- Page 1 User Manual & Instruction ET02HC Automatic Sensor Tap...
-
Page 2: Function & Feature
FUNCTION & FEATURE WATER-SAVING water flows out when your hands approach it and it will stop at once when hands draw back, saving water dramatically SANITATION Self-open and close to free hand from any touching,which e eciently avoids bacteria mutual infections INTELLIGENCE with its micro-computercontrollingits action and against light and ultraviolet radiation, the faucet can sell-adjust its best detec-... - Page 3 SPECIFICATION & MODEL Remark Power DC6V(4AA alkaline batteries) Voltage 220V faucet voltazge changer Power When use 4AA alkaline batteries it can be used about consumption ＜0.5mw 2 years as per worked 300 in static cycles one day Detection 12-18cm zone water 0.05~ 0.6MPa pressure...
- Page 4 UNIT NAME FAUCET UNIN Faucet part sensor display Battery box Temperature handle rubber gasket SS gasket M8 fastened bold M8 Install the cap Non-return check valve Strainer Water supply connector 220V faucet voltage changer 4AAA alkaline batterries Control box Self tapping screw Expansion sleeve...
-
Page 5: Installation Warning
INSTALLATION WARNING lOCATION DESIGN When design installation loctation,it should avoid sun- shine or strong light whicn may glare down on sensor display BASIN DESIGN It should choose standard single basin and the hole diameter should be larger than 28mm. PIPE CLEANING Before installation please flush the pipe circuit firstly or it will block... - Page 6 INSTALLATION APPROACH INSTALLATION SHOW Hot hose Cold hose Note: please close water switch before installation...
- Page 7 INSTALLATION APPROACH 1. Install the inlet pipe into the faucet, (2) Install the power control box. and then instal the faucet into the basin hole. (Pay attention to the directionof cold and hot when you instal the water supply) 3. If only DC power is connected without 220V AC power supply, the battery output line is directly connected with the faucet induction...
-
Page 8: Battery Installation
INSTALLATION APPROACH 4.BATTERY INSTALLATION 1). Dismantle one bolts, put into 4AAA alkaline batteries correctly(please beware of anode and cathode), put back the cover and fasten bolts. 2). When change batteries, new batteries should be put into after 5 minutes from taking out old ones, which can make the original datas in machine clean completely, or it will work abnormally. - Page 9 INSTALLATION APPROACH (6) If the DC line of the battery is 7.Connect the hot and cold water connected with 220 V AC power supply supply,and open the inlet water valve. at the same time, insert the plug of the battery box into the plug head of the power supply, and then insert the induction window plug into the power supply plug.
- Page 10 USE INTRODUCTION CLOSE & OPEN 1. when hands touch detection zone, it will work automatically after0.5S, once hands draw back, it will be closed in 0.5S. 2. when wash hands over 1 minutes or continous detection by error object, machine will be closed automatically, when hands or error object leaves about 10S it will be detective again.
- Page 11 PROTECTION MAINTAIN BATTERY INSPECTION When lignt blink one timeevery 4S, it shows batteryis power out and we should change new battery. baterry is Note: it can′t work when power out. STRAINER AND MOUTH-FILTER CLEANING Clean strainer and mouth-filte every six to twelve months or when water flux is fewer.
- Page 12 WARNING PROCEEDS Avoid objects! Avoid Strong hit! It will influence correct detection if There are electronic components and there are some other objects on some plastic elements in machine. so sensor display,We must cleanthem. it should avoid strong hit. Don′t use acid and alkaline cleanser! alkaline acid...
- Page 13 PROBLEM ELIMINATION Phenomenon Trouble reason Elimination Change new ones Batteries Power-out(DC mode products) No water Await water Too dirty for strainer Clean strainrer Not flush Dirt or other object on sensor display Clean dirt or move object Re-design as per Water pressure not under range specification Batteries power-out (DC mode products)
