XIA5003 External Locking
Attachment Instructions
Installation and Operating Instructions
External Locking Attachment
This product is designed to operate with Eurospec Emergency and Panic Exit Devices XIA5002,
and XDL5760, which are fitted to comply with EN179 or EN1125
This product is non-handed and can be fitted on both left and right handed doors.
With the External Locking attachment in "Unlocked" position, pull handle to release XIA5002
Push Pad Device.
Lock and unlock External Locking Device as follows:
"Unlocked" position - Insert key, turn clockwise to stop, turn key back to starting position, and
withdraw key.
"Locked" position - Insert key, turn anti-clockwise to stop, turn key back to starting point, and
withdraw key.
Note: The key must always be removed prior to operation.
With external Locking Attachment in "locked" position, handle wth pull, but the follower will not
rotate.
After 20,000 operations, lubricate using GT85 PTFE solution or similar. Repeat after each
additional 20,000 operations.
Ensure all fixings are secure, and check for correct operation.
FITCB0087 | Revision A
Important Information
PLEASE READ THESE INSTRUCTIONS CAREFULLY
Operational Instructions and Maintenace
+44 1228 511030
Carlisle Brass Ltd, Parkhouse Road, Carlisle, CA3 0JU
enquiries@carlislebrass.com
www.carlislebrass.com
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XIA5003 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eurospec XIA5003

  • Page 1 Important Information PLEASE READ THESE INSTRUCTIONS CAREFULLY This product is designed to operate with Eurospec Emergency and Panic Exit Devices XIA5002, and XDL5760, which are fitted to comply with EN179 or EN1125 This product is non-handed and can be fitted on both left and right handed doors.
  • Page 2 XIA5003 External Locking Attachment Instructions Product Preparation Prior to fitting, select correct hand of door, See Fit. 1 and prepare spindle roation as follows: Right Hand door, rotate follower fully “clockwise.” See Fig. 2 Left Hand door, rotate follower rully “anti-clockwise.” See Fig. 2 Follower Fig.
  • Page 3 XIA5003 External Locking Attachment Instructions Installation With XDL5760 Push Bar Panic Latch Step 1. Fitting with Push Pad Fig. 5 3.1 Ensuring the Follower centreline of External Locking Attachment is aligned with Follower centreline of the internal devicce, drill 3 x 5.5mm diameter holes for fixing bolts and 1...
  • Page 4 XIA5003 External Locking Attachment Instructions Annex A Installation and Fitting Instructions A.1 The producer shall specify the appropiate fixing arrangement for the door types for which the exit device is designed. A.2 Before fitting an exit device to a door, the door should be checked to ensure correct hanging and freedom from blinding.
  • Page 5 XIA5003 External Locking Attachment Instructions A.10 Emergency exit devices are not intended for use on double action (double swing) doors unless specifically designed by the exit device producer. A.11 The fixing instructions should be carefully followed during installation. These instructions and any maintenance instructions should be passed on by the installer to the user.
  • Page 6 XIA5003 External Locking Attachment Instructions Annex C Maintenance Instructions The following information shall accompany the product: A) Inspect and operate the emergency exit device to ensure that all components are in a satisfactory working condition. Using a force gauge, measure and record the operating forces to release the exit device.
