Cinegears GHOST EYE 1000M Manual Book

Wireless hdmi/sdi video transmission system

Advertisement

Quick Links

GHOST EYE WIRELESS HDMI/SDI
VIDEO TRANSMISSION SYSTEM
600M/1000M/800T
GHOST EYE
MANUAL BOOK
© 2016 Cine Gears INC. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GHOST EYE 1000M and is the answer not in the manual?

Questions and answers

Summary of Contents for Cinegears GHOST EYE 1000M

  • Page 1 GHOST EYE WIRELESS HDMI/SDI VIDEO TRANSMISSION SYSTEM 600M/1000M/800T GHOST EYE MANUAL BOOK © 2016 Cine Gears INC. All Rights Reserved.
  • Page 2 Trademarks Ghost-Eye Wireless Video Transmission SystemsTM are trademarks of Cine Gears Inc. Web Interface. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, Cine Gears Inc. reserves the right to make changes to the products described in this docu- ment without notice.
  • Page 3 Information to the user The user’s manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equip- ment.
  • Page 4: Table Of Contents

    Ghost Eye Wireless Video Transmission Systems Specifications M-Series Transmitter M-Series Receiver T-Series Transmitter T-Series Receiver Product Features User Manual Setting Up the Unit Fan Motor Controls Channel Settings Setting Up the Intercom (800T) Troubleshooting Disclaimers About Cinegears © 2016 Cine Gears INC. All Rights Reserved.
  • Page 5: Cautions

    Cautions Warning Please read this user introduction manual to become familiar with the features of the Ghost-Eye series products before operation. Failure to operate the product correctly can result in damage to the product, or interference with other devices. This is a sophisticated product which must be operated with caution and common sense.
  • Page 6: Ghost Eye Wireless Video Transmission Systems

    Ghost Eye Wireless Video Transmission Systems Here at Cine Gears Inc., we supply some of the best wireless HD video transmitters and receivers available. During the development of Ghost-Eye units, we subjected our prototypes to rigorous testing on set with professional film crews, and took customer feedback and suggestions into serious consideration.
  • Page 7: Specifications

    Specifications ITEM SPECIFICATION 5.1-5.9(GHz)*Subject different regulations in different regions. Frequency range 2.4-2.483GHz with ISM band OFDM/40MHz for video Modulation method and Bandwidth GFSK/1MHz for intercom system 1080p 23.98/24/25/30/50/60 1080psf 23.98/24/25 Video Formats 1080i 50/59.94/60 Supported 720p 50/59.94/60 576p 576i 480p 480i Audio Formats PCM, DTS-HD, Dolby TrueHD Supported...
  • Page 8 Specifications Net Weight(with 400g antenna) Dimensions 142.5×76×24.3mm Temperature -10-50 (Operating); -40-80 (Storage) Receiver External Antenna 5G × 5pcs Antenna External Antenna 2G x1pcs (T series) Receiving Sensitivity -70dBm SDI Dual Output; HDMI Output; Mini USB; LEMO Power IN; Antenna RPSMA Socket; Functional Interface Power ON/OFF 800T and 800TC:...
  • Page 9: M-Series Transmitter

    M-Series Transmitter © 2016 Cine Gears INC. All Rights Reserved.
  • Page 10 M-Series Transmitter STRUCTURE OLED Display Displays information of channel, Video status and battery capacity. UP Button Channel + DOWN Button Channel - MENU Button Unlock the channel and Confirm the Selection Power ON/OFF Turn ON or OFF the transmitter SDI IN Connect to SDI Video Source SDI OUT(Loop Through) Connect to the your monitor or other...
  • Page 11: M-Series Receiver

    M-Series Receiver © 2016 Cine Gears INC. All Rights Reserved.
  • Page 12 M-Series Receiver STRUCTURE Antenna Connector x5 RPSMA connectors for antennas OLED Display Displays information of channel, signal strength and battery capacity. MENU Button Unlock and Confirm the Selection LEFT Button Channel - RIGHT/DOWN Button Channel + V+/UP Button Volume +, not use on this version V-/DOWN Button Volume -, not use on this version BAT-OUT...
  • Page 13 M-Series Receiver Connect to your SDI monitor or other DC IN(Lemo) *Support 9-18V Support 9-18V Battery Clip Support V-Mount battery Power ON/OFF Power on or OFF the receiver © 2016 Cine Gears INC. All Rights Reserved.
  • Page 14: T-Series Transmitter

