LiFePO4 Battery Specification
SHENZHEN TOPBAND NEW ENERGY CO.,LTD
Address: Topband Industrial Park,Liyuan Industrial Zone,Shiyan,Bao'an,Shenzhen,
China,518108.
Web: www.topband.com.cn
Registered
Checked
Approved
Issue Date
Issue Version
Issue number
版本：V00
Model:
TB1250N-T500W
Dengzhaowei
Lili
2017-06-28
V00
Customer
Customer model
Customer reback:
Page 1 of 6
Advertisement
Table of Contents
Related Manuals for Topband TB1250N-T500W
Summary of Contents for Topband TB1250N-T500W
- Page 1 LiFePO4 Battery Specification Model: TB1250N-T500W SHENZHEN TOPBAND NEW ENERGY CO.,LTD Address: Topband Industrial Park,Liyuan Industrial Zone,Shiyan,Bao'an,Shenzhen, China,518108. Web: www.topband.com.cn Registered Dengzhaowei Customer Checked Customer model Approved Lili Customer reback: Issue Date 2017-06-28 Issue Version Issue number 版本：V00 Page 1 of 6...
- Page 2 Specification revisal record Date Contents Revised Remarks 2017-06-2 First issue 版本：V00 Page 2 of 6...
-
Page 3: General Information
General information The portable solar power station is all-in-one system, combing the solar controller, inverter, lithium ion batteries and BMS. It is developed for power shortage remote mountain area, health care, agriculture and animal husbandry, military, outdoor camping, scientific investigation and disaster emergency applications, etc. It is simple operation and convenient carrying, it could be used for household and office appliances, electrical equipment in public place and rescue stations, including television, audio, electronic games, lighting, fans, laptops and mobile phone, etc. - Page 4 Product structure description Handle: easy to carry Front door cover: Please close the door cover when not in use to prevent water and dust. Status indicators: The light is blinking green when charging the product. The light is green when the system is running. The light is red when the system fails. Capacity indicators: The five lights means the capacity of battery.
- Page 5 Communication interface: This interface communicates with computer via RS485. Specification (@Initial temperature 25±5℃) Item Criteria Remarks Nominal 50Ah Capacity DC Charge Voltage: 13.5V-18V Current: 5A Solar Charge Voltage: 18V Current:＜10A AC Adapter Voltage: 13.5V Current: 6A Charge Max. Continue Output Power: 400W/500W Output Voltage: AC220V/110V土10% AC Output...
- Page 6 BMS Management system Over current protection: Status indicator light is red when charging current is greater than 10A. Low-voltage protection: When the battery voltage is lower than 9.2V, BMS automatically close all output function, status indicator light turns red. You need to turn off the switch, and then turn on the switch to make the product recover to normal.
-
Page 7: Working Environment
* Non-professional personnel shall not open the products and remove parts, otherwise it's at your risk; * Due to the large output power of this product, the large load plug or short circuit may cause a slight spark in the output state, so it is forbidden to use the product under the environment of flammable and explosive gas;... -
Page 8: Storage And Transportation
Please read and follow the specification and caution remarks on battery surface before using the battery. Improper use may cause heat, fire, rupture, damage or capacity deterioration of the battery. SHENZHEN TOPBAND NEW ENERGY CO., LTD will not responsible for any accidents caused by the usage without following our specification. - Page 9 of a discharge, battery should maintain a certain capacity, maintain the voltage at 50% state of SOC. Other Chemical Reaction Because batteries utilize a chemical reaction, battery performance will deteriorate over time even if stored for a long period of time without being used. In addition, if the various usage conditions such as charge, discharge, ambient temperature, etc.
