Cinegears Ghost-Eye 150M User Manual

Ghosteye m series
Hide thumbs Also See for Ghost-Eye 150M:

Advertisement

Quick Links

Download this manual
WIRELESS HDMI/SDI
GHOSTEYE
VIDEO TRANSMISSION SUITE
TM
www.ghosteye.com
GHOSTEYE M-SERIES
MANUAL BOOK
© 2016 Cine Gears INC. All Rights Reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ghost-Eye 150M and is the answer not in the manual?

Questions and answers

Related Manuals for Cinegears Ghost-Eye 150M

Summary of Contents for Cinegears Ghost-Eye 150M

  • Page 1 WIRELESS HDMI/SDI GHOSTEYE VIDEO TRANSMISSION SUITE www.ghosteye.com GHOSTEYE M-SERIES MANUAL BOOK © 2016 Cine Gears INC. All Rights Reserved...

  • Page 2: Electrical Considerations

    Cautions This instructional user manual and all the related documents are subject to change at the sole discretion of SFAIMO (Guangzhou SunFieldAimo Electron Technology Co., Ltd.). SFAIMO inc. reserves the right to make changes and improvements to any of the products described without prior notice.
  • Page 3 HD video broadcast with virtually no new technologies, but to improve on our existing designs. At Cinegears we are not allowing us to expand to our current size, with 3 branches; our original Canadian branch, a branch in the USA, a branch in China, and service centers around the globe.
  • Page 4 Ghost-Eye HD Wireless Video Transmission Systems Here at Cine Gears Inc., we supply some of the best wireless HD video transmitters and receivers available. During the development of Ghost-Eye units, we subjected our feedback and suggestions in to serious consideration. After careful consideration, Ghost-Eye products have integrated all the in-demand wireless video transmission in the form of our unique Ghost-Eye Wireless Video Transmission kits, across the transmission needs.
  • Page 5 WIRELESS HDMI/SDI GHOSTEYE VIDEO TRANSMISSION SUITE www.ghosteye.com GHOSTEYE 150M KIT © 2016 Cine Gears INC. All Rights Reserved...
  • Page 6 3G SDI/HDMI HD input, the receiver provides 3G SDI//HDMI output. The Ghost-Eye 150M suite has 2 external stick antennas on the receiver and 5 internal antennas inside the transmitter. The transmission suite functions in the 5.1-5.9GHz frequency band and can be flexibly configured to licensed or ISM band frequencies around the globe.
  • Page 7 About the 150M What is included ■       Waterproof custom-fit hard case (310mm*190mm*93mm)  © 2016 Cine Gears INC. All Rights Reserved...
  • Page 8 • Supports point to point, and point to multi points network topology, multiple receiver is supported with up to 4 receivers . • Cross compatibility between Cinegears Ghost-eye 100M, 300M, and 400M transmitter and receivers. • Support professional audio formats include Dolby True HD, DTS-master, etc.
  • Page 9 About the 150M ■ Diagram - Transmitter Transmitter 1) 1/4-20 Screw Hole 2) RP-SMA male antenna connector 3) Video input indicator, 1 yellow LED 4) Power indicator, 1 green LED 5) Frequency selection knob,0-9 6) SD/HD/3G SDI input 7) HDMI Input 8) DC power switch 9) DC input, LEMO 4-pin B series connector ©...
  • Page 10 About the 150M ■ Diagram - Receiver Receiver 1) 1/4-20 Screw Hole 2) LED status indication(4 blue LED for RSSI &1 LED yellow for POWER/VIDEO) 3) Frequency selection knob,0-9 4) SD/HD/3G SDI output 5) HDMI output 6) DC power switch 7) DC input, LEMO 4-pin B series connector ©...
  • Page 11 About the 150M ■Specifications: Transmitter Receiver SDI Input(BNC Female); HDMI Input SDI Output(BNC Female); HDMI Output (Type A female); 2 Antenna port(PR- Interface (Type A female); DC input SMA male); DC input Supply voltage range 6.5-16.8V DC 6.5-16.8V DC Power consumption <...

  • Page 12: Getting Started

    150M Installation Getting started 1) Ensure the video source output of the camera is OK, and the HD monitor is powered on and switched to connected video input port. 2) Ensure 2 TX antennas are installed, preferably with an orthogonal angle to each other for best RF performance, as in figure below.
  • Page 13 150M Installation 5) Ensure the frequency knobs of transmitter and receiver are set with the same number, this will make sure the transmitter and receiver work with 6) If the camera is on and video input is OK, TX side 'video' indicator will light 7) Before RX finished wireless link with TX, 4 “RSSI”...

