FEI mimsafe 80326 Assembly And Operation Instructions Manual

Corner kit
Hide thumbs

Advertisement

Quick Links

Download this manual
Corner Kit - 80326
mimclip.mimsafe.com
IMPACT TECHNOLOGY
UNIVERSAL SAFETY
SINCE
1986
45°-75°
ASSEMBLY AND OPERATION INSTRUCTIONS
CORNER KIT
75°-90°
MIMCLIP SYSTEM
APPROVED

Advertisement

loading
Need help?

Need help?

Do you have a question about the mimsafe 80326 and is the answer not in the manual?

Questions and answers

Related Manuals for FEI mimsafe 80326

Summary of Contents for FEI mimsafe 80326

  • Page 1 Corner Kit - 80326 mimclip.mimsafe.com IMPACT TECHNOLOGY UNIVERSAL SAFETY SINCE 1986 45°-75° ASSEMBLY AND OPERATION INSTRUCTIONS CORNER KIT 75°-90° MIMCLIP SYSTEM APPROVED...
  • Page 2 INFORMATION ABOUT THE CORNER KIT The Corner Kit has been designed and to the horse if hit vertically. The rail is only developed specifically to greatly reduce the released when impacted horizontally by the risk of rotational falls. horse. The risk of a resulting rotational fall The most important element of this kit is is thus reduced.
  • Page 3 Jumping direction 45°-90° Minimum-Maximum IMPORTANT Secured to the ground IMPORTANT The clips F18F must be placed on ALL posts. 00454 F70A F18F Part no Part no Part no M-TS10X90 POST TOP POST BOTTOM RAIL SECTION SECTION not included not included not included...
  • Page 4 Square posts 0-10 inch 0-250 mm IMPORTANT Make sure you follow these measurements for correct fence IMPORTANT release/function When mounting, make sure the hinge is mounted as shown in this picture to ensure correct activation. 130mm 5.1” 50mm 2”...
  • Page 5 Round posts 20mm 3/4” Cut offs IMPORTANT Aligned cuts for torsional rigidity Cut offs 130mm 5.1” 70mm 2 3/4” not included...
  • Page 6 not included...
  • Page 7 IMPORTANT USE M12 or UNC 1/2” to make sure the horizontal rail is rigid fixed to the posts.
  • Page 8 CORRECT alignment of the clip WRONG alignment of the clip Square 90° degrees angle top view top view Jumping direction IMPORTANT Drilling pattern 80326-DP M-TS10X90 IMPORTANT 9.3” ± 0.5” 237 ± 15 mm Add material to create a flat surface large enough for 6.7”...
  • Page 9 IMPORTANT Distance between brackets should be adjusted to avoid clip C rattling. Rotate the pieces C around the bolt’s possition if necessary not included...
  • Page 10 45°-75° IMPORTANT Remove this bolt when the corner kit is wider than 75°. This will facilitate the fence releasing. 75°-90°...
  • Page 11 IMPORTANT Make sure it’s clearance during activation IMPORTANT Fill out the gap with a fixed lower post and a loose stub above to avoid “foot trap”. IMPORTANT Connect the stub with 3.6 mm zip ties...
  • Page 12 The flag is bent when the clip is exposed 2. Reduces the possibility of rotational falls. to fatigue. In both cases the clip must be 3. FEI approved number FEI15SWE. replaced. The top section is connected 4. Controlled movement of fence during release.
  • Page 13 Oxer Kit - 80329 mimclip.mimsafe.com IMPACT TECHNOLOGY UNIVERSAL SAFETY SINCE 1986 ASSEMBLY AND OPERATION INSTRUCTIONS OXER KIT MIMCLIP SYSTEM APPROVED...
  • Page 14 INFORMATION ABOUT THE OXER KIT The Oxer Kit has been designed and risk injury to the horse if hit vertically. developed specifically to greatly The rail is only released when impacted reduce the risk of rotational falls. horizontally by the horse. The risk of a The most important element of this resulting rotational fall is thus reduced.
  • Page 15 Jumping direction IMPORTANT The posts must be: PARALLEL, VERTICALLY LEVELLED & FRONTAL ALIGNED IMPORTANT Secured to the ground F64A5 F70A F18C Part no Part no Part no Part no M-SM12x120 M-BR12x22x2s M-MM12Ny M-TS10X90 POST RAIL not included not included...
  • Page 16 M-SM12x120 M-BR12x22x2s M-MM12Ny S T T O A D J U E I G H T E C T H C O R R IMPORTANT The A & B pieces must be: PARALLEL to each other IMPORTANT The BOLTS must be: ALIGNED to each other...
  • Page 17 *alternative not included not included not included...
  • Page 18 not included *alternative not included not included...
  • Page 19 The C pieces must be: PARALLEL AND (±10°) HORIZONTALLY LEVELLED not included DISTANCE BETWEEN C PIECES M-TS10X90 The C pieces must be: PARALLEL AND HORIZONTALLY LEVELLED...
  • Page 20 The flag is bent when the clip is exposed 2. Reduces the possibility of rotational falls. to fatigue. In both cases the clip must be 3. FEI approved number FEI09SWE. replaced. The top section is connected 4. Controlled movement of fence during release.
  • Page 21 Post & Rail Narrow Kit - 80322 mimclip.mimsafe.com IMPACT TECHNOLOGY UNIVERSAL SAFETY SINCE 1986 ANGLED JUMP STRAIGHT JUMP USING YELLOW CLIP USING RED CLIP included in this kit order separately kit nr.80328 APPROVED...
  • Page 22 INFORMATION ABOUT THE POST & RAIL NARROW KIT The Post & Rail Narrow Kit has been designed and break the fence or risk injury to the horse if hit vertically. developed specifically to greatly reduce the risk of rotational The rail is only released when impacted horizontally by the falls.
