- Page 1 Thermal Imaging Camera Quick Start Guide Shenzhen Pard Technology Co.,Ltd...
-
Page 2: Components And Controls
Components and Controls No. Name No. Name Name Button panel Battery cap TF card slot Focus lever Objective lens Type C- charging port Lens focus ring Red dot pointer HDMI port Range finder (LRF model) Range emitter Picatinny rail Power/Sleep Range receiver Lens cap Diopter Focus... - Page 3 red dot switch scene Key 4 menu pointer/PIP/back mode Explanation: Key 1 ① Home screen mode: press [+] to magnify the screen 1/2/4/6/8 times. 1. Single Press: ② Menu mode: press [+] to scroll up and adjust the relevant option settings. ①Home screen mode: long press to view video and picture files saved in the memory card: 2.
- Page 4 ② Menu mode: press [-] to scroll down or adjust the relevant option settings. hot/iron mode. 2.Long Press Long press [-] to take a photo. 3.Double Press: Double press [-] to turn on the illuminator and double press [-] again to turn off the illuminator. Key 4 1.Single Press Home screen mode: press [Menu] to open/close the menu interface.
-
Page 5: Key Features
2) Diopter Focusing Rotate the diopter focusing wheel until you can see the screen clearly. 3)Objective Lens focusing Adjust the objective focusing wheel until you can see the target image clearly. 4)Compass Calibration Please use the "figure 8 pattern method" as shown in the figure below to calibrate the compass. Key Features ... -
Page 6: Packaging Contents
Packaging Contents Contents Quantity Thermal imaging device 3.7V 18650 rechargeable lithium-ion battery （inside the battery compartment） Carry case Velvet drawstring pouch Shoulder strap Type-C cable Metal mount Allen wrench (D4.0mm) Mount tightening screw (KM*10mm) Allen wrench (D1.5mm) Red dot adjustment screw (M3*3mm) Shim 1（15*8.5*0.1mm) Shim 2（15*8.5*0.2mm) Quick start guide / User manual... -
Page 7: Specifications
Specifications Model SA32/SA32 LRF SA62/SA62 LRF Sensor 12μm，384*288 12μm，640*480 Objective lens（mm) 19/25/35/45 25/35/45 Horizontal: 13.8°/10.5°/7.5°/5.9° Horizontal: 17.5/12.5°/9.7° Field of view（HxV） Vertical: 10.4°/7.9°/5.6°/4.4° Vertical: 13.1°/9.4°/7.3° Diagonal: 17.2°/13.1°/9.4°/7.3° Diagonal: 21.7°/15.6°/12.2° Optical Magnification(x) 2/2.6/3.7/4.7 1.6/2.2/2.8 Human detection distance(m) 800/1100/1400/1700 1200/1500/1800 Vehicle detection distance(m) 1800/2200/2600/3000 2500/2900/3300 Product dimension(L x W x H,... - Page 8 Cautions 1. Please remove the insulating tape on the battery before first use. It is recommended to use a fully charged lithium-ion battery with a rated voltage of 3.7V. 2. Always turn off the device when it’s not in use. If you are planning on not using the device for more than 10 days, remove the battery and store it in a safe place.
- Page 9 This equipment complies with FCC's RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna(s) must not be co-located or conjunction with any other antenna or transmitter. E-mail: info@pard-tech.com Telephone: 400-099-2599 Website: www.pard.com Address: No. 328 Baoshi East Road, Shiyan, Baoan, District, Shenzhen, China...
