Partner BR-4100 Setting Manual

BR-4100 Bar Code Reader (RS232)

Dip Switch Settings

The switch block located on the bottom of the reader provides seven switches to configure the bar code
reader. Turn off power before setting any switches to ensure they are properly loaded.

Switch 1,2: Baud Rate

SW1 SW2
OFF OFF
ON OFF
OFF ON
ON ON

Switch 3,4: Parity

SW3 SW4
ON ON
ON OFF
OFF ON
OFF OFF
Switch 5: Option to enable or disable STX (start of text) and ETX (end of text).
These are ASCII codes whose values are 02h and 03h respectively, and can be preformed to
pack together the normal data transmission.
ON Enable STX-ETX
OFF Disable STX-ETX
Switch 6: Auto CR (carriage return). A carriage return will be sent after each read.
ON Enable CR
OFF Disable CR

Switch 7: Option switch to select Extended Code 39

ON Enable Extended Code 39
OFF Disable Extended Code 39
Baud Rate
1200
2400
4800
9600
Parity
EVEN
ODD
SPACE
MARK