  • Page 23 Jumping direction IMPORTANT IMPORTANT The clips must be placed on Secured to ALL posts. the ground order separately kit nr.80328 00454 F70A F18C F18F Part no Part no Part no Part no M-TS10X90 POST TOP POST BOTTOM RAIL SECTION SECTION not included not included not included...
  • Page 24 Square posts 0-10 inch 0-250 mm IMPORTANT Make sure you follow these measurements for correct fence IMPORTANT release/function When mounting, make sure the hinge is mounted as shown in this picture to ensure correct activation. 130mm 5.1” 50mm 2”...
  • Page 25 Round posts 20mm 3/4” Cut offs IMPORTANT Aligned cuts for torsional rigidity Cut offs 130mm 5.1” 70mm 2 3/4” not included...
  • Page 26 not included...
  • Page 27 IMPORTANT USE M12 or UNC 1/2” to make sure the horizontal rail is rigid fixed to the posts.
  • Page 28 CORRECT alignment of the clip WRONG alignment of the clip Square 90° degrees angle top view top view Jumping direction IMPORTANT Drilling pattern 80326-DP M-TS10X90 IMPORTANT 9.3” ± 0.5” 237 ± 15 mm Add material to create a flat surface large enough for 6.7”...
  • Page 29 IMPORTANT Distance between brackets should be adjusted to avoid clip C rattling. POSITIONING OF CLIP FOR POSITIONING OF CLIP FOR ANGLED JUMP STRAIGHT JUMP order separately kit nr.80328 Rotate the pieces C around the bolt’s possition if necessary not included...
  • Page 30 ANGLED JUMPS Adjusting the hinge for diferent jumping angles 55°-70° IMPORTANT Remove this bolt when the jumping angle is less than 55°. This will facilitate the fence releasing. 45°-55°...
  • Page 31 In both 2. Reduces the possibility of rotational falls. cases the clip must be replaced. The top section 3. FEI approved number FEI12SWE. is connected to the post with a hinge that makes 4. Controlled movement of fence during release.
  • Page 32 Post & Rail Kit - 80321 mimclip.mimsafe.com IMPACT TECHNOLOGY UNIVERSAL SAFETY SINCE 1986 ASSEMBLY AND OPERATION INSTRUCTIONS POST & RAIL KIT MIMCLIP SYSTEM APPROVED...
  • Page 33 INFORMATION ABOUT THE POST & RAIL KIT The Post & Rail Kit has been designed risk injury to the horse if hit vertically. and developed specifically to greatly The rail is only released when impacted reduce the risk of rotational falls. horizontally by the horse.
  • Page 34 Jumping direction IMPORTANT The posts must be: PARALLEL, VERTICALLY LEVELLED & FRONTAL ALIGNED IMPORTANT Secured to the ground F64A5 F70A F18C Part no Part no Part no Part no M-SM12x120 M-BR12x22x2s M-MM12Ny M-TS10X90 POST RAIL not included not included...
  • Page 35 M-SM12x120 M-BR12x22x2s M-MM12Ny S T T O A D J U E I G H T E C T H C O R R IMPORTANT The A & B pieces must be: PARALLEL to each other IMPORTANT The BOLTS must be: ALIGNED to each other...
  • Page 36 *alternative not included not included not included...
  • Page 37 not included *alternative not included not included...
  • Page 38 CORRECT alignment of the clip WRONG alignment of the clip top view top view Square 90° degrees angle Jumping direction Jumping direction The C pieces must be: PARALLEL AND (±10°) HORIZONTALLY LEVELLED not included DISTANCE BETWEEN C PIECES M-TS10X90 The C pieces must be: PARALLEL AND HORIZONTALLY LEVELLED...
  • Page 39 The flag is bent when the clip is exposed 2. Reduces the possibility of rotational falls. to fatigue. In both cases the clip must be 3. FEI approved number FEI10SWE. replaced. The top section is connected 4. Controlled movement of fence during release.
  • Page 40 Table Kit - 80320 mimclip.mimsafe.com IMPACT TECHNOLOGY UNIVERSAL SAFETY SINCE 1986 ASSEMBLY AND OPERATION INSTRUCTIONS TABLE KIT MIMCLIP SYSTEM APPROVED...
  • Page 41 INFORMATION ABOUT THE TABLE KIT The Table Kit has been designed injury to the horse if hit vertically. and developed specifically to greatly The top is only released when impacted reduce the risk of rotational falls. horizontally by the horse. The risk of a The most important element of this kit resulting rotational fall is thus reduced.
  • Page 42 Jumping direction IMPORTANT The fence as an unit, needs to be placed on a flat and horizontal area. Diagonal reinforcement should be applied. This to avoid torsion when the fence is activated by impact of center. The fence lower section needs to be secured to the ground. F64B F76A3 F76A1...
  • Page 43 M-SM10x110 M-BR10,5x22x2s M-MM10Ny 186X not included...
  • Page 44 MID SIZE Recommended for CIC** and lower fences G2 H2 Instruction: Decide length A Instruction: Decide length A (inch) (milimeter) Piece Cross Section Length Minimum lenght Piece Cross Section Length Minimum lenght 2”x4” 40,5” 45x95 1030 3,5”x4” 17,1” 90x95 2”x8” (A+18,5”) 63”...
  • Page 45 FULL SIZE Recommended for CIC*** and higher fences G2 H2 Instruction: Decide length A Instruction: Decide length A (inch) (milimeter) Piece Cross Section Length Minimum lenght Piece Cross Section Length Minimum lenght 2”x4” 49,4” 45x95 1255 3,5”x4” 23,2” 90x95 2”x8” (A+23,4”) 72,8”...
  • Page 46 Important Recommendations for installation WARNING The three posts No 2 should be connected to a box construction or wall to become a rigid object. This to avoid different angles of the three posts No 2 and to avoid torsion when the fence is activated by impact of center.

