Continental Refrigerator DL1W-SS Specifications

D D L L 2 2 W W - - S S S S
D D L L 1 1 W W - - S S S S - - P P T T
Models Available
•Half Door
•Pass-Thru
Heating System - (Range 90°F to 180°F)
Electrically operated heating system is con-
trolled by means of a highly sensitive calibrat-
ed thermostat mounted on the cabinet front.
Fin strip heating elements are located at the
base of the interior. Air circulating blower locat-
ed in a top mounted, concealed "plug" housing
distributes heat throughout product zone,
assuring uniform cabinet
Cabinet top has a built-in humidity relief vent.
The entire "plug" system is mounted on a stur-
dy steel, rail-type base which can be easily
removed if refrigerator or freezer conversion is
desired. A strict quality assurance team
inspects all material and components to certify
that each model conforms to the most exacting
standards. All models are factory performance
tested for a minimum of 16 hours prior to crat-
ing.
WARMERS
•Consult Factory
Cabinet Construction
All materials are of top quality, assembled to
conform with strict quality-assurance require-
ments. The cabinet front and doors are con-
structed of heavy-gauge polished stainless
steel for durability. All cabinet joints and seams
are sealed vapor-tight. Case is of all metal,
welded construction and internally supported
temperatures. and braced for a rigid unit construction.
Cabinet design eliminates overlapping panels
with raw edges. Cabinet body and doors are
insulated with non-CFC, foamed-in-place
polyurethane foam with an average thickness
of 3 inches to ensure increased energy effi-
ciency. Automatic interior lighting is controlled
by door openings. Cabinets are equipped with
6-inch adjustable stainless steel legs.
REACH-IN & PASS-THRU
• Modern, State-of-the-Art Styling
• Top Mounted Heating Plenum "Plug" Design
with Circulating Fans for Uniform
Temperature Distribution
• Humidity Relief Vent
• 3" Non-CFC Polyurethane Foam Insulation
• Cam-Action Lift-Off Hinges
• Self-Closing Doors
• Magnetic Snap-In Door Gaskets
• Cylinder Lock In Each Door
• Exterior Thermostat Control with Master
On/Off Control Switch
• Adjustable 6" Stainless Steel Legs
DL3W-SS
• Heavy-Duty, Chrome Coated Steel Shelves
• External Digital Thermometer
• Automatic Interior Lighting
Standard (S/S Front, Aluminum Ends & Interior)
Suffix SA (S/S Exterior, Aluminum Interior)
Suffix SS (S/S Exterior & Interior)
WARMERS
90° to 180° RANGE

Standard Features

Shelving
Shelves are designed for heavy-duty use with
.306" diameter frame and brace members and
.140" diameter fill wires spaced
Shelves are welded steel and chrome plated
for a durable, long, rust-free service life.
Adjustments are in 1/2 inch increments and a
wide door opening allows the use of a variety
of optional pan and tray slide types.
Door Construction
Door shells are constructed of heavy-gauge
stainless steel and are internally braced and
urethane-foam-insulated for rigidity. Door cor-
ners are of welded construction and polished.
Replaceable snap-in door gaskets are self-
adjusting, heavy-duty, magnetic type. Door
handles and hinges are chrome-plated and
non-corrosive. Doors are provided with built-in
cylinder locks which are keyed alike. Hinges
are cam-action, lift-off type featuring positive
safety stop at 120 degrees.
3 / " apart.
4