  • Page 14: Frequency Selection

    150M Installation Frequency selection ■ The wireless suite works in the 5.1-5.9GHz frequency band and can be flexibly configured to other licensed or ISM bands to accommodate different global regions. The side panel of the transmitter features a frequency selection knob (see below illustration), which provides a maximum of 10 workable frequency channels, and supports a maximum of 4 simultaneous receiver units.
  • Page 15 WIRELESS HDMI/SDI GHOSTEYE VIDEO TRANSMISSION SUITE www.ghosteye.com GHOSTEYE 300M KIT © 2016 Cine Gears INC. All Rights Reserved...
  • Page 16 About the 300M ■ Product description The Ghost-Eye 300M Wireless HDMI/SDI Transmission Suite utilizes today's most advanced wireless video transmission technology, broadcasting uncompressed 3G SDI/HDMI HD video signals with zero delay up to 300 meters (line of sight). The suite includes one transmitter and one receiver;...
  • Page 17 About the 300M What is included ■       Waterproof custom-fit hard case  © 2016 Cine Gears INC. All Rights Reserved...
  • Page 18 • Supports point to point, and point to multi points network topology, multiple receiver is supported with up to 4 receivers . • Cross compatibility between Cinegears Ghost-eye 100M, 300M, and 400M transmitter and receivers. • HDMI 1.4 with EDID support •...
  • Page 19 About the 300M ■Specifications: Transmitter Receiver SDI Input(BNC Female); HDMI Input SDI Output(BNC Female); HDMI Output (Type A female); 2 Antenna port(PR- Interface (Type A female); DC input (4 Pin Lemo SMA male); DC input (4 Pin Lemo Female) Female) Supply voltage range 6.5-16.8V DC 6.5-16.8V DC...
  • Page 20 300M Installation Getting started 1) Ensure the video source output of the camera is OK, and the HD monitor is powered on and switched to connected video input port. 2) Ensure all 7 RX and all 2 TX antennas are installed, preferably with an orthogonal angle to each other for best RF performance, as in figure below.
  • Page 21 300M Installation Frequencey selection ■ The wireless suite works in the 5.1-5.9GHz frequency band and can be flexibly configured to other licensed or ISM bands to accommodate different global regions. The side panel of the transmitter features a frequency selection knob (see below illustration), which provides a maximum of 10 workable frequency channels, and supports a maximum of 4 simultaneous receiver units.
  • Page 22 WIRELESS HDMI/SDI GHOSTEYE VIDEO TRANSMISSION SUITE www.ghosteye.com GHOSTEYE 400M KIT © 2016 Cine Gears INC. All Rights Reserved...
  • Page 23 About the 400M ■ Product description The Ghost-Eye 400M Wireless HDMI/SDI Transmission Suite utilizes today's most advanced wireless video transmission technology, broadcasting uncompressed 3G SDI/HDMI HD video signals with zero delay up to 400 meters (line of sight). The suite includes one transmitter and one receiver;...
  • Page 24 About the 400M What is included ■       Waterproof custom-fit hard case  © 2016 Cine Gears INC. All Rights Reserved...
  • Page 25 • Support point to point, and point to multi points network topology, Multiple receiver is supported with up to 4 receivers . • Cross compatibility between Cinegears Ghost-eye 100M, 150M, and 300M transmitter and receivers. • Highest resolution 10bits color depth 4:4:4, 1080p 60FPS HDMI and SD/HD/3G SDI input and output, HDMI SDI cross conversion is supported.
  • Page 26 About the 400M ■ Diagram - Transmitter 1) LCD display 2) Channel selection button 3) HDMI/SDI selection button 4) OK button for option confirmation 5) Power supply in (Lemo, 6-17V) 6) HDMI input 7) SDI out (monitor loop) 8) SDI input 9) Antenna connectors 10) V-mount connection (optional) 11) 1/4"...
  • Page 27 About the 400M ■ Diagram - Receiver 1) LCD display 2) Channel selection box 3) HDMI/SDI selection button 4) OK button for option confirmation 5) SDI output 6) HDMI output 7) Antenna connectors 8) V-mount connections (optional) 9) 1/4" hot-shoe connection 10) 1/4"...
  • Page 28 About the 400M ■Specifications: Transmitter Receiver SDI Input(BNC Female); HDMI Input SDI Output(BNC Female); HDMI Output (Type A female); SDI LOOP Out; LEMO (Type A female); SDI LOOP Out; LEMO Interface (0B/2 core); POWER IN; RP5MA (0B/2 core); POWER IN; RP5MA Antenna;...
  • Page 29 400M Installation Getting started 1) Ensure the video source output of the camera is OK, and the HD monitor is powered on and switched to connected video input port. 2) Ensure all 7 RX and all 2 TX antennas are installed, preferably with an orthogonal angle to each other for best RF performance, as in figure below.
  • Page 30 400M Installation 5) Select the broadcasting channel via the "CH" button on both RX and TX, ensuring that both are set to the same channel. Press "OK" to confirm channel selection. When the network connection is established, the LCD display will display "LINK".
  • Page 31 400M Installation Frequency selection ■ The wireless suite works in the 5.1-5.9GHz frequency band and can be flexibly configured to other licensed or ISM bands to accommodate different global regions. The front LED panel of the transmitter features a frequency selection button (see below illustration), which provides a maximum of 4 workable frequency channels, and supports a maximum of 4 simultaneous receiver units.

  • Page 32: Troubleshooting

    Troubleshooting No output on display ■ installed correctly. Next, check ‘Video’ indicator. If TX ‘Video’ indicator is not lit, check SDI or HDMI cable is plugged in and the video source is ready. Finally, Poor quality output video ■ Ensure the SDI or HDMI input cable is properly connected, then check how many receiver-side ‘RSSI’...
