- Page 1 INSTRUCTION MANUAL AIR 19 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x45mm SCREW M3.5x50mm SCREW 4PCS+1spare 20PCS+1spare M3.5x30mm SCREW M3.5x35mm SCREW 4PCS+1spare 8PCS+1spare M3.0x16mm SCREW M3.0x10mm SCREW 4PCS+1spare 2PCS+1spare Chewing Toy for gift Latch... - Page 4 HARDWARE M3.0x16mm SCREW M4.0x30mm BOLT 2PCS 4PCS+1spare...
- Page 5 PARTS Back panel Front UP panel Front down panel Front panel of pen Left panel Right panel Top panel of pen Back panel of pen Side panel of pen...
- Page 6 PARTS Metal ramp supporting Asphalt roofs Roof cap 2PCS Pen tray Ramp Upper hutch tray Casters without brakes Folding metal feeder Casters with brakes 4PCS 2PCS...
- Page 7 PARTS Bottom hutch tray...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY ① Attach front panel Part A, B & back panel Part C to the right panel Part E by 4xP2 one side and 2xP2 the other side. ② Notice there are predrill screws holes to direct. ① Attach left panel Part D to step 1 by 2xP2 one side and 4xP2 the other side. - Page 9 PRODUCT ASSEMBLY Screw the ramp Part M to the right panel by 4xP5. ① Attach the side pen! ② Screw the Part H to the Part F & Part G by 2xP2 each side.
- Page 10 PRODUCT ASSEMBLY Screw the metal ramp supporting board Part J inside the back panel of pen Part G by 2xP9. Attach the pen to the wood hutch by screwing 2xP1 each side.
- Page 11 PRODUCT ASSEMBLY Slide in the Upper tray N and bottom tray S, pen tray O. ① Screw the metal feeder Part R to the back panel by 2xP6. ② Put the chewing toy Part P7 into the cage anywhere you want.
- Page 12 PRODUCT ASSEMBLY Attach the top panel of pen Part I by 4xP2 screws. ① Screw the asphalt roofs Part L to the hutch by 8xP3. ② Notice to level up the roof line.
- Page 13 PRODUCT ASSEMBLY Screw the roof cap Part K to the roof by 4xP4. Attach top panel of pen and side panel of pen with 1xP8 by ① 4xP10 screws. Screw two brake casters Part Q to the 2 back legs, and one ② ...
- Page 14 PRODUCT ASSEMBLY Screw the 3 casters without brakes Part P to the front 3 legs. LOCKED OPEN Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
