FONESTAR LED-BEAM24 Instruction Manual

Mushroom effect dmx led
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
LED-BEAM24
MUSHROOM EFFECT DMX LED
N Instruction Manual

Advertisement

loading

Related Manuals for FONESTAR LED-BEAM24

Summary of Contents for FONESTAR LED-BEAM24

  • Page 1 LED-BEAM24 MUSHROOM EFFECT DMX LED N Instruction Manual...
  • Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.

  • Page 3: Exemption Of Liability

    The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.

  • Page 4: Connection And Operating

    DESCRIPTION - Mushroom with 30 mobile beams, 2 x 2 W RGB LED. - DMX control through 4 channels, automatic mode, audio activation and master/slave mode. - Colour and dimmer adjustment through DMX controller. - Long lasting LED up to 100 000 hours. - Double microphone incorporated (motor rotation and lighting).
  • Page 5 FUNCTION DMX MODE: DIRECTION USING DIP 1 to 9 AUDIO ACTIVATION R ON G ON B ON STROBE STROBE SPEED X2 STROBE SPEED X4 STROBE SPEED X6 STROBE SPEED X8 AUTOMATIC MODE AUTOMATIC MODE SPEED X2 AUTOMATIC MODE SPEED X4 AUTOMATIC MODE SPEED X6 AUTOMATIC MODE SPEED X8 RGB TRANSITION SPEED X2...
  • Page 6 See the figure below: - The equipment can be set in master/slave mode by connecting 2 x LED-BEAM24 together. Connect an XLR cable from the DMX OUT output on the first element (master) to the DMX IN input on the second element.

  • Page 7: Safety Recommendations

    - Do not move or manipulate the device while it is connected to the mains and operating. - Do not modify the lighting elements in the device without technical supervision or equipment guaranteed by the supplier. SPECIFICATIONS LED-BEAM24 CHARACTERISTICS Mushroom effect with 30 mobile beams. Automatic mode and audio activation with adjustable sensitivity and master/slave mode.
  • Page 8 - 8 -...
