Continental Refrigerator Designer Line DL1WI-SS-E Specification Sheet

WARMERS
D D L L 1 1 W W I I - - S S S S - - E E
D D L L 2 2 W W I I - - S S S S - - E E
Models Available
•Consult Factory
Heating System-(Range 90°F to 180°F)
Electrically operated heating system is con-
trolled by means of a highly sensitive calibrat-
ed thermostat mounted on the cabinet front.
Fin strip heating elements are located at the
base of the interior. Air circulating blower
located in a top mounted, concealed "plug"
housing distributes heat throughout product
zone, assuring uniform cabinet temperatures.
Cabinet top has a built-in humidity relief vent.
The entire "plug" system is mounted on a stur-
dy steel, rail-type base which can be easily
removed if refrigerator or freezer conversion is
desired. A strict quality assurance team
inspects all material and components to certi-
fy that each model conforms to the most
exacting standards. All models are factory
performance tested for a minimum of 16 hours
prior to crating.
D D L L 3 3 W W I I - - S S S S - - E E
Cabinet Construction
All materials are of top quality, assembled to
conform with strict quality-assurance require-
ments. The cabinet front and doors are con-
structed of heavy-gauge polished stainless
steel for durability. All cabinet joints and
seams are sealed vapor-tight. Case is of all
metal, welded construction and internally sup-
ported and braced for a rigid unit construction.
Cabinet design eliminates overlapping panels
with raw edges. Cabinet body and doors are
insulated with non-CFC, foamed-in-place
polyurethane foam with an average thickness
of 3 inches to ensure increased energy effi-
ciency. Automatic interior lighting is controlled
by door openings. Cabinets are equipped with
an easily removable, stainless steel ramp and
interior rack guides.
ROLL-IN WARMERS
90° TO 180° RANGE
EXTENDED HEIGHT
(72" CART CAPACITY)

Standard Features

• Modern, State-of-the-Art Styling
• Top Mounted Heating Plenum "Plug" Design with
Circulating Fans for Uniform Temperature
Distribution
• Humidity Relief Vent
• 27 3 / " Wide, 72 1 / " High Door Openings
8 2
• 3" Non-CFC Polyurethane Foam Insulation
• Cam-Action Lift-Off Hinges
• Self-Closing Doors
• Automatic Interior Lighting
• Cylinder Lock In Each Door
• Exterior Thermostat Control with master
On/Off Control Switch
• Removable Stainless Steel Ramps
• Magnetic Snap-In Door Gasket
• Exterior Digital Thermometer
• Removable Stainless Steel Rack Guides
Standard (S/S Front, Aluminum Ends & Interior)
Suffix SA (S/S Exterior, Aluminum Interior)
Suffix SS (S/S Exterior & Interior)
Door Construction
Door shells are constructed of heavy-gauge
stainless steel and are internally braced and
urethane-foam-insulated for rigidity. Door cor-
ners are of welded construction and polished.
Door gaskets are self-adjusting, heavy-duty,
magnetic type. Door handles and hinges are
chrome-plated and non-corrosive. Doors are
provided with built-in cylinder locks which are
keyed alike. Hinges are cam action, lift-off
type featuring positive safety stop at 120
degrees.