    T-Series Transmitter © 2016 Cine Gears INC. All Rights Reserved.
  • Page 15 T-Series Transmitter STRUCTURE 15mm Front TALLY indicator(Red/Yellow) The indicator color will be same(RED/YELLOW) for Rear/ front and external TALLY 2G Antenna Connector SMA connector for 2.4G antenna OLED Display Displays information of channel, Video status, signal strength; Battery voltage indicator, MENU information VOL +/UP Button Normally, it is a Volume +.
  • Page 16 T-Series Transmitter Connect to Video Source which supports 3G-SDI, HD-SDI,SD-SDI SDI OUT(Loop Through) Connect to other SDI equipment if need HDMI IN Connect to HDMI video source DC power IN(Lemo) Support 9-18V 5G Antenna Connectors RPSMA connectors for 5G antennas Battery Clip Battery compartment, for F550/F970 battery Rear TALLY(RED/YELLOW)
  • Page 17: T-Series Receiver

    T-Series Receiver © 2016 Cine Gears INC. All Rights Reserved.
  • Page 18 T-Series Receiver STRUCTURE 5G Antenna Connectors RPSMA connectors for antennas OLED Display Channel, signal strength, battery voltage, audio Volume and MENU. MENU Button Unlock and Confirm the Selection LEFT/UP Button Select Channels RIGHT/DOWN Button Select Channels V+/UP Button Volume + V-/DOWN Button Volume - BAT-OUT...
  • Page 19 T-Series Receiver Connect to an external headphone HDMI OUT Video output, connect to HDMI receiver or device SDI OUT Video output(the video output is same from the two SDI interface), connect to SDI receiver or device DC Power IN(Lemo) Support 9-18V 2.4G Antenna Connector SMA connector for 2.4G antenna Battery Clip...
  • Page 20: Product Features

    Product Features Uncompressed 3G/HD/SD-SDI and HDMI Transmission Up to 1080p 50/60 uncompressed HDMI and SDI. Less than 1 millisecond latency There is no discernible video delay and can be used for real time on-location monitoring. Multicast support Support one transmitter to multiple receiver. Users can set the channel to pair the transmitter and receivers.
  • Page 21: User Manual

    User Manual 1. Fix the three antennas to the transmitter and arrange them to be a right angle as below figure to get better performance. 2. On transmitter side, when both SDI and HDMI source are inputted, the transmitter will automatically select the SDI source for transmission 3.
  • Page 22: Fan Motor Controls

    User Manual Transmitter Fix the three antennas (5G x2, 2.4G x1) respectively. Connect the SDI or HDMI video source to the “SDI IN”/”HDMI IN” of transmitter (when both SDI and HDMI video are inputted, it will auto select the SDI video for transmission). If needed, you can connect the SDI out (loop through) to other equipment as well.
  • Page 23: Channel Settings

    User Manual Channel Settings Both Transmitter and Receiver are set to the same channel by default. If you want to change to a new channel, please follow the instructions below. Note: Both transmitter and receiver must be set to the same channel to work. Changing Channel on Transmitter Power on the Transmitter Press the “MENU”...
  • Page 24: Setting Up The Intercom (800T)

    User Manual Setting Up the Intercom (for 800T only) After connecting the units, power on both Transmitter and Receiver. On the Transmitter side, you will hear sound from the receiver end if “TALK” is not pressed on converter box. When the “TALK” button is pressed and held, both the receiver end and the transmitter end can conversation normally.
  • Page 25: Troubleshooting

    User Manual Troubleshooting If the Receiver fails to output video correctly, follow the chart below to find possible causes and solutions. ISSUE SOLUTION Displaying “Waiting for Connection...” for a Prolonged Period Transmitter is not powered up. Turn on the transmitter. Transmitter or receiver is not placed Place the TX or RX correctly.
  • Page 26 User Manual No Signal Input to Receiver or TV/Monitor Receiver is turned off. Turn on the receiver. Receiver and TV are not connected. Connect receiver and TV/Monitor via SDI/HDMI input. TV/Monitor not switched to SDI/HDMI Switch TV/Monitor to SDI/HDMI input. input Bad cable connection of receiver or Disconnect and re-connect the SDI/HDMI...
  • Page 27: Disclaimers

    Disclaimers FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 28 You agree that you are responsible for your own conduct and any content created while using CINEGEARS products, and for any consequence thereof. You agree to use this product only for purposes that are proper and in accordance with local regulations, terms and any applicable polices and guidelines.
  • Page 29: About Cinegears

    About Cinegears Cine Gears Inc. is an industry leading company that designs and manufactures digital wireless follow focus systems, lens control systems, camera motion control systems and accessories for film and broadcast industry. As a big believer in the power of creativity and ideas, we designed the Pegasus cablecam, the wireless motor drive that integrated a built in wireless transmitter, and the wireless finger wheel controller.
