- Page 1 INSTRUCTION MANUAL AIR 31 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. days. tighten screws until the item is completely assembled. flammable/combustible chemicals. Be aware that moving parts can injure,crush and cut. If any parts are missing,broken,damaged,or worn,stop using this product until repairs are made and/or factory replacement parts are installed.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M3.5x60mm SCREW 12PCS+1spare 18PCS+1spare M3.0x16mm SCREW M3.5x25mm SCREW 2PCS+1spare 30PCS+1spare Spring latch M3.5x35mm SCREW 4PCS 6PCS+1spare M3.0x16mm SCREW Connect pieces 4PCS+1spare 2PCS... - Page 5 HARDWARE...
- Page 6 PARTS CARTON 1/2 Back panel of coop Middle panel of back pen Side panel of back pen Right panel of pen Ramp Roof of nest box...
- Page 7 PARTS Metal rod Hardware bag Perch 2PCS CARTON 2/2 Tray Divider panel Access door panel...
- Page 8 PARTS Back panel of nest box PVC Waterproof Strip Side panel of nest box Front panel of nest box Divider panel of nest box Bottom panel of nest box Coop roof Pen roof...
- Page 9 Side panel of front pen Middle panel of front pen Front panel of coop Back panel of coop Middle panel of back pen Right panel of pen Side panel of back pen...
-
Page 10: Product Assembly
PRODUCT ASSEMBLY ① Attach the front Part A to the front Part B by 3xP1. ② Ensure all corner line up before screwing together. ① Attach the back Part D to the back Part E by 3xP1. ② Ensure all corner line up before screwing together. - Page 11 PRODUCT ASSEMBLY Attach the divider panel Part G and access panel Part H to the front by 4xP2. Attach the back panel by 4xP2.
- Page 12 PRODUCT ASSEMBLY Attach the front Part C by 3xP1. Attach the back Part F by 3xP1.
- Page 13 PRODUCT ASSEMBLY Insert the perches Part L into the slots inside the front and back ① panel. Slide in the tray Part J. ② Screw the ramp Part ① K to the access panel Part H by 4xP7. Notice not to block with the sliding door. ② ...
- Page 14 PRODUCT ASSEMBLY Attach the side pen panel Part I by 6xP2. Attach Part N & O to the coop from INSIDE by 1xP6 each side.
- Page 15 PRODUCT ASSEMBLY Connect the nest box to the main coop from INSIDE by 2xP4 each side. Attach Part M by 4xP2.
- Page 16 PRODUCT ASSEMBLY Drop in bottom of nest box Part Q. Slide in divider Part P.
- Page 17 PRODUCT ASSEMBLY Attach the roof Part R by 6xP4. Attach the roof Part S by 4xP6.
- Page 18 PRODUCT ASSEMBLY Screw the roof hinge by 4xP4， Attach the roof Part T by 4xP6. Screw 2xP4 to the access panel Part H and then rotate the metal rod accordingly.
- Page 19 PRODUCT ASSEMBLY Attach the spring latch P5 to the door by 2xP4 each. ① (Notice the direction of latch) Attach Part U by 2xP3 ② Finish...
- Page 20 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
