Summary of Contents for Daewoo DALPS18-1
- Page 1 DALPS18-1 Lithium pole saw USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. GENERAL OPERATING INSTRUCTIONS ....................3 2. GENERAL SAFETY INSTRUCTIONS ...................... 4 3. ASSEMBLY ............................... 9 4. TECHNICAL SPECIFICATIONS ......................16 5. EXPLODED VIEW AND SPARE PART LIST ................... 17 WARRANTY ............................... 20... -
Page 3: General Operating Instructions
1. GENERAL OPERATING INSTRUCTIONS Read and keep the general operating instructions These operating instructions belong to this cordless pole pruner (hereinafter also referred to as "device"). It contains important information on commissioning and operation. Read the operating instructions carefully, especially the safety instructions, before using the device. Failure to follow these operating instructions can result in serious injury or damage to the device. -
Page 4: General Safety Instructions
1. GENERAL SAFETY INSTRUCTIONS WARNING: Read all safety notices, instructions, illustrations and technical data with which this power tool is provided. Failure to follow the instructions below could result in electric shock, re and / or serious injury. Retain all safety notices and instructions for future use. The term "power tool"... - Page 5 • Do not overload the power tool. Use the power tool designed for your work. With the right power tool you can work better and more safely in the speci ed performance range. • Do not use a power tool with a defective switch. A Power tools that can no longer be switched on or off are dangerous and must be repaired.
- Page 6 handle. Holding the chainsaw in the reverse working position increases the risk of injury and must not be used. • The power tool may only be held by the insulated gripping surfaces, as the saw chain can touch hidden cables. Saw chains that come into contact with a live wire make metal parts of the power tool live and could give the operator an electric shock.
- Page 7 • Always use replacement bars and saw chains prescribed by the manufacturer. Incorrect replace- ment bars and saw chains can cause the chain to tear and / or kickback. • Follow the manufacturer's instructions for sharpening and maintaining the saw chain. Depth gauges that are too low increase the tendency to kickback.
- Page 8 retreat away from the falling branch. Before starting the chainsaw, make sure that no objects are touching the saw chain. Do not modify your chainsaw in any way. A rst aid kit with bandages for large wounds and a means of calling for help (e.g. a whistle) should be with the user.
-
Page 9: Assembly
3. ASSEMBLY Assembly of chain and sword. Risk of injury! If parts are missing or damaged, the device must not be operated until everything has been correct- ly replaced. Failure to heed this warning could result in serious personal injury. •... - Page 10 Mount additional handle 1. Use the Allen key 10 to unscrew the fastening screws on the additional handle 6 in an anti-cloc- kwise direction. 2. Remove the clamping plate. 3. Place the additional handle with the incline in the direction of the saw chain head 8 on the tube 11. 4.
- Page 11 Adjust the angle of inclination In order to enable an optimal working position, the saw chain head 8 can be inclined by 15° and 30°. 1. Press and hold the locking device of the inclination angle 18. 2. Set the desired angle of inclination. 3.
- Page 12 Remove the battery 1. Press and hold the battery release button. 2. Pull the battery out of the battery holder. If the battery cannot be removed easily, the battery release button was not pressed enough. Press the battery release button more rmly. Insert the battery 1.
- Page 13 • It is therefore essential to check the oil level on the level indicator regularly and every time you start working with the device. • Make sure that the container is always ¼ full so that there is enough oil for the respective project. 1.
- Page 14 Work instructions • Hold the device with both hands, with your thumb and ngers rmly gripping the handles. • Bring your body and arms in a position where you can withstand the kickback forces. • When working on a slope, always stand above or to the side of the branch you are sawing. •...
- Page 15 Remove blockages WARNING: Risk of injury! Unintentional switching on can lead to injuries. • Make sure that the device is switched off. • Disconnect the battery from the device. Remove blockages 1. Make sure the device is turned off. 2. Remove any jammed material from the saw chain 5 and blade 4. Wear suitable gloves to avoid injury. Test WARNING: Risk of injury from sharp knives •...
-
Page 16: Technical Specifications
• Store the device and its accessories in a dark, dry and frost-free place that is inaccessible to children. The optimal storage temperature is between 5˚C and 30˚C. • Keep the device away from corrosive substances such as garden chemicals and de-icing salts. •... - Page 19 1. Battery bracket (x1) 52-2. Oil can rubber nozzle (x1) 2. Unlock the push button(x1) 52-3. Oil spout (x1) 3. Micro Switch(x1) 52-4. seal ring (x1) 4. Spring1 (x1) 52-5. Spring (x1) 5. Switch the trigger (x1) 52-6. Mesh plug (x1) 6.
-
Page 20: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 21 Manufactured under license of Daewoo International Corporation, Korea...
