- Page 1 F-M1SDI-TR-ET 1-Bidirectional HD-SDI Optical Transceiver with RS485 and 10/100 Fast Ethernet User Manual 2017...
-
Page 2: Table Of Contents
............................2 1.2 F EATURE ............................2 1.3 A PPLICATION RAWING ........................3 CHAPTER 2. F-M1SDI-TR-ET PANELS ..................4 2.1 F RONT ANEL ...........................4 2.2 R ANEL .............................6 CHAPTER 3. TECHNICAL SPECIFICATIONS ................7 Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 3: Chapter 1. Introduction
Chapter 1. 1.1 Overview The Thor Fiber F-M1SDI-TR-ET is a compact power house that will allow any user to transport one single channel of 1.485Gbps HD-SDI Serial Data Interface bi-directionally while simultaneously transmitting 10/100Mb/s Ethernet Data. Furthermore this Thor Fiber Kit of Transmitter and Receiver will send RS485 in reverse for easy control over the kit. -
Page 4: Application Drawing
F-M1SDI-TR-ET 1.3 Application Drawing Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 5: Chapter 2. F-M1Sdi-Tr-Et Panels
F-M1SDI-TR-ET F-M1SDI-TR-ET Panels Chapter 2. 2.1 Front Panel Figure 2-1-1 F-M1SDI-TR-ET Front Panel Table 2-1-1 Interface on F-M1SDI-TR-ET Front Panel Name Description Optical interface, bi-directional, ST/PC Connector HD-SDI input HD-SDI output Copper Fast Ethernet port, RJ45 connector, uses CAT-5 cross-over or straight- through cable. - Page 6 F-M1SDI-TR-ET Table 2-1-2 Indicators on F-M1SDI-TR-ET Name Description Optical signal loss alarm indicator, red. ON: Optical signal loss is detected at the port. OFF: the optical port receive normal signal. Running indicator, green. Normal blink: works normally OFF: Abnormal. The HD-SDI input lock indicator, green.
-
Page 7: Rear Panel
F-M1SDI-TR-ET 2.2 Rear Panel Figure 2-2-1 F-M1SDI-TR-ET Rear Panel Table 2-2-1 F-M1SDI-TR-ET Rear Panel Name Description DC 12V power input interface DC12V Adopts AC220V/DC12V power adapter, provides 12V power supply Protective Ground (PGND) screw, connect with the chassis. Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com... -
Page 8: Chapter 3. Technical Specifications
Flow Control Default settings: open Standard IEEE802.3u 100Base-TX/ IEEE802.3 10Base-T RS485 Interface Connector PHOENIX connector Baud rate 0~115.2Kb/s Bit error ratio <10 Duplex Half-duplex CONSOLE Interface Connector RJ45 Baud rate 19200 Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... - Page 9 180mm x 123mm x 30mm Note: The optical module is optional for users, the default is 20Km on single mode fiber, other long distance needs to be declared when ordering. Thor Fiber 2017 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com...
