Thank you for purchasing a RockBoard® MOD V2 - the new portal to your setup! The RockBoard® MOD V2 All-in-One Patchbays offer a simple solution to organize all the
connections to and from your effects setup, whether you are using a RockBoard® or any other brand pedalboard. The MODs are designed to route connections from
underneath your pedalboard to its front, in order to give you a central access point to your setup and tidy up your connections. Please note, that the MODs do not require any power,
and they do not distribute power. They are routing tools to organize your effects rig's connections.
1
There are 3 different „patchbay-only" versions of the MODs:
Page 1
Manuals for MOD V2 1+2+3 Thank you for purchasing a RockBoard® MOD V2 - the new portal to your setup! The RockBoard® MOD V2 All-in-One Patchbays offer a simple solution to organize all the connections to and from your effects setup, whether you are using a RockBoard® or any other brand pedalboard. The MODs are designed to route connections from underneath your pedalboard to its front, in order to give you a central access point to your setup and tidy up your connections.
Page 2
EXAMPLE SET UP POWER SUPPLIES AMP FOOTSWITCH POWER MAINS DC 2,1 x 5,5 mm barrel thru DC 2,1 x 5,5 mm barrel thru VOCAL FX OUT 2 OUT 1 5-pin DIN USB Type A AC IEC AC IEC USB Type A 5-pin DIN 6,3 mm / 1/4"...
