  • Page 1 User Manual For use with Graviton M1 Software 1.0.2 www.luminitefx.com...
  • Page 2 Contents Basic Introduction Features and Specifications The Hardware: XY Controller The Hardware: Graviton M1 The Software: Navigation The Software: Glossary Preset Mode Getting Started MIDI Screen Bank Screen Live Screen Control Screens Setlist Mode Getting Started...
  • Page 3 Song Screen Setlist Screen Setlist Control Screen Song Library Screen Setlist Library Screen Live Screen Control Screens Footswitch Pedals Getting Started Footswitch Screen Expression Pedals Getting Started Expression Screen Edit Expression Preset Screen Settings Display MIDI Clock Bank Data Update...
  • Page 5 Basic Introduction Graviton M1 is the next-generation MIDI controller pedal designed for guitarists and bassists who want to incorporate the full power of MIDI into their live or studio rigs with total wireless freedom, effortless usability, compatibility and expandability in an ultra compact package.
  • Page 6 ● Ultra Compact Footprint: Graviton M1 is smaller than an overdrive pedal, with the full control of a large 10-switch MIDI controller, saving pedalboards space and weight. Or use Graviton M1 to turn compact multi-effects pedals / amp modelers / computers / iPhones / iPads into portable and powerful gigging machines.
  • Page 7 ● Send Program Change, Control Change, Note On / Off, Scrolling PC / CC, SysEx, MIDI Clock / Start / Stop / Continue, Tap Tempo, Expression CC / PC / Clock BPM, Expression Toe / Heel Down triggered Preset, Preset triggered Expression etc. ●...
  • Page 8 XY Controller comes with a velcro patch and can be attached to any instrument. Experiment with different positions to see what works best for you. You may want to move the controller closer to your picking hand for quicker switching or further away for more room while strumming.
  • Page 9 ● Fully programmable: With 10 switches that can be assigned to send MIDI, switch banks or songs, and more. ● Advanced wireless: 650ft (200m) range; encrypted signal; strong interference resistance. ● Ultra-long battery life: 6–12 months per charge. A full charge only takes five minutes. ●...
  • Page 10 Graviton M1 Graviton M1 MIDI Interfaces Graviton M1 can send MIDI to six devices at once over four different MIDI interfaces: ● 1 x Standard MIDI ● 3 x MIDI over TRS (2 x 1/4" and 1 x 1/8" jacks): each configurable with four output modes, compatible with all TRS MIDI devices.
  • Page 11 Graviton M1 input / output jacks: ● 9VDC: Power Adapter in (9V center-negative, 250mA minimum). ● TRS 1 and TRS 2: MIDI out or Footswitch / Expression Pedals in with 1/4-inch (6.35mm) stereo cables ● TRS 3: MIDI out with 1/8-inch (3.5mm) stereo cable.
  • Page 12 Each screen serves a unique purpose to suit your needs. The Graviton M1's User Interface has a "Select a Screen" page at the top, which organizes multiple Screens into three modes: Preset Mode, Setlist Mode, and Settings. In Preset Mode and Setlist Mode, the XY Controller is active and can be customized with individual switching actions for each mode.
  • Page 13 ● Playing Mode: can be Preset Mode or Setlist Mode. ● Toggle MIDI Off Messages: are PC and CC messages in the playing Preset, but with their Value changed to 0. Useful for using Graviton M1 to control DAW like Ableton Live.
  • Page 14 ● TRS: Tip, Ring, and Sleeve. A TRS Jack is a stereo jack, which can be either ¼” or ⅛” type. List of Actions: ● Preset: (while playing in Preset Mode only) ○ Play Preset: play the selected Preset. ○ Bank + / -: jump to the next / previous Bank. ○...
  • Page 15 ● Note: Note On / Note Off / All Note Off. ● SysEx: send a System Exclusive MIDI message from the SysEx Library. Graviton M1 supports up to 128 byte long SysEx messages. See Preset Mode > MIDI > SysEx Library for more details.
  • Page 16 ● EXP Preset: assign an Expression Pedal to an Expression Preset. ● MIDI Preset: play a Preset. You can chain multiple Presets with this method, useful if you want to send more than 6 MIDI Messages at once. List of Expression MIDI Messages: ●...

