User Manual
TOPBAND Energy
Lithium Iron Phosphate Battery with Smart Phone Monitoring
48V30AH
深圳市拓邦锂电池有限公司 / SHENZHEN TOPBAND BATTERY CO.,LTD
地址: 深圳市 宝安区 石岩镇 梨园工业区 拓邦工业园, 邮编 518108
Address: Topband Industrial Park, Liyuan Industrial Zone, Shiyan, Bao'an, Shenzhen, China, 518108.
邮箱/Email: li-power@topband-e.com
网址/ Web： ：www.topband.com.cn
Advertisement
Table of Contents
Related Manuals for Topband 48V30AH
Summary of Contents for Topband 48V30AH
- Page 1 Lithium Iron Phosphate Battery with Smart Phone Monitoring 48V30AH 深圳市拓邦锂电池有限公司 / SHENZHEN TOPBAND BATTERY CO.,LTD 地址: 深圳市 宝安区 石岩镇 梨园工业区 拓邦工业园, 邮编 518108 Address: Topband Industrial Park, Liyuan Industrial Zone, Shiyan, Bao'an, Shenzhen, China, 518108. 邮箱/Email: li-power@topband-e.com 网址/ Web： ：www.topband.com.cn...
- Page 2 1. Safety /安全 1.1 Instruction /说明 Please read the user manual carefully before installation, operation and maintenance, and pay attention to various warning boards and warning statements on the equipment. Please keep it for future reference after reading the user manual, 请在安装、操作和维护前仔细阅读本手册，并注意设备上的各种警示牌及警示语句。本手册阅读后请妥善保存，...
- Page 3 warranty. 在将电池组连接到您的设备之前，检查电压，并确保他们在您的设备规格的限制之内。不遵守这些规格会使 你的保修无效。 Installation / 安装过程中: • Personnel familiar with the electrical specifications of the country or region are required to install the battery pack. For best safety, follow the steps described in this manual 需要熟悉所在国家或地区电气规范的人员才能进行电池组的安装。 为了最佳的安全， 请遵循本手册中描述的步骤 • The ambient conditions given in the product documentation must be observed. 必须遵守产品规格书中规定的环境条件。...
- Page 4 请按照电池组所在国家或地区的法律法规处理包装和更换部件。 Do not dispose the battery with normal domestic waste. 不要将电池与日常生活垃圾一起丢弃。 2. Introduction to the TOPBAND series battery/TOPBAND 系列电池简介 2.1. Key Features/主要特点 • a、LiFePO4 composition – provides exceptional safety and longevity LiFePO4 成分–提供卓越的安全性和寿命...
- Page 5 2.3 Functional characteristics/ 功能特性 Item Specification Item Specification Rated voltage 51.2V Size 260*180*283mm Rated capacity 30AH Communication Standard Charging voltage 58.2V~58.6V Weight 12.5KG charge：0℃-50℃ Max continuous charging current Working temperature dsicharge：-20℃-65℃ Standard charging current Maximum continuous discharge Short circuit protection 500A/500ms current <3%/month 待机模式...
- Page 6 The red light indicates that the fault is displayed. Under normal conditions, the indicator is not on. When a fault occurs, the indicator is on. Green light represents: it represents different SOC according to different lighting modes. ``LED 指示灯，一个红灯、一个绿灯 红灯代表：故障显示，正常情况下该指示灯不亮，当发生故障时，该指示灯亮起。 绿灯代表：根据不同的亮灯方式，代表不同...
- Page 7 Check the solar regulator you intend to use has a dedicated lithium charge setting that meets the above charging requirements. A solar regulator without a lithium charge setting may be used to charge the TOPBAND series battery. However, it must be set to charge no higher than58.4V and then MUST be switched off once the TOPBAND series battery is fully charged.
- Page 8 A DC-DC charger without a lithium charge setting may be used to charge the TOPBAND series battery. However, it must be set to charge no higher than 58.4V and then MUST be switched off once the TOPBAND series battery is fully charged. DO NOT leave a DC-DC charger switched on without a suitable lithium charge setting once the battery is fully charged.
