Page 1 SL-342H RFID Locker Lock Setup and User Guide Thank you for purchasing the SL-342H RFID Locker Lock. This user guide details the different functions of this product, please keep a copy for your records. Table of Contents What’s in the box...
Page 2 1. What’s in the box Each lock is packaged in its own box that includes the follow parts: 1 x SL-342H RFID Lock Housing (Installed Inside Locker Door) 2 x Phillips wood screws to secure the housing 1 x Round Reader Module Cover Plate (Installed Outside Locker Door)
Page 3 Changing Owner Card 1. Remove the front lock housing from the door. 2. Follow initialization procedure in section 1. 3. Program a new Owner Card as instructed above. SL-342H Setup and User Guide Page 3 of 7 ©2023 SYNOLOCK...
Page 4 1. Scan the Master Card. A chime will sound and both LEDs will blink for 6 seconds. 2. After 6 seconds, a second chime sounds and the unit will unlock. 3. All User Cards have also been removed. SL-342H Setup and User Guide Page 4 of 7 ©2023 SYNOLOCK...
Page 5 Unregistered Card Alarm 1. An alarm will sound after 5 attempts to open the lock with an unregistered User Card. 2. Scan a registered User Card to deactivate the alarm. SL-342H Setup and User Guide Page 5 of 7 ©2023 SYNOLOCK...
Page 6 2. Scan the Owner Card and wait for the lights to blink. 3. Press the latch and listen for one “Beep” sound. 4. The latch alarm is now active. SL-342H Setup and User Guide Page 6 of 7 ©2023 SYNOLOCK...
Page 7 Battery Connector 1. Attach battery to the connector. 2. Connect leads to the two contact points on the faceplate. 3. With the battery connected, scan a valid Card to open. SL-342H Setup and User Guide Page 7 of 7 ©2023 SYNOLOCK...
