- Page 1 F-M1SDI-2ET HD-SDI Optical Tx-Rx Kit with RS485 and 2x 10/100 Fast Ethernet User Manual 2017...
-
Page 2: Table Of Contents
CHAPTER 5 RACK MOUNT CHASSIS ....................11 3.1 F-1MSDI-2ET-RK ........................ 11 PANEL 3.2 NMS ......................... 12 CARD ANEL 3.3 R ........................13 OUNT HASSIS 3.4 R ................14 ACKMOUNT HASSIS PPLICATION RAWING Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 3: Chapter 1. Introduction
Chapter 1. 1.1 Overview The Thor Fiber F-M1SDI-2ET is a compact power house that will allow any user to transport one single channel of 1.485Gbps HD-SDI Serial Data Interface uni-directionally while simultaneously transmitting two fast Ethernet 10/100Mb/s data. Furthermore this Thor Fiber Kit of Transmitter and Receiver will send RS485 in reverse for easy control over the kit. -
Page 4: Application Drawing
F-M1SDI-2ET 1.3 Application Drawing Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 5: Chapter 2. F-M1Sdi-2Et Panels
F-M1SDI-2ET F-M1SDI-2ET Panels Chapter 2. 2.1 Front Panel Figure 2-1 F-M1SDI-2ET Front Panel Table 2-1-1 Interface on F-M1SDI-TR-ET Front Panel Name Description Optical interface, bi-directional, ST/PC Connector HD-SDI input LOOP Looping SD/HD SDI output (Tx Only) HD-SDI output (Mirrored BNC Connectors on RX) Copper Fast Ethernet port, RJ45 connector, uses CAT-5 cross-over or straight- through cable. - Page 6 F-M1SDI-2ET Table 2-1-2 Indicators on F-M1SDI-2ET Name Description Optical signal loss alarm indicator, red. ON: Optical signal loss is detected at the port. OFF: the optical port receive normal signal. Running indicator, green. Normal blink: works normally OFF: Abnormal. The HD-SDI input lock indicator, green.
- Page 7 RS485 RXA2) differential signal A AUX204(R side) TXB(T/ RS422 differential signal B output/ RS485 channel-2 RXB2) differential signal B RS232 signal output 1-channel bi- RS232 signal input directional RS232 Ground AUX205 Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com...
-
Page 8: Rear Panel
F-M1SDI-2ET 2.2 Rear Panel Figure 2-2-1 F-M1SDI-2ET Rear Panel Table 2-2-1 F-M1SDI-TR-ET Rear Panel Name Description DC 12V power input interface DC12V Adopts AC220V/DC12V power adapter, provides 12V power supply Protective Ground (PGND) screw, connect with the chassis. Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com... -
Page 9: Chapter 3. Technical Specifications
Flow Control Default settings: open Standard IEEE802.3u 100Base-TX/ IEEE802.3 10Base-T RS485 Interface Connector PHOENIX connector Baud rate 0~115.2Kb/s Bit error ratio <10 Duplex Half-duplex CONSOLE Interface Connector RJ45 Baud rate 19200 Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... - Page 10 180mm x 123mm x 30mm Note: The optical module is optional for users, the default is 20Km on single mode fiber, other long distance needs to be declared when ordering. Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com...
-
Page 11: Chapter 4 Serial Management Interface
PC, the diagram is as Fig. A-1-1, Fig.A-1-2 shows: Figure A-1-1 RJ45 connector PC DB9 card 2 RX 7 RX 3 TX 8 TX 5 GND 6 GND Figure A-1-2 Connection Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 12: Chapter 5 Rack Mount Chassis
100W, supports power card management control. Note: The HD-SDI optical receive card supports hot-pluggable, which won't affect other working cards . 3.1 F-1MSDI-2ET-RK panel Figure 3-1-1 F-1MSDI-2ET-RK panel Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 13: Nms Card Panel
Blink: Normal link and there are data transmitting and receiving. OFF: No link or the interface is not used. EMU-EX work speed indicator, yellow ON: work in 100M; OFF: work in 10M. Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 14: Rack Mount Chassis
Protective ground (PGND) screw, connect with the chassis. PGND -48V power ground 220VIN ~220V AC power interface, the voltage range:176~264V “ON”: Power On; “OFF”: Power Off. Power switch Protective ground (PGND) screw, connect with the chassis. Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 15: Rackmount Chassis Application Drawing
F-M1SDI-2ET 3.4 Rackmount Chassis Application Drawing Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com...
