Summary of Contents for VIEW-it V2-UV-SET

  • Page 1 Ultraviolet Detectors Operation Manual Caution: Always Wear Laser Protective Eyewear...
  • Page 2 DESCRIPTION The VIEW-IT® Ultraviolet Detector product line features vari- ous substrates and target sizes designed to convert invisible ultraviolet light to visible red light. A very convenient tool for viewing ultraviolet light sources, laser beam shape, mode structure, and alignment. These tools provide unlimited viewing of both pulsed and continuous-wave sources operat- ing between 190-390nm.
  • Page 3 VIEW-IT® UV Detector. 3. Wear appropriate safety eyewear for your application. Place the VIEW-IT® UV Detector target in the path of the infrared light source being careful not to reflect it towards you or others.
  • Page 4 100J/cm2 at pulse durations between 30 nanosecond - 40 milliseconds. Also, emission of hydrogen sulfide (H under influence of acidic environment with pH 2-3 may occur. Use the VIEW-IT® UV tool in a well-ventilated area. VIEW-IT UV® BEAM DETECTORS...
  • Page 5 • Verify that the target surface hasn’t been damaged by the laser. • Make sure the target is clean before placing it in the path of the laser beam. COMPLIANCE This product line is RoHS, REACH and LaserSmart® compliant. VIEW-IT UV® BEAM DETECTORS...
  • Page 6 0.78 inches [20mm] diameter (VSPOT-UV) V2-UV-SET and 2 inches [50.8mm] square (VC-22UV) VB-UV50X50 2 inches [50.8mm] square VC-22UV 2 inches [50.8mm] square VDISC-UV 1.49 inches [38mm] diameter VF-UV10-10 10 inches [254mm] square VF-UV20-20 20 inches [508mm] square VIEW-IT UV® BEAM DETECTORS...
  • Page 7 5 inches [127mm] square 1.37 inches [35mm] diameter (VW-UV) V-UV-SET and 2 inches [50.8mm] square (VC-22UV) VSPOT-UV 0.78 inches [20mm] diameter VS-UV 1.37 inches [35mm] diameter VT-UV-3 3.75 inches [95.25mm] diameter VW-UV 1.37 inches [35mm] diameter VIEW-IT UV® BEAM DETECTORS...
  • Page 8 Rev. 04/23 kenteklaserstore.com ©Kentek Corporation. All rights reserved. VIEW-IT® is a registered trademark of Kentek Corporation.