  • Page 17: Preset Mode

    Preset Mode Getting Started When you are in any Screen within Preset Mode, hitting an XY Switch will perform its assigned Action (like playing a Preset or switching Banks) as defined in the Bank screen. See Glossary section for the list of available Actions. To assign an Action to an XY Switch, see the Bank Screen Section below.
  • Page 18 MIDI Screen This screen shows the playing Preset and its MIDI Messages. From left to right, top to bottom: Preset Name: shows playing Preset name. Tap to quickly jump between Bank ● screen and MIDI screen. Bank: shows playing Bank number. Tap to switch to another Bank. ●...
  • Page 19 From left to right, top to bottom: Page: shows the current SysEx Page. Tap to switch to another SysEx Page. ○ 1 - 10: shows the SysEx Message numbers. Tap one to select it. ○ SysEx Message Names: tap on one to Edit / Rename / Copy / Swap / Delete ○...
  • Page 20 Control Screens Shows all different ways to control Graviton M1 while playing in Preset Mode. This group has 3 screens, selectable by tapping on the top right corner: ● TRS 1 / 2: shows the Footswitch / Expression Pedals connected to the TRS 1 / 2 Jacks and their assigned Actions.

  • Page 21: Setlist Mode

    Setlist Mode Getting Started Setlist Mode is useful when you want to organize up to 10 Presets into a Song, and up to 10 Songs into a Setlist (there are 120 Setlists in total), and scroll through them while playing. To play in Setlist Mode, simply go to any screen from within the Setlist Mode menu.
  • Page 22 Song Screen This screen shows the playing Song and a list of its 10 Song Presets (Presets added from the Banks), with the playing Preset highlighted in blue. From left to right, top to bottom: ● Playing Song: shows the playing Song name. Tap to quickly jump between Song screen and Setlist screen.
  • Page 23 ● Song names: tap one one to add / replace it with another Song from your Song Library. To switch to another Setlist, go to the Setlist Library and tap on a Setlist number in the list (1 - 120). Song Library Screen This screen shows a list of all 120 Songs, organized into 12 Pages with the playing Song...
  • Page 24 Control Screens Shows all different ways to control Graviton M1 while playing in Setlist Mode. This group has 4 screens (selectable by tapping on the top right corner): ● TRS 1 / 2: shows the Footswitch / Expression Pedals connected to the TRS 1 / 2 Jacks and their assigned Actions.
  • Page 25 Footswitch Pedals Getting Started Graviton M1 can auto-detect and work with any Footswitch Pedal (momentary / latch / resistor ladder etc) with its "Learn" function, requiring no further manual configuration. Up to two footswitch pedals can be connected, with up to 10 switches each, for a total of 20 programmable switches.

  • Page 26: Expression Pedals

    Expression Pedals Getting Started Graviton M1 can auto-detect and work with any Expression Pedal (potentiometer value / hot tip / hot ring etc) with its "Calibrate" function, requiring no further manual configuration. Up to two Expression Pedals can be connected and assigned to one of ten Expression...
  • Page 27 2. Go to Expression screen: go to Preset Mode / Setlist Mode > TRS. Tap on the TRS button (top right) to switch to the TRS Jack you just connected. 3. Edit an Expression Presets: tap on the name of an Expression Preset > Edit (see Control >...
  • Page 28 ● Preset Name: shows playing Preset name. ● Number / Value / Channel: show MIDI messages number / value / channel. Tap to edit. ● “+”: add a MIDI message. ● “-”: remove the last added MIDI message. ● Clock Off / BPM: shows running MIDI Clock BPM (beat-per-minute). Tap to set a new BPM.
  • Page 29 ● USB MIDI: over USB and USB Host port. ● BLE MIDI: MIDI over Bluetooth Low Energy (wirelessly). BLE MIDI is on and discoverable by default. To turn it off, simply switch off all of its routing options. Routing options: ●...
  • Page 30 Graviton M1 can act as either one of these two USB MIDI modes: ● Device (to Computers): when connected to a computer using the USB MIDI port...
  • Page 31 ● Play Its Parallel Preset: parallel Presets are in different Banks but assigned to the same XY Switch (X1 - Y5) ● Pair: A Graviton M1 can pair with up to 10 XY Controllers. This is useful if you have more than one instrument, each can have their own XY Controller attached.
  • Page 32 ● Remap: customize the XY Controller layout. Data All of your Presets, Songs, Setlists, Settings etc data in Graviton M1 can be saved into a Backup. You can have up to 10 Backups (useful if you have different setups / rigs) and switch between them.
  • Page 33 Update ● Update Software: check and perform the Over-The-Air software update if available (require a WiFi network with internet). No computer needed.
