MOKA
GRINDER
1
2
3
4
5
1 8
USE & MAINTENANCE:
6
7
8
9
10
11
1. Hopper Lid
5. Adjustment Guide
2. Bean Hopper
6. Dispenser Lid
3. Adjustment Icon
7. Dispenser
4. Locking Pin
1
2
3
11
12
14
13
8. Dispenser
9. Dispensing Star
10.Tamper
Adjustment Knob
11.Porta-Filter Guide
13
12.Dispenser Lever
13.On-Off Switch
14.????
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pasquini Chrome
Summary of Contents for Pasquini Chrome
- Page 1 MOKA GRINDER USE & MAINTENANCE: 1. Hopper Lid 5. Adjustment Guide 2. Bean Hopper 6. Dispenser Lid 3. Adjustment Icon 7. Dispenser Adjustment Knob 4. Locking Pin 8. Dispenser 12.Dispenser Lever 9. Dispensing Star 13.On-Off Switch 10.Tamper 14.???? 11.Porta-Filter Guide...
- Page 2 For a truly “Italian Style” espresso or cappuccino: Once the proper setting on the grinder has been determined, it should take a PASQUINI LIVIA 15 - 18 seconds to dispense a 1 1/2-2oz. cup of “Italian Style” espresso. It should appear to have the flow consistency of syrup as it pours into the cup.
- Page 3 ADJUSTMENTS DISPENSING 1. COARSENESS / FINENESS ADJUSTMENT • If the coffee flow is too fast (i.e. rippling out), the coffee is too coarse; adjust for a finer grind. Rotate ring clockwise (toward the “-”) or a lower number. Figure A. Figure A: Rotate Adjustment Ring Clockwise for Finer •...
- Page 4 ADJUSTMENTS (CONT.) 3. AMOUNT OF GROUND COFFEE TO BE DISPENSED Adjust the amount of ground coffee that is dispensed into the porta-filter by rotating the Dispenser Adjustment Knob (7) inside the dispensing chamber: • • The Dispensing Star (9) should be completely covered to a level of approximately 1” above the star as measured from the side of the chamber.