  • Page 47: Hazardous Area

    6. The parts are made of powder coated steel and can be 2. Reduces the possibility of rotational falls. left outside, no maintenance is required. 3. FEI approved number FEI14SWE. 7. The very highest quality of product from Sweden. 4. Controlled movement of fence during release.
  • Page 48 Wall Kit - 80324 mimclip.mimsafe.com IMPACT TECHNOLOGY UNIVERSAL SAFETY SINCE 1986 ANGLED JUMP STRAIGHT JUMP USING YELLOW CLIP USING RED CLIP included in this kit order separately kit nr.80328 APPROVED...

  • Page 49: Recommended Material

    INFORMATION ABOUT THE WALL KIT The Wall Kit has been designed and developed specifically to greatly reduce the risk of rotational falls. The most important element of this kit is that it will not break the fence or risk injury to the horse if hit vertically. The top section is only released when impacted horizontally by the horse.
  • Page 50 THE TOP SECTION IS THE FOLDABLE PART OF THE FENCE AND NEEDS TO BE TORSIONALLY RIGID A torsionally rigid object is achieved by making a box construction. This concerns the top section which should be a rounded or square box construction. This is to avoid torsion when the fence is activated by impact of center.
  • Page 51 IMPORTANT It is important that the top section is torsionally stiff. HOW TO CHECK TORSIONAL STIFFNESS Hold up the Top Section by one end only according to schematic below. While this is being held parallel to ground, measure the distances H left and H right. These may only differ by 10 mm per 1000 mm in length L Example: L=3000 mm...
  • Page 52 M-SM12x120 M-BR12x22x2s M-MM12Ny 8-10 inch 20-25 cm IMPORTANT Don’t cut until the clip is correctly mounted. Make sure you follow the cutting measurements for correct fence release/function 4 inch 10 cm Chech the weight at this point with the top section at 90°...
  • Page 53 not included not included...
  • Page 54 POSITIONING OF CLIP FOR POSITIONING OF CLIP FOR ANGLED JUMP STRAIGHT JUMP 16” ± 1” 400 ± 20 mm 8” ± 0.5” 16” ± 1” 200 ± 15 mm 400 ± 20 mm 8” ± 0.5” 200 ± 15 mm IMPORTANT Distance between brackets should be adjusted to avoid...
  • Page 55 In both cases 2. Reduces the possibility of rotational falls. the clip must be replaced. The top section is 3. FEI approved number FEI13SWE. connected to the post with a hinge that makes 4. Controlled movement of fence during release.
