is low, the LED will flash red and emit three tones. When this occurs, please recharge the earbud.
When using your earbuds with an iPhone, the top right comer will indicate your earbuds battery life.
Charge

SYNCING THE EARBUDS FOR THE FIRST TIME

Ensure both earbuds are turned off.
Press the multifunction button 1 second on both earbuds to turn them both on.
Press and hold the multifunction buttons for 8 seconds on both earbuds simultaneously.
Wait for 3 seconds until both earbuds flash blue. This indicates that your earbuds are now synced together.

PAIRING THE EARBUDS

After you have synced your earbuds together, follow the below instructions to pair your earbuds to your smart phone or tablet.
Ensure the earbuds are turned off. If they are not, please turn off the earbuds first before pairing.
On the earbud you wish to use, press and hold the multi-function button for 8 seconds until the red and blue LED flash alternate. This will indicate your earbud is now in pairing mode.
Ensure Bluetooth is enabled on your phone or music device. Refer to the manufacturer's instructions for how to enable Bluetooth on your device.
Place the earbuds and the Bluetooth device to which you would like to pair it within the operating distance. We recommend keeping the two devices no further than 3 feet apart. Once you have activated Bluetooth on your device, select the earbuds «TNB BUDDY" from the list of available Bluetooth devices.
If required, enter the PIN code «0000» and confirm the entiy. Please note, pairing mode on the earbuds will last for two minutes. If no devices are paired after two minutes, the earbuds will automatically return to standby mode.
If pairing is unsuccessful, turn off the earbuds first and repair following the aforementioned steps. Once you have paired the earbuds with a device, the earbuds will remember this device and will pair automatically when the device's Bluetooth is activated and in range. You do not need to re-pair any previously connected devices. Your earbuds can pair up to two multi-point devices. You can reconnect a previously paired device without going through the pairing or PIN process on up to two devices.
Once your earbud is successfully paired with your smart phone or tablet, turn on your second earbud: press and hold the multifunction button on your second earbud for 3 seconds. The LED on the second earbud will flash blue once to indicate it is synced to your firet earbud.
During use, the battery life of your earbuds is visible on your iPhone or iPad screen.

TURNING HEADSET ON/OFF

USING 2 EARBUDS

Power On:
Using either earbud, press and hold the multi-function button for 3 seconds. You will hear a «Beep «. On the second earbud, press and hold the multifunction button for 3 seconds, you will hear a «Beep". The LED on the second earbud will flash red once and flash blue periodically, this indicate it has paired with the first earbud.

Power Off:
On either earbud, press and hold the multifunction button for 3 seconds until the LEDs stops flashing. You will hear a "Beep" and both earbuds will turn off.
In order to save power, the earbuds will automatically turn off if not paired with a device after 5 minutes.

USING EARBUDS SEPARATELY

Power On:
The earbuds can be used independently on separate devices. If you want to use them separately, select the earbud you want to use, press and hold the multi-function button for 3 seconds. This will power the earbud on and into its own pairing mode.

Power Off:
On the earbud you are using, press and hold the multifunction button for 3 seconds until the LED stop flashing. You will hear a «Beep" and the earbud will power off. In order to save power, the earbud will automatically turn off if not paired with a device after 5 minutes.
