Summary of Contents for MONTAGUE CM 24
- Page 2 Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the operating and m a i n t e n a n c e i n s t r u c t i o n s thoroughly before installing or servicing this equipment.
- Page 3 INSTALLATION The Montague gas fired cheesemelters are produced with the best possible material and workmanship. PROPER INSTALLA TION ESSENTIAL SAFE EFFICIENT TROUBLE-FREE OPERATION. The gas fired cheesemelter is manufactured for use with the type of gas indicated on the nameplate,...
- Page 6 INSTALLATION Lift cheesemelter assembly above range slide vertical posts into position on the range body . (See Figure 2 ) • RANGE MOUNTED MODELS CM24, CM36, CM48, CM60, CM72 Any of these cheesemelters ma y be mounted on a reinforced high shelf on VG)26, (G, VG)2626, (G, VG)260, (G, VG)2616,...
- Page 7 INSTALLATION GAS CONNECTION REMOVE CONTROL PANEL AND TOP PANEL FOR ACCESS TO GAS CONNECTION. Before connecting the cheesemelter to the gas supply line, sure that al I new piping has been cleaned and purged to prevent foreign matter from being carried Into the controls by the gas.
- Page 8 OPERATI ON THIS APPLIANCE HAS BEEN CLASSIFIED AS COMMERCIAL COOKING EQUIPMENT AND MUST BE OPERATED BY QUALIFIED AND/OR PROFESSIONAL OPERATING PERSONNEL. CAUTION DO NOT OBSTRUCT THE FLOW OF COMBUSTION AND VENTILATION AIR TO THE CHEESEMELTER. KEEP THE APPLIANCE AREA FREE AND CLEAR FROM COMBUSTIBLES.
- Page 9 MAINTENANCE CARE AND CLEANING GENERAL CLEANING Lint and grease suspended in the air tend to collect in passages. Therefore, air openings, flueways, and primary air prevent openings, etc., should be periodically cleaned clogging. complete cheesemelter should given periodic general cleaning. DAILY: Remove grid rack, drip shield (below grid rack)
- Page 11 SERVICE COMPANY , WHEN SERVICE IS NEEDED, CONTACT LOCAL SERVICE DEALER FACTORY PERFORM MECHANICAL MAINTENANCE AND REPAIRS. THESE INSTRUCTIONS ARE INTENDED FOR USE BY COMPETENT SERVICE PERSONNEL. CAUTION TURN OFF GAS AT MANUAL SHUT OFF VALVE NEXT TO THE APPLIANCE BEFORE ATTEMPTING TO LOOSEN ANY GAS CONNECTIONS.
- Page 12 SERVICE MODEL CM SERIES CHEESEMELTER RENEWAL PARTS D..E.S.CBl.E.IlQt:1 .E.AB.I_t:IQi .l.llM 01019-7 Burner Pilot Assy - Nat. Gas 01020-0 Propane Gas 01000-6 Valve, Pilot (28-1/4) 09308-4 Burner Assy Nat. Gas Orifice 09314-9 (28-1/4) Propane Gas Orifice (16-3/4) 09321-1 Nat. Gas Orifice (16-3 / 4) 09323-8 Propane Gas Orifice...
- Page 14 Serial No. ________________ _ Model No. ________________ _ Change No. ____ ___________ _ Name & No. of Part Model No Change No Serial No • The Montague Company 1830 Stearman Avenue P.O. Box 4954 Hayward, Ca. 94540-4954 11591-6...
